Vision Wide Vertical Machining Centers (VMC)

Vision Wide NF-8026 / NF-8033

Q: How much does the Vision Wide NF-8026 / NF-8033 cost?

The price estimate for the Vision Wide NF-8026 / NF-8033 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/vision-wide-nf-8026-nf-8033#price; the request is passed to Vision Wide or an authorised dealer.

Specs verified 2026-10-04 · visionwide-tech.com Updated 2026-10-04

Image: visionwide-tech.com, Vision Wide

Key Specifications

Table Size

8,000×2,450 mm (315.0×96.5 in)

x axis travel

8,100 mm (318.9 in)

y axis travel

2,600/ 3,300 mm (102.4/ 129.9 in)

z axis travel box way single ballscrew

920 / 1,020 mm (36.2 / 40.2 in)(Opt.)

z axis travel linear way enclosed box ram dual ballscrews

1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)

max table load

24,000 kg (52,910 lb)

How much does the Vision Wide NF-8026 / NF-8033 cost?

Price estimate

Uncertain

We do not have a price for the Vision Wide NF-8026 / NF-8033 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

For parts that are both long and wide, the Vision Wide NF-8026 / NF-8033 offers 8,100 mm (318.9 in) of X travel over an 8,000×2,450 mm (315.0×96.5 in) table. Load capacity is 24,000 kg (52,910 lb).

A table of this size holds more than one job. Two four-metre weldments can sit end to end, or a single long frame can share the table with its own fixtures and a tool setter. With five-face heads the machine can finish each without turning it, which on parts of this weight means no second crane lift and no second alignment.

Plan the cycle around the feed figures. Cutting feed is 1-7,000 mm/min and the X/Y rapid is 8 m/min, so a move from one end of the table to the other is a slow one. Grouping operations by position, not by tool, saves real time on this machine.

Y travel is 2,600 mm (102.4 in) on the NF-8026 and 3,300 mm (129.9 in) on the NF-8033. Both X and, on the NF-8033, Y are long enough to come under the maker's rule for a ballscrew support device. The standard spindle is the 4,000 rpm box way gear type with 18.5/22 kW (24.8/29.5 hp).

Full Specifications

Parameter	Value
X Axis Travel	8,100 mm (318.9 in)
Y Axis Travel	2,600/ 3,300 mm (102.4/ 129.9 in)
Z Axis Travel Box Way Single Ballscrew	920 / 1,020 mm (36.2 / 40.2 in)(Opt.)
Z Axis Travel Linear Way Enclosed Box Ram Dual Ballscrews	1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)
Table Size	8,000×2,450 mm (315.0×96.5 in)
Max Table Load	24,000 kg (52,910 lb)
Spindle Power Cont 30 Min	18.5/22 kW (24.8/29.5 hp)(22/26 kW (29.5/34.9 hp) Opt.)(30/37 kW (40.2/49.6 hp) Opt.)
Spindle Speed Box Way 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram Direct Driven	10,000 rpm(Opt.)
Cutting Feed Rate	1-7,000 mm/min
Rapid Traverse Xy	8 m/min
Rapid Traverse Z Box Way or Linear Way	15 m/min
Rapid Traverse Z Enclosed Box Ram	12 m/min
Tool Capacity Vertical Tool Change	32 / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Horizontal Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)

Specifications sourced from visionwide-tech.com — verified 2026-10-04

Strengths & Limitations

Strengths

8,000×2,450 mm (315.0×96.5 in) table holds two four-metre parts end to end
24,000 kg (52,910 lb) table load
Y travel of 3,300 mm (129.9 in) on the NF-8033
X, Y-axis ballscrew support device is standard on long axes

Limitations

X/Y rapid of 8 m/min makes end-to-end moves slow
Cutting feed capped at 7,000 mm/min
Standard spindle speed is 4,000 rpm

Best For

Two large weldments machined in one loading Long, wide frames up to 24,000 kg (52,910 lb) Five-face work that avoids a second crane lift

Frequently Asked Questions

01 How large is the Vision Wide NF-8026 table?

8,000×2,450 mm (315.0×96.5 in), with a maximum table load of 24,000 kg (52,910 lb). X travel is 8,100 mm (318.9 in).

02 How fast does the NF-8026 / NF-8033 move?

X/Y rapid traverse is 8 m/min and cutting feed is 1-7,000 mm/min. Z rapid is 15 m/min with the box way or linear way head and 12 m/min with the enclosed box ram.

03 What is the Y travel of the NF-8026 and NF-8033?

2,600 mm (102.4 in) on the NF-8026 and 3,300 mm (129.9 in) on the NF-8033. Vision Wide prints the two as 2,600/ 3,300 mm (102.4/ 129.9 in) in one column.

04 Does the NF-8026 have supported ballscrews?

The standard accessory list includes an X, Y-axis ballscrew support device where the X axis is 4 m or longer or the Y axis 3 m or longer. X travel here is 8,100 mm (318.9 in).
