Dener DD-M-10030

Specs verified 2026-10-05 · en.dener.com Updated 2026-10-05

Key Specifications

bending length

3,050 mm (120.1 in)

bending capacity

100 ton

stroke

300 mm (11.8 in)

distance between tables

660 mm (26 in)

approach speed

75 mm/sec

bending speed

20 mm/sec

How much does the Dener DD-M-10030 cost?

Price estimate

Uncertain

We do not have a price for the Dener DD-M-10030 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

A three-metre electric brake at 100 ton is the classic job-shop size, and the Dener DD-M-10030 is Dener's version of it. Bending length is 3,050 mm (120.1 in). The drive is servo electric with no hydraulic circuit.

This is the lightest of the three DD-M models on the 3,050 mm bed. It weighs 6,500 kg (14,330 lb) and keeps the 11 kW (14.8 hp) motor of the smaller sizes. The other two, the DD-M-13030 and DD-M-15030, add force and motor power on the same length.

Ram travel is the slowest row in its table: 75 mm/sec for both approach and return. Bending itself runs at 20 mm/sec. A buyer comparing cycle times should time a real part, because the fast bend and the slow approach pull in opposite directions depending on stroke length.

The opening is 300 mm of stroke with 660 mm between the tables. Overall length is 4,220 mm, depth 1,960 mm and height 2,500 mm.

Dener lists an ESA 875 W 3D control, Y1, Y2, X and R axes and a DSP front laser safety system as standard. Options include six-axis ATF backgauges, a sheet follower, automatic angle measuring and Wila clamping.

Full Specifications

Parameter	Value
Bending Length	3,050 mm (120.1 in)
Bending Capacity	100 ton
Stroke	300 mm (11.8 in)
Distance Between Tables	660 mm (26 in)
Approach Speed	75 mm/sec
Bending Speed	20 mm/sec
Return Speed	75 mm/sec
Motor Power	11 kW (14.8 hp)
Machine Weight	6,500 kg (14,330 lb)
Machine Length	4,220 mm (166.1 in)
Machine Depth	1,960 mm (77.2 in)
Machine Height	2,500 mm (98.4 in)
Maximum Height	2,900 mm (114.2 in)

Specifications sourced from en.dener.com — verified 2026-10-05

Strengths & Limitations

Strengths

3,050 mm bending length in a 6,500 kg (14,330 lb) all-electric machine
20 mm/sec bending speed, a series constant
Modest 11 kW (14.8 hp) drive motor
660 mm between tables with a 300 mm stroke

Limitations

Approach and return of 75 mm/sec are the slowest in the DD-M table
100 ton over 3,050 mm is a thin-sheet rating at full length
Crowning has to be ordered as an option

Best For

Full-sheet panels in thin gauge Job shops moving from hydraulic to electric bending Parts with shallow strokes and many bends

Frequently Asked Questions

01 What are the key figures of the Dener DD-M-10030?

100 ton maximum tonnage, 3,050 mm (120.1 in) bending length, 300 mm maximum stroke and 660 mm between the tables. The motor is 11 kW (14.8 hp).

02 How does it compare with the DD-M-13030?

Both bend 3,050 mm. The DD-M-13030 offers 130 ton with a 12.5 kW motor, runs approach and return at 85 mm/sec and weighs 8,500 kg. The DD-M-10030 is rated at 100 ton and weighs 6,500 kg.

03 What speeds does the DD-M-10030 reach?

75 mm/sec on approach, 20 mm/sec in the bend and 75 mm/sec on return, according to the specification table on the maker's page.

04 What electrical supply is needed?

The standard equipment list states a 380 V, 50-60 Hz, 3-phase electrical system. Motor power is 11 kW (14.8 hp), and an electrical cabinet cooling system is included.
