You Ji VHL1600ATC
Image: image.youji.com, You Ji
Key Specifications
Spindle Power
table diameter
max swing diameter
max turning diameter
max turning height
x1 axis travel
How much does the You Ji VHL1600ATC cost?
Price estimate
We do not have a price for the You Ji VHL1600ATC that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
On the You Ji VHL1600ATC a side head works alongside the main ram of a Ø1,600 mm (63.0 in) vertical turning center. The machine turns Ø1,800 mm (70.9 in), swings Ø2,000 mm (78.7 in) and takes parts 1,200 mm (47.2 in) high.
Most of its column in the catalogue repeats the smaller VHL1200ATC. Z1 travel is 900 mm (35.4 in), crossrail travel 800 mm (31.5 in), and the side head again has 1,720 mm (67.7 in) of X2 and 800 mm (31.5 in) of Z2. The motors are the same pair: 37/45 kW (49.6/60.3 hp) (α40i) for the table and 7.5/11 kW (10.1/14.8 hp) (α8i) for the side head's live spindle.
The row that changes is X1. The main ram travels -600, +1,050 mm (-23.6, +41.3 in), a longer positive stroke to reach the rim of the larger table. Because the side head's X2 stroke is not lengthened, how far it can retract from and approach a full-diameter part is worth checking on the layout drawing.
Floor dimension is 12,500 x 6,200 mm (492.1 x 244.1 in) and height 5,500 mm (216.5 in). The series key lists ATC, ATC+C and two column height increases. Rail wheels and tyres, large brake drums, crane sheaves and flanged cylinders are the kind of part where a tool on the outside and a tool on the face can cut together.
Full Specifications
| Parameter | Value |
|---|---|
| Table Diameter | Ø1,600 mm (63.0 in) |
| Max Swing Diameter | Ø2,000 mm (78.7 in) |
| Max Turning Diameter | Ø1,800 mm (70.9 in) |
| Max Turning Height | 1,200 mm (47.2 in) |
| X1 Axis Travel | -600, +1,050 mm (-23.6, +41.3 in) |
| Z1 Axis Travel | 900 mm (35.4 in) |
| Crossrail Vertical Travel | 800 mm (31.5 in) |
| Spindle Motor Power | 37/45 kW (49.6/60.3 hp) (α40i) |
| Side Head X2 Axis Travel | 1,720 mm (67.7 in) |
| Side Head Z2 Axis Travel | 800 mm (31.5 in) |
| Side Head Live Spindle Power | 7.5/11 kW (10.1/14.8 hp) (α8i) |
| Floor Space | 12,500 x 6,200 mm (492.1 x 244.1 in) |
| Machine Height | 5,500 mm (216.5 in) |
Specifications sourced from image.youji.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Main ram X1 travel of -600, +1,050 mm (-23.6, +41.3 in) on a Ø1,600 mm (63.0 in) table
- Side head with its own 7.5/11 kW (10.1/14.8 hp) live spindle motor
- Ø1,800 mm (70.9 in) turning diameter and 1,200 mm (47.2 in) turning height
- ATC, ATC+C and raised-column builds are listed
Limitations
- Side head X2 travel stays at 1,720 mm (67.7 in), the same as on the VHL1200ATC
- Table motor is 37/45 kW (49.6/60.3 hp); the VHL2000ATC has 60/75 kW (80.5/100.6 hp)
- Occupies 12,500 x 6,200 mm (492.1 x 244.1 in); no loading weight in the table
Best For
Frequently Asked Questions
01
The table, swing and turning diameter grow, and X1 travel becomes -600, +1,050 mm (-23.6, +41.3 in). On the VHL1200ATC it is -600, +875 mm (-23.6, +34.4 in). Z1, crossrail, side head travels and both motors are unchanged.
02
X2-axis travel 1,720 mm (67.7 in), Z2-axis travel 800 mm (31.5 in) and a live spindle motor of 7.5/11 kW (10.1/14.8 hp), marked α8i in the catalogue.
03
Table Ø1,600 mm (63.0 in), maximum swing Ø2,000 mm (78.7 in), maximum turning diameter Ø1,800 mm (70.9 in) and maximum turning height 1,200 mm (47.2 in).
04
The floor dimension is 12,500 x 6,200 mm (492.1 x 244.1 in) and the machine height 5,500 mm (216.5 in). The length comes from the side head column standing beside the table.
