Ermak Power-Bend Falcon 6100-220
Image: ermaksan.com.tr, Ermak
Key Specifications
bending length
bending power
distance between columns
y rapid speed
y working speed
y return speed
How much does the Ermak Power-Bend Falcon 6100-220 cost?
Price estimate
We do not have a price for the Ermak Power-Bend Falcon 6100-220 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Six-metre bending starts in the Falcon series with the Ermak Power-Bend Falcon 6100-220. The bed takes 6,100 mm (240.2 in), roughly 20 ft, and bending power is 220 Ton (243 US tons).
Ermak changes the equipment for this length. There are 4 backgauge finger blocks and 4 sheet supports where shorter Falcons have 2 of each, since a six-metre blank resting on two points would droop between them. The table height also rises, to 1,100 mm.
The frame is far heavier than the tonnage alone would require. At 24,828 kg it outweighs the Power-Bend Falcon 4270-220, a 14,000 kg machine with an equal force rating, because a long bed and ram must be deep to stay straight.
Speeds are 130 mm/s in approach, 10 mm/s in work and 125 mm/s in return. The motor is 18.5 kW, the oil capacity 300 L. Stroke, daylight and throat are 275 mm, 550 mm and 410 mm. Between the columns the passage is 5,100 mm (200.8 in). The table is 180 mm wide.
A building has to be found for it: 7,750 mm long, 2,260 mm wide, 3,000 mm high. With 220 Ton spread over six metres, full-length work means thin sheet such as lighting poles in halves, long gutters and facade profiles, while thicker stock is bent on part of the bed.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Length | 6,100 mm (240.2 in) |
| Bending Power | 220 Ton (243 US tons) |
| Distance Between Columns | 5,100 mm (200.8 in) |
| Y Rapid Speed | 130 mm/s (5.12 in/s) |
| Y Working Speed | 10 mm/s (0.39 in/s) |
| Y Return Speed | 125 mm/s (4.92 in/s) |
| Crowning | Motorized |
| X Axis Travel | 800 mm (31.5 in) |
| X Axis Speed | 500 mm/s (19.69 in/s) |
| R Axis Travel | 250 mm (9.8 in) |
| R Axis Speed | 350 mm/s (13.78 in/s) |
| Backgauge Finger Blocks | 4 |
| Sheet Supports | 4 |
| Oil Capacity | 300 L (79.3 US gal) |
| Motor Power | 18.5 kW (24.8 hp) |
| Stroke | 275 mm (10.8 in) |
| Daylight | 550 mm (21.7 in) |
| Throat Depth | 410 mm (16.1 in) |
| Table Height | 1,100 mm (43.3 in) |
| Table Width | 180 mm (7.1 in) |
| Length | 7,750 mm (305.1 in) |
| Height | 3,000 mm (118.1 in) |
| Width | 2,260 mm (89 in) |
| Machine Weight | 24,828 kg (54,735 lb) |
Specifications sourced from ermaksan.com.tr — verified 2026-10-05
Strengths & Limitations
Strengths
- 6,100 mm bending length, about 20 ft
- 4 finger blocks and 4 sheet supports as standard
- 5,100 mm between the columns
- 18.5 kW motor keeps the power demand moderate
Limitations
- 220 Ton over 6,100 mm allows thin material only at full length
- 24,828 kg and 7,750 mm of floor length
- Table height of 1,100 mm, high for hand loading
- 130 mm/s approach and 125 mm/s return
Best For
Frequently Asked Questions
01
The backgauge gets 4 finger blocks, the front gets 4 sheet supports, and the table sits at 1,100 mm. Stroke, daylight and throat stay at the standard 275 mm, 550 mm and 410 mm.
02
7,750 mm in length, 2,260 mm in width and 3,000 mm in height. In front of the machine there must also be room to bring a blank of up to 6,100 mm to the die.
03
It weighs 24,828 kg. Ermak does not comment on the figure, but beams spanning 5,100 mm between columns have to be much deeper than those of a short machine to limit deflection.
04
A bed of 6,100 mm with 4 finger blocks lends itself to two tool stations. Ermak's optional LED bar guiding system marks bending stations with coloured LED bars.
