Dener DD-M-15030
Key Specifications
bending length
bending capacity
stroke
distance between tables
approach speed
bending speed
How much does the Dener DD-M-15030 cost?
Price estimate
We do not have a price for the Dener DD-M-15030 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
With 150 ton on a 3,050 mm (120.1 in) bed, the Dener DD-M-15030 is the strongest three-metre model among Dener's servo electric press brakes. It is also the point where the drive doubles in size.
The motor is 22 kW (29.5 hp). Compare that with the 12.5 kW of the DD-M-13030 and the reason for the next figure becomes clear: approach and return run at 100 mm/sec, the best ram speed among the larger DD-M models. Bending speed is 20 mm/sec.
The machine is bigger in every direction. It is 4,740 mm long, 2,000 mm deep and 2,680 mm high, and it weighs 9,500 kg (20,944 lb).
The usable opening has not grown, though. Maximum stroke is 300 mm and the tables are 660 mm apart, the same as on the smallest model in the range. That suits sheet and light plate, not tall tooling for heavy sections.
Who needs it? A shop that wants electric accuracy and low energy use but regularly bends three-metre parts beyond the reach of the two lighter models on this bed. Dener quotes up to 50% lower energy consumption than hydraulic press brakes for the series.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Length | 3,050 mm (120.1 in) |
| Bending Capacity | 150 ton |
| Stroke | 300 mm (11.8 in) |
| Distance Between Tables | 660 mm (26 in) |
| Approach Speed | 100 mm/sec |
| Bending Speed | 20 mm/sec |
| Return Speed | 100 mm/sec |
| Motor Power | 22 kW (29.5 hp) |
| Machine Weight | 9,500 kg (20,944 lb) |
| Machine Length | 4,740 mm (186.6 in) |
| Machine Depth | 2,000 mm (78.7 in) |
| Machine Height | 2,680 mm (105.5 in) |
| Maximum Height | 2,950 mm (116.1 in) |
Specifications sourced from en.dener.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 150 ton, the most Dener offers on its 3,050 mm electric bed
- 100 mm/sec approach and return with 20 mm/sec bending
- 22 kW (29.5 hp) servo drive
- No hydraulic oil to maintain
Limitations
- Stroke of 300 mm is the same as on the smallest DD-M
- Needs 4,740 mm of length for a 3,050 mm bed
- Weighs 9,500 kg (20,944 lb) on the floor
Best For
Frequently Asked Questions
01
150 ton maximum over a bending length of 3,050 mm (120.1 in). The motor power is 22 kW (29.5 hp) and the maximum stroke is 300 mm.
02
The DD-M-13030 has 130 ton, a 12.5 kW motor and 85 mm/sec ram travel. The DD-M-15030 has 150 ton, a 22 kW motor and 100 mm/sec, and is longer at 4,740 mm.
03
Overall length 4,740 mm, depth 2,000 mm, height 2,680 mm and maximum height 2,950 mm. The weight is 9,500 kg (20,944 lb).
04
An automatic angle measuring system is on the optional equipment list, together with a sheet follower system and manual or automatic crowning. None of the three is standard.
