Palmary OCD-3240
Image: palmary.com, Palmary
Key Specifications
swing over table
distance between centers
max grinding diameter
max load between centers
wheel size
wheel peripheral speed
How much does the Palmary OCD-3240 cost?
Price estimate
We do not have a price for the Palmary OCD-3240 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Palmary OCD-3240 is the short-bed member of the OCD-32 family, a CNC cylindrical grinder with Ø320 mm (12.6 in) of swing over the table and 400 mm (15.7 in) between centers. It grinds up to Ø300 mm (11.8 in) and takes 150 kg (331 lb) between No. 4 Morse taper centers.
Short does not mean cramped along Z. The table stroke is 665 mm (26.2 in) against the 400 mm center distance, which leaves room to run the wheel clear of the part for dressing on the tailstock-mounted diamond holder that comes as standard. The wheelhead has 260 mm (10.2 in) of X stroke. Both axes rapid at 10 m/min (394 ipm).
Of the three OCD-32 lengths this one has the widest table swivel, 0° to 12°. The OCD-3260 gives 0° to 10°, so steep tapers on short parts are the case for the OCD-3240. The workhead swivels from -30° to +90° and turns at 10 to 300 rpm on a 1 kW (1.3 hp) servo motor.
The wheel is Ø405 mm, 50 to 75 mm wide, on a 5.5 kW (7.4 hp) motor, and the spindle runs in hybrid hydro-static bearings. Standard accessories include the FANUC CNC controller, a fully enclosed splash guard, a micro adjustment tailstock and a linear scale for the X axis. Total power is 18 kVA and the machine weighs 3,300 kg (7,275 lb), the lightest of the 32 family.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Table | Ø320 mm (12.6 in) |
| Distance Between Centers | 400 mm (15.7 in) |
| Max Grinding Diameter | Ø300 mm (11.8 in) |
| Max Load Between Centers | 150 kg (331 lb) |
| Wheel Size | Ø405 x 50~75 x Ø127 (Ø152.4) mm |
| Wheel Peripheral Speed | 33 m/s (6,496 ft/min) |
| X Axis Rapid Traverse | 10 m/min (394 ipm) |
| X Axis Travel | 260 mm (10.2 in) |
| X Axis Min Setting Unit | 0.001 (0.0001) mm |
| Z Axis Rapid Traverse | 10 m/min (394 ipm) |
| Z Axis Travel | 665 mm (26.2 in) |
| Z Axis Min Input Increment | 0.001 (0.0001) mm |
| Table Swivel Angle | 0°~12° |
| Workhead Swivel Angle | -30°~+90° |
| Workhead Center Taper | M.T. No. 4 |
| Work Spindle Speed | 10-300 rpm |
| Max Load of Work Spindle | 35 kg (77 lb) (max. length: 150 mm) |
| Tailstock Center Taper | M.T. No. 4 |
| Tailstock Stroke | 25 mm (1.0 in) |
| Tailstock Fine Adjustment Range | ±0.03 mm (±0.0012 in) |
| Wheel Spindle Motor | 5.5 kW (7.4 hp) (6P) |
| Workhead Motor | 1 kW (1.3 hp) |
| Wheelhead Feed Motor | 1.2 kW (1.6 hp) |
| Table Feed Motor | 1.8 kW (2.4 hp) |
| Hydrostatic Pump Motor | 0.37 kW (0.5 hp) (4P) |
| Wheel Spindle Lubrication Pump Motor | 0.37 kW (0.5 hp) (4P) |
| Coolant Pump Motor | 0.18 kW (0.2 hp) (2P) |
| Ballscrew Lubrication | Auto lubricator (LUBE) |
| Internal Grinding Spindle Motor Optional | 0.75 kW (1.0 hp) (2P) |
| Power Requirement | 18 kVA |
| Wheel Spindle Lubrication Tank | 31 L (8.2 gal) |
| Lubrication Tank | 31 L (8.2 gal) |
| Hydraulic Tank | 31 L (8.2 gal) |
| Ballscrew Lubrication Tank | 0.7 L (0.2 gal) |
| Coolant Tank | 120 L (31.7 gal) |
| Machine Weight | 3,300 kg (7,275 lb) |
| CNC Control | FANUC CNC controller |
Specifications sourced from palmary.com — verified 2026-10-05
Strengths & Limitations
Strengths
- Table swivel of 0° to 12°, the widest among the three OCD-32 bed lengths
- 665 mm (26.2 in) of table stroke on a 400 mm (15.7 in) center distance leaves run-off for dressing
- 150 kg (331 lb) between centers and a 5.5 kW (7.4 hp) wheel motor on a 3,300 kg (7,275 lb) machine
- Linear scale on X, micro adjustment tailstock and FANUC CNC controller are all standard accessories
Limitations
- 400 mm (15.7 in) between centers; longer shafts need the OCD-3260 or OCD-32100
- Hydraulic tailstock, internal grinding attachment and in-process gauge are optional accessories
- Work held on the spindle alone is limited to 35 kg (77 lb) at a maximum length of 150 mm
- Tailstock stroke is 25 mm (1.0 in), so parts of very different lengths need the tailstock repositioned
Best For
Frequently Asked Questions
01
Ø320 mm (12.6 in) swing over the table, 400 mm (15.7 in) between centers and Ø300 mm (11.8 in) maximum external grinding diameter. The centers are No. 4 Morse taper and carry 150 kg (331 lb). The work spindle on its own carries 35 kg (77 lb) including the holder.
02
The wheelhead (X axis) has a maximum stroke of 260 mm (10.2 in) and the table (Z axis) 665 mm (26.2 in). Both rapid at 10 m/min (394 ipm). The feed motors are AC servo motors rated 1.2 kW (1.6 hp) for the wheelhead and 1.8 kW (2.4 hp) for the table.
03
A FANUC CNC controller is listed among the standard accessories, together with a linear scale for the X axis. Palmary's table gives the minimum setting unit of the X axis as 0.001 mm. Options that work through the control include a touch probe gauge, an automatic in-process gauge and an automatic grinding wheel balancer.
04
The swing, wheel and wheel motor are the same. The OCD-3260 has 600 mm (23.6 in) between centers and 900 mm (35.4 in) of table stroke, and weighs 3,600 kg (7,937 lb). The OCD-3240 is 3,300 kg (7,275 lb) and swivels its table to 12°, against 10° on the OCD-3260. Pick by part length.
