Ermak Power-Bend Falcon 3760-220
Image: ermaksan.com.tr, Ermak
Key Specifications
bending length
bending power
distance between columns
y rapid speed
y working speed
y return speed
How much does the Ermak Power-Bend Falcon 3760-220 cost?
Price estimate
We do not have a price for the Ermak Power-Bend Falcon 3760-220 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Between sheet and plate there is a band of work, heavy sheet and medium plate in long lengths, that the Ermak Power-Bend Falcon 3760-220 is well placed for. It has 220 Ton (243 US tons) and a bending length of 3,760 mm (148 in).
Ermak widens the table to 160 mm at this tonnage. That supports the larger dies medium plate calls for without going to the very wide tables of the heaviest Falcons.
The drive is an 18.5 kW motor on a 300 L tank. In the cycle the ram moves at 180 mm/s on the way down and 160 mm/s on the way back, with the usual 10 mm/s under load. No other 3,760 mm Falcon returns as fast.
Overall the machine is 5,700 mm long, 2,300 mm wide and 2,710 mm high. Curiously it is lower than the Power-Bend Falcon 3760-175, which stands 2,930 mm. The weight is 12,750 kg.
Standard opening applies: 275 mm stroke, 550 mm daylight, 410 mm throat, 3,250 mm between the columns. The table height is 900 mm. X and R give 800 mm and 250 mm of backgauge travel, and both Y cylinders are measured by linear rulers on the top beam.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Length | 3,760 mm (148 in) |
| Bending Power | 220 Ton (243 US tons) |
| Distance Between Columns | 3,250 mm (128 in) |
| Y Rapid Speed | 180 mm/s (7.09 in/s) |
| Y Working Speed | 10 mm/s (0.39 in/s) |
| Y Return Speed | 160 mm/s (6.3 in/s) |
| Crowning | Motorized |
| X Axis Travel | 800 mm (31.5 in) |
| X Axis Speed | 500 mm/s (19.69 in/s) |
| R Axis Travel | 250 mm (9.8 in) |
| R Axis Speed | 350 mm/s (13.78 in/s) |
| Backgauge Finger Blocks | 2 |
| Sheet Supports | 2 |
| Oil Capacity | 300 L (79.3 US gal) |
| Motor Power | 18.5 kW (24.8 hp) |
| Stroke | 275 mm (10.8 in) |
| Daylight | 550 mm (21.7 in) |
| Throat Depth | 410 mm (16.1 in) |
| Table Height | 900 mm (35.4 in) |
| Table Width | 160 mm (6.3 in) |
| Length | 5,700 mm (224.4 in) |
| Height | 2,710 mm (106.7 in) |
| Width | 2,300 mm (90.6 in) |
| Machine Weight | 12,750 kg (28,108 lb) |
Specifications sourced from ermaksan.com.tr — verified 2026-10-05
Strengths & Limitations
Strengths
- 160 mm/s return, the quickest among the 3,760 mm sizes
- 220 Ton for medium plate in long lengths
- 160 mm table width for larger dies
- 2,710 mm height is moderate for the tonnage
Limitations
- 300 L oil fill and 18.5 kW connected motor power
- 12,750 kg on a 5,700 mm by 2,300 mm footprint
- 550 mm daylight; the larger opening needs a heavier model
- Sheet supports number 2 as standard
Best For
Frequently Asked Questions
01
Long parts in medium plate and heavier sheet. The machine combines 220 Ton with a 3,760 mm bending length and a 160 mm wide table for larger dies.
02
Space for a machine 5,700 mm long, 2,300 mm wide and 2,710 mm high, a floor for 12,750 kg, supply for an 18.5 kW motor and 300 L of hydraulic oil.
03
The Power-Bend Falcon 3760-260 has a 200 mm table and a 22 kW motor, with a 140 mm/s approach. This model has a 160 mm table and approaches at 180 mm/s.
04
Ermak does not print a positioning figure in the table. It states that linear rulers on the top beam synchronise Y1 and Y2 with a tolerance of 0.01.
