Amada EGB 4010e
Image: amada.com, Amada
Key Specifications
control
press capacity
distance between frames
open height
stroke
throat depth
How much does the Amada EGB 4010e cost?
Estimated price range
Our best estimate for a cnc press brake in this class — not a quote from Amada. Configuration moves it a long way.
Overview
The Amada EGB 4010e is a compact CNC press brake: 400 kN of press capacity, 710 mm between the frames and 7 axes under the AMNC 4ie control. The machine is 1890 mm long, 1624 mm wide and 2300 mm high, so it takes the floor space of a small machine tool, not of a bending bay.
The working envelope is small in every direction. Open height is 420 mm and the stroke is 150 mm, which suits short punches and shallow dies; tall tooling and deep box sides use that room up quickly. Throat depth is 230 mm. A blank wider than the 710 mm frame spacing can only enter as far as the throat allows, so compare both figures against the widest part you plan to bend. Amada's table for this model states neither a bending length nor a machine weight, and both should be confirmed before tooling or a floor position is planned.
Ram speeds are 250 mm/s on approach and return and 25 mm/s while bending, a tenth of the approach speed. On small parts the stroke is short and the bend itself is brief, so the fast approach and return are what shorten the cycle. Oil capacity is listed as 0 l: there is no hydraulic tank to fill, change or dispose of.
Larger work moves to the bigger machines of the range. The EGB 6020e has 600 kN, 10 axes, a 250 mm stroke and 1700 mm between the frames, and the EGB 8025e goes to 800 kN with 2220 mm between the frames.
Full Specifications
| Parameter | Value |
|---|---|
| CNC Control | AMNC 4ie |
| Press Capacity | 400 kN |
| Distance Between Frames | 710 mm |
| Open Height | 420 mm |
| Stroke | 150 mm |
| Throat Depth | 230 mm |
| Oil Capacity | 0 l |
| Approach Speed | 250 mm/s |
| Bending Speed | 25 mm/s |
| Return Speed | 250 mm/s |
| Number of Axes | 7 |
| Machine Length | 1890 mm |
| Machine Width | 1624 mm |
| Machine Height | 2300 mm |
Specifications sourced from amada.eu — verified 2026-10-03
Strengths & Limitations
Strengths
- Approach and return at 250 mm/s keep the non-bending part of each stroke short on small parts
- Compact installation: 1890 mm long, 1624 mm wide and 2300 mm high
- Oil capacity is listed as 0 l, so there is no hydraulic oil to change or dispose of
- 7 axes under the AMNC 4ie control on a 400 kN machine
Limitations
- 400 kN press capacity rules out thick or long bends; the EGB 6020e offers 600 kN and the EGB 8025e 800 kN
- Only 710 mm between the frames and 230 mm of throat depth, so wide blanks cannot pass far behind the tooling
- The 150 mm stroke and 420 mm open height leave little room for tall punches or deep box sides
- Amada's table for this model gives no bending length and no machine weight
Best For
Frequently Asked Questions
01
400 kN. The EGB 6020e is rated 600 kN and the EGB 8025e 800 kN, so this has the lowest capacity of the three. Work out the force your thickest and longest bend needs before settling on this size.
02
The frames are 710 mm apart, throat depth is 230 mm, open height is 420 mm and the stroke is 150 mm. Parts narrower than the frame spacing can pass between the frames; wider blanks are limited by the throat. Amada's table for this model does not give a bending length, so ask for it with the quotation.
03
Approach and return are both 250 mm/s, and the bending speed is 25 mm/s. The approach is ten times the bending speed, which matters most on small parts where the ram spends more of each cycle travelling than forming.
04
The machine measures 1890 mm long, 1624 mm wide and 2300 mm high. Allow room around it for the operator and for the largest blank. The table does not state a weight, so get that figure from Amada before planning the floor or the lift.
05
The oil capacity is listed as 0 l, so there is no oil tank to maintain. Routine jobs tied to hydraulic oil, such as oil changes and disposal, do not apply to this machine.
