AWEA LG-10030
Image: awea.com, AWEA
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
Spindle Power
x axis travel
How much does the AWEA LG-10030 cost?
Price estimate
We do not have a price for the AWEA LG-10030 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Ten metres of X on a 3,000 mm (118.1 in) Y: the AWEA LG-10030 is the longest machine in the narrow LG group, with X travel of 10,000 mm (393.7 in), Z of 1,000 mm (39.4 in) and a fixed table of 10,000 x 2,800 mm (393.7 x 110.2 in).
Length costs accuracy, and the table says how much. X positioning under VDI is P = 0.050 mm with repeatability of Ps = 0.038 mm. The LG-4030 at the other end of the group is listed at P = 0.025 mm and Ps = 0.018 mm. Across the gantry nothing changes: Y and Z stay at P = 0.025 mm over full travel and Ps = 0.020 mm. So features machined across the part are held as closely as on the short machines. It is positions along the length that need the wider tolerance.
The fixed table is what makes this length practical. Its load rating is 2,500 kg/m² wherever the work sits, AWEA describes a double layer table attached firmly to the base, and the modular table and side columns are how the X travel gets extended. Chips leave by two rotating augers, on both sides of the table, into a separate 1,300 liter coolant tank.
If the part is wider than the table, the LG-10040 keeps the same X and adds a metre of Y: 4,000 mm (157.5 in) with a 10,000 x 3,800 mm (393.7 x 149.6 in) table. X rapid on this machine is 20 m/min (787 ipm), Y is 15 m/min (591 ipm).
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 10,000 mm (393.7 in) |
| Y Axis Travel | 3,000 mm (118.1 in) |
| Z Axis Travel | 1,000 mm (39.4 in) |
| Table Size | 10,000 x 2,800 mm (393.7 x 110.2 in) |
| Max Table Load | 2,500 kg/m² |
| Distance Spindle Nose to Table | 200 ~ 1,200 mm (7.9 ~ 47.2 in) |
| Distance Between Columns with Water Eliminator | 3,800 mm (3,500 mm) |
| Spindle Motor Power | 22 / 26 kW (30 / 35 HP) |
| Max Spindle Speed | Gear 4,000 rpm (Std.) ; Gear 5,000 / 6,000 rpm (Opt.) ; Built-in 6,000 / 8,000 rpm (Opt.) |
| Spindle Taper | CAT50 (7 / 24) |
| Rapid Traverse X | 20 m/min (787 ipm) |
| Rapid Traverse Y | 15 m/min (591 ipm) |
| Rapid Traverse Z | 10 m/min (394 ipm) |
| Cutting Feed Rate | 1 ~ 10 m/min (39 ~ 394 ipm) |
| Tool Capacity | 32 |
| Max Tool Diameter (full magazine) | Ø127 / 215 mm (Ø5.0 / 8.5 in) |
| Max Tool Length | 350 mm (13.8 in) |
| Max Tool Weight | 20 kg (44 lb) |
| Positioning Accuracy Jis B 6338 | ± 0.025 / Full Travel |
| Positioning Accuracy X VDI 3441 | P = 0.050 mm |
| Positioning Accuracy Yz VDI 3441 | P = 0.025 mm / Full Travel |
| Repeatability Jis B 6338 | ± 0.003 mm |
| Repeatability VDI 3441 | Ps = 0.038 mm |
| Repeatability Yz VDI 3441 | Ps = 0.020 mm |
| Power Requirement | 80 kVA 220 ±10 % Vac 3 phase 50 / 60 Hz |
| Air Pressure Requirement | 5 ~ 8 (5) kg/cm² |
| Hydraulic Tank Capacity | 120 liter |
| Lubrication Tank Capacity | 6 liter |
| Coolant Tank Capacity | 1,300 liter |
Specifications sourced from awea.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 10,000 mm (393.7 in) of X travel, the longest of the LG models with 3,000 mm (118.1 in) of Y
- Y and Z accuracy unchanged from the shortest model: P = 0.025 mm over full travel, Ps = 0.020 mm
- Load rating of 2,500 kg/m² applies along the whole 10,000 x 2,800 mm (393.7 x 110.2 in) table
- 20 m/min (787 ipm) X rapid, so crossing the table end to end is not the slow part of the cycle
- Chip augers on both sides of the table and a separate 1,300 liter coolant tank
Limitations
- X positioning of P = 0.050 mm and repeatability of Ps = 0.038 mm, the widest figures in the 3,000 mm group
- The coolant tank is 1,300 liter, the same as on the LG-4030 with a table less than half as long
- 32 tools serve a 10,000 mm table; the specification for this size shows no larger magazine
- Cutting feed is limited to 1 ~ 10 m/min (39 ~ 394 ipm), half the X rapid
Best For
Frequently Asked Questions
01
02
Width. The LG-10040 has 4,000 mm (157.5 in) of Y, a 10,000 x 3,800 mm (393.7 x 149.6 in) table and a 1,600 liter coolant tank, and its Y and Z positioning is P = 0.030 mm. The LG-10030 has 3,000 mm (118.1 in) of Y, a 2,800 mm wide table, 1,300 liter of coolant and P = 0.025 mm on Y and Z. X travel, X rapid and X accuracy are the same.
03
The rating is 2,500 kg/m², and because the table is fixed the load does not affect axis motion. AWEA describes a double layer structure that can endure super heavy work-pieces without deformation and a floor type design that attaches the table firmly to the base to damp vibration.
04
For X travels of 6 m and above AWEA uses its patented zero backlash rack & pinion combined with a high resolution linear scale, and the X-axis runs under AWEA's synchronous servo control. The listed rapid is 20 m/min (787 ipm).
