Vision Wide NF-10032 / NF-10039

Q: How much does the Vision Wide NF-10032 / NF-10039 cost?

The price estimate for the Vision Wide NF-10032 / NF-10039 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/vision-wide-nf-10032-nf-10039#price; the request is passed to Vision Wide or an authorised dealer.

Specs verified 2026-10-04 · visionwide-tech.com Updated 2026-10-04

Image: visionwide-tech.com, Vision Wide

Key Specifications

Table Size

10,000×2,450 mm (393.7×96.5 in)

x axis travel

10,100 mm (397.6 in)

y axis travel

3,200/ 3,900 mm (126.0/ 153.5 in)

z axis travel box way single ballscrew

920 / 1,020 mm (36.2 / 40.2 in)(Opt.)

z axis travel linear way enclosed box ram dual ballscrews

1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)

max table load

26,000 kg (57,319 lb)

How much does the Vision Wide NF-10032 / NF-10039 cost?

Price estimate

Uncertain

We do not have a price for the Vision Wide NF-10032 / NF-10039 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

No NF is larger than the Vision Wide NF-10032 / NF-10039. X travel is 10,100 mm (397.6 in). Y travel is 3,200 mm (126.0 in) on the NF-10032 and 3,900 mm (153.5 in) on the NF-10039. The table measures 10,000×2,450 mm (393.7×96.5 in) and the load rating is 26,000 kg (57,319 lb).

At this size the tool changer becomes a logistics question. A part that occupies the machine for days goes through a great many tools, and worn ones must be swapped during the cycle. The standard vertical type magazine holds 32 tools and travels with the machine structure. The two floor-standing types, vertical and vertical-horizontal, are optional with 32, 40 or 60 pcs, and they put the magazine where an operator can reach it from the floor while the machine cuts.

The page describes the NF as one of the maker's most attractive products for its linear guideways and Z-axis box way. In this largest form the limits are speed and standard power: an X/Y rapid of 8 m/min, cutting feed of 1-7,000 mm/min, and 18.5/22 kW (24.8/29.5 hp) unless one of the two larger motors is ordered.

For five-face work the heads are changed automatically, with a 90º head, an extension head and a universal head listed.

Full Specifications

Parameter	Value
X Axis Travel	10,100 mm (397.6 in)
Y Axis Travel	3,200/ 3,900 mm (126.0/ 153.5 in)
Z Axis Travel Box Way Single Ballscrew	920 / 1,020 mm (36.2 / 40.2 in)(Opt.)
Z Axis Travel Linear Way Enclosed Box Ram Dual Ballscrews	1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)
Table Size	10,000×2,450 mm (393.7×96.5 in)
Max Table Load	26,000 kg (57,319 lb)
Spindle Power Cont 30 Min	18.5/22 kW (24.8/29.5 hp)(22/26 kW (29.5/34.9 hp) Opt.)(30/37 kW (40.2/49.6 hp) Opt.)
Spindle Speed Box Way 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram Direct Driven	10,000 rpm(Opt.)
Cutting Feed Rate	1-7,000 mm/min
Rapid Traverse Xy	8 m/min
Rapid Traverse Z Box Way or Linear Way	15 m/min
Rapid Traverse Z Enclosed Box Ram	12 m/min
Tool Capacity Vertical Tool Change	32 / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Horizontal Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)

Specifications sourced from visionwide-tech.com — verified 2026-10-04

Strengths & Limitations

Strengths

Largest NF envelope: 10,100 mm (397.6 in) by up to 3,900 mm (153.5 in)
26,000 kg (57,319 lb) table load
Floor-standing tool changers with up to 60 pcs as options
Auto head change with 90º, extension and universal heads

Limitations

Standard magazine of 32 tools for very long cycles
X/Y rapid of 8 m/min and cutting feed of 1-7,000 mm/min
Standard motor of 18.5/22 kW (24.8/29.5 hp); larger motors are options

Best For

The largest beds, frames and beams in one clamping Multi-day cycles with floor-level tool servicing Parts up to 26,000 kg (57,319 lb)

Frequently Asked Questions

01 What is the largest Vision Wide NF machine?

The NF-10032 / NF-10039, with 10,100 mm (397.6 in) of X travel, 3,200/ 3,900 mm (126.0/ 153.5 in) of Y travel and a 10,000×2,450 mm (393.7×96.5 in) table rated for 26,000 kg (57,319 lb).

02 Which tool changers can the NF-10032 have?

A vertical type tool change with 32 tools standard and 40 or 60 optional; a floor-standing vertical type; and a floor-standing vertical-horizontal type. Both floor-standing types are optional at 32, 40 or 60 pcs.

03 How do the NF-10032 and NF-10039 differ?

The NF-10032 has 3,200 mm (126.0 in) of Y travel and the NF-10039 has 3,900 mm (153.5 in). All other figures in their shared column are the same.

04 How fast is the NF-10032 / NF-10039?

X/Y rapid traverse is 8 m/min and the cutting feed range is 1-7,000 mm/min. Z rapid is 15 m/min on the box way or linear way head and 12 m/min on the enclosed box ram.
