Ermak Power-Bend Falcon 3760-135
Image: ermaksan.com.tr, Ermak
Key Specifications
bending length
bending power
distance between columns
y rapid speed
y working speed
y return speed
How much does the Ermak Power-Bend Falcon 3760-135 cost?
Price estimate
We do not have a price for the Ermak Power-Bend Falcon 3760-135 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Some parts are simply longer than three metres: door frames, lighting troughs, cladding trays. The Ermak Power-Bend Falcon 3760-135 serves them with a 3,760 mm (148 in) bending length and 135 Ton (149 US tons) of bending power.
That tonnage over that length points to thin material. The machine is quick to match, with the ram dropping at 200 mm/s, pressing at 10 mm/s and lifting at 120 mm/s. An 11 kW motor and a 200 L tank are all the hydraulics it needs.
Long thin parts are where crowning earns its place. A lightly built bed of this length bows under load, the middle of the bend opens up, and the operator ends up shimming dies. Here the CNC drives a motorized crowning system that corrects the deflection for each program.
There are 3,250 mm (128 in) between the columns, generous for a bed of this size. Stroke is 275 mm, daylight 550 mm, throat depth 410 mm. The table is 90 mm wide and 900 mm from the floor.
The footprint is 5,560 mm by 2,150 mm, the height 2,650 mm and the weight 9,400 kg. Two sheet supports are standard, which is few for flimsy parts nearly four metres long; pneumatic rear supports and a sheet extraction system are on Ermak's option list.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Length | 3,760 mm (148 in) |
| Bending Power | 135 Ton (149 US tons) |
| Distance Between Columns | 3,250 mm (128 in) |
| Y Rapid Speed | 200 mm/s (7.87 in/s) |
| Y Working Speed | 10 mm/s (0.39 in/s) |
| Y Return Speed | 120 mm/s (4.72 in/s) |
| Crowning | Motorized |
| X Axis Travel | 800 mm (31.5 in) |
| X Axis Speed | 500 mm/s (19.69 in/s) |
| R Axis Travel | 250 mm (9.8 in) |
| R Axis Speed | 350 mm/s (13.78 in/s) |
| Backgauge Finger Blocks | 2 |
| Sheet Supports | 2 |
| Oil Capacity | 200 L (52.8 US gal) |
| Motor Power | 11 kW (14.8 hp) |
| Stroke | 275 mm (10.8 in) |
| Daylight | 550 mm (21.7 in) |
| Throat Depth | 410 mm (16.1 in) |
| Table Height | 900 mm (35.4 in) |
| Table Width | 90 mm (3.5 in) |
| Length | 5,560 mm (218.9 in) |
| Height | 2,650 mm (104.3 in) |
| Width | 2,150 mm (84.6 in) |
| Machine Weight | 9,400 kg (20,723 lb) |
Specifications sourced from ermaksan.com.tr — verified 2026-10-05
Strengths & Limitations
Strengths
- 3,760 mm bending length with a 200 mm/s rapid approach
- 3,250 mm of clearance between the columns
- Motorized crowning corrects bow on long thin bends
- 11 kW motor: low installed power for the bed length
Limitations
- 135 Ton across 3,760 mm confines the work to light gauges
- 120 mm/s return is the slowest part of the cycle
- Two sheet supports for parts close to four metres
- Table only 90 mm wide, for narrow dies
Best For
Frequently Asked Questions
01
Shops whose parts outgrow a three-metre brake but stay thin. It bends 3,760 mm with 135 Ton and passes parts up to 3,250 mm wide between its columns.
02
By motorized crowning under CNC control, listed as standard for this size. Ermak states that it compensates deflection automatically to keep bend angles even along the part.
03
Rapid approach is 200 mm/s, working speed 10 mm/s and return speed 120 mm/s. The X axis of the backgauge moves at 500 mm/s over a travel of 800 mm.
04
Yes. The Power-Bend Falcon 3760-175 uses a 15 kW motor and weighs 10,300 kg, within the same 5,560 mm overall length. This model weighs 9,400 kg.
