Vision Wide MHN-5035 / MHN-5042
Image: visionwide-tech.com, Vision Wide
Key Specifications
Table Size
x axis travel
y axis travel
z axis travel box way single ballscrew
z axis travel linear way enclosed box ram dual ballscrews
max table load
How much does the Vision Wide MHN-5035 / MHN-5042 cost?
Price estimate
We do not have a price for the Vision Wide MHN-5035 / MHN-5042 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
A 65mm guideway runs along the Y axis of the Vision Wide MHN-5035 / MHN-5042. Vision Wide calls it an ultra-load guideway and says it gives more than 40% more rigidity under higher cutting load, and a longer life.
The figure is the rail size. A larger rail has larger rolling elements and a wider base, so it deflects less when the head pushes against it and its rated load rises steeply. The 40% the maker quotes is presumably against the next size down; the page does not name the comparison. On a beam carrying the head across 3,500 mm (137.8 in) of travel, or 4,200 mm (165.4 in) on the MHN-5042, the guide is where the cutting force first enters the structure, and stiffening it is the direct way to raise the cut the machine can hold.
Life matters too. A guide working well inside its rating lasts far longer than one near its limit, and on a machine expected to run for decades that is part of what is being bought.
The table is 5,000×3,000 mm (196.9×118.1 in), rated for 24,000 kg (52,910 lb), with 5,100 mm (200.8 in) of X travel. Spindle power is 22/26 kW (29.5/34.9 hp). X/Y rapid is 10 m/min.
Full Specifications
| Parameter | Value |
|---|---|
| X Axis Travel | 5,100 mm (200.8 in) |
| Y Axis Travel | 3,500/ 4,200 mm (137.8/ 165.4 in) |
| Z Axis Travel Box Way Single Ballscrew | 920 / 1,020 mm (36.2 / 40.2 in)(Opt.) |
| Z Axis Travel Linear Way Enclosed Box Ram Dual Ballscrews | 1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.) |
| Table Size | 5,000×3,000 mm (196.9×118.1 in) |
| Max Table Load | 24,000 kg (52,910 lb) |
| Spindle Power Cont 30 Min | 22/26 kW (29.5/34.9 hp)(30/37 kW (40.2/49.6 hp) Opt.) |
| Spindle Speed Box Way 2 Step Gear | 4,000 / 6,000 rpm(Opt.) |
| Spindle Speed Linear Way Enclosed Box Ram 2 Step Gear | 4,000 / 6,000 rpm(Opt.) |
| Spindle Speed Linear Way Enclosed Box Ram Direct Driven | 10,000 rpm (Opt.) |
| Cutting Feed Rate | 1-7,000 mm/min |
| Rapid Traverse Xy | 10 m/min |
| Rapid Traverse Z Box Way or Linear Way | 15 m/min |
| Rapid Traverse Z Enclosed Box Ram | 12 m/min |
Specifications sourced from visionwide-tech.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 65mm ultra-load guideway on the Y axis
- More than 40% higher rigidity under cutting load, as stated by the maker
- 5,000×3,000 mm (196.9×118.1 in) table for 24,000 kg (52,910 lb)
- Y travel of 3,500 mm (137.8 in) or 4,200 mm (165.4 in)
Limitations
- The 40% figure has no stated baseline
- Cutting feed of 1-7,000 mm/min
- No tool changer appears in the table or on the page
Best For
Frequently Asked Questions
01
The Y-axis guide. Vision Wide says the Y-axis with a 65mm ultra-load guideway gives more than 40% more rigidity on higher cutting load and a longer lifetime. The comparison baseline is not stated.
02
X 5,100 mm (200.8 in). Y 3,500/ 4,200 mm (137.8/ 165.4 in) for the MHN-5035 and MHN-5042. Z 920 mm on the standard head, with longer strokes optional.
03
24,000 kg (52,910 lb) on a 5,000×3,000 mm (196.9×118.1 in) table. The shorter MHN-4035 carries 20,000 kg (44,092 lb).
04
Cutting feed is 1-7,000 mm/min. X/Y rapid is 10 m/min, and Z rapid 15 m/min, or 12 m/min with the enclosed box ram.
