PAMA Speedmat RAM

Q: How much does the PAMA Speedmat RAM cost?

The price estimate for the PAMA Speedmat RAM is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/pama-speedmat-ram#price; the request is passed to PAMA or an authorised dealer.

Specs verified 2026-10-05 · pamamachinetools.com Updated 2026-10-05

Key Specifications

x axis travel

2,200 - 5,000 mm

y axis travel

1,750 - 4,000 mm

v axis travel

1,500 - 4,000 mm

z axis travel

1,200 / 1,600 mm

swing diameter

2,200 - 5,000 mm

milling table size

1,250 x 1,250 - 3,000 x 3,000 mm

How much does the PAMA Speedmat RAM cost?

Price estimate

Uncertain

We do not have a price for the PAMA Speedmat RAM that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

Add a ram to the Speedmat and one more axis appears in the table. On the PAMA Speedmat RAM the column moves on a V axis of 1,500 - 4,000 mm, and Z becomes the travel of a 430 x 430 mm ram, 1,200 / 1,600 mm. The headstock no longer has to bring the whole column forward to reach into a part.

That is the practical difference from the plain Speedmat. A ram reaches inside deep housings and between flanges where a headstock face cannot go, and with a boring bar inside the ram the reach extends again by the W stroke. PAMA guides the ram on hydrostatic pads and measures its thermal elongation in real time.

The ram can carry one of three units. The W headstock has a geared boring spindle of 130 - 160 mm with 800 mm (31.5 in) of W, 41 - 82 kW and 1,389 - 3,451 Nm at 3,000 - 4,000 rpm. The WD headstock is a single Direct Drive bar: 120 mm (4.7 in), 600 mm (23.6 in) of W, 66 kW (88.5 hp), 1,175 Nm (867 lb-ft), 5,000 rpm. The MD headstock, without bar, gives 66 - 90 kW and 822 - 1,175 Nm at 6,000 rpm.

Table figures are those of the Speedmat. Swing is 2,200 - 5,000 mm, milling tables run 1,250 x 1,250 - 3,000 x 3,000 mm with up to 50,000 kg, and turning tables Ø1,250 - Ø3,500 mm with up to 32,000 kg at up to 300 rpm. X travel is 2,200 - 5,000 mm and Y 1,750 - 4,000 mm.

Rapid feed is up to 50,000 mm/min on X, Y, Z and V. As on the other PAMA centers, attachment heads, pallet systems and tool and head changers are optional, and the CNC is Siemens, Heidenhain or Fanuc.

Full Specifications

Parameter	Value
X Axis Travel	2,200 - 5,000 mm
Y Axis Travel	1,750 - 4,000 mm
V Axis Travel	1,500 - 4,000 mm
Z Axis Travel	1,200 / 1,600 mm
Swing Diameter	2,200 - 5,000 mm
Milling Table Size	1,250 x 1,250 - 3,000 x 3,000 mm
Milling Table Load	up to 50,000 kg
B Axis Rapid Feed	up to 6 rpm
Turning Table Size	Ø1,250 - Ø3,500 mm
Turning Table Load	up to 32,000 kg
Turning Speed	up to 300 rpm
Ram Section	430 x 430 mm
W Headstock Boring Spindle Diameter	130 - 160 mm
W Headstock W Axis Travel	800 mm (31.5 in)
W Headstock Transmission	2 ranges
W Headstock Spindle Power S1	41 - 82 kW
W Headstock Spindle Torque S1	1,389 - 3,451 Nm
W Headstock Spindle Speed	3,000 - 4,000 rpm
Wd Headstock Boring Spindle Diameter	120 mm (4.7 in)
Wd Headstock W Axis Travel	600 mm (23.6 in)
Wd Headstock Transmission	Direct Drive
Wd Headstock Spindle Power S1	66 kW (88.5 hp)
Wd Headstock Spindle Torque S1	1,175 Nm (867 lb-ft)
Wd Headstock Spindle Speed	5,000 rpm
Md Headstock Transmission	Direct Drive
Md Headstock Spindle Power S1	66 - 90 kW
Md Headstock Spindle Torque S1	822 - 1,175 Nm
Md Headstock Spindle Speed	6,000 rpm
Rapid Traverse Xyzv	up to 50,000 mm/min

Specifications sourced from pamamachinetools.com — verified 2026-10-05

Strengths & Limitations

Strengths

Ram of 430 x 430 mm section with Z travel of 1,200 / 1,600 mm, in addition to column travel V of 1,500 - 4,000 mm
Hydrostatically guided ram with real-time thermal elongation feedback
Geared boring bar option with 1,389 - 3,451 Nm
Rotary table load up to 50,000 kg; turning tables up to Ø3,500 mm
Up to 50,000 mm/min rapid on X, Y, Z and V

Limitations

The Direct Drive boring bar comes in one size only: 120 mm (4.7 in) with 600 mm (23.6 in) of W
MD headstock torque is 822 - 1,175 Nm, below the 2,494 Nm top figure of the Speedmat's MD headstock
Only one ram section, 430 x 430 mm, across all four sizes
B axis rapid feed is up to 6 rpm

Best For

Deep housings and parts with internal features beyond headstock reach Boring between flanges with the ram and W axis combined Multitasking on turning tables up to 32,000 kg Heavy prismatic parts up to 50,000 kg

Frequently Asked Questions

01 What is the difference between the Speedmat RAM and the Speedmat?

The Speedmat RAM has a ram in the headstock. Its Z axis is the ram stroke, 1,200 / 1,600 mm, and the column travel becomes a separate V axis of 1,500 - 4,000 mm. On the Speedmat, Z is the column travel and there is no ram. Table sizes and loads are the same on both.

02 Which spindles are available on the Speedmat RAM?

W headstock: boring spindle 130 - 160 mm, 2 ranges, 41 - 82 kW, 1,389 - 3,451 Nm, 3,000 - 4,000 rpm. WD headstock: 120 mm (4.7 in) Direct Drive bar, 66 kW (88.5 hp), 1,175 Nm (867 lb-ft), 5,000 rpm. MD headstock: Direct Drive, 66 - 90 kW, 822 - 1,175 Nm, 6,000 rpm.

03 How far can the Speedmat RAM reach into a part?

Ram travel on Z is 1,200 / 1,600 mm. With the W headstock the boring spindle adds 800 mm (31.5 in) of W, and with the WD headstock 600 mm (23.6 in). Column travel on V, 1,500 - 4,000 mm, positions the headstock before the ram extends.

04 What table options does the Speedmat RAM have?

Milling tables or pallets from 1,250 x 1,250 to 3,000 x 3,000 mm with a load capacity up to 50,000 kg and a B axis rapid feed up to 6 rpm. Turning tables of Ø1,250 - Ø3,500 mm take up to 32,000 kg and turn at up to 300 rpm.
