LICO LNT-51S
Image: licomachinery.com, LICO
Key Specifications
Max Spindle
Spindle Power
bar capacity
spindle center height
collet chuck type
spindle nose
How much does the LICO LNT-51S cost?
Price estimate
We do not have a price for the LICO LNT-51S that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
With the LICO LNT-51S the LNT S series changes spindle motor. This multi-slide CNC automatic takes 50.8 mm (2.0 in) bar and is rated 20 kW (27 HP) with the S840Dsl control or 15 kW (20 HP) with the M730, a step above the two smaller sizes. Maximum speed is 4,500 rpm.
The LNT-42S, one size down, is listed at 15 kW (20 HP) with the S840Dsl. So the move to two-inch bar brings a larger motor with it, and the total power required rises to 30 kVA. LICO gives an ISO A2-5 spindle nose for this size and an F58 (Ø51) collet chuck. The through hole is 60 mm (2.4 in) and the draw tube 52 mm (2.0 in).
What does not change is the rest of the machine. The compound slide still travels 115 mm (4.52 in) in Z and 70 mm (2.75 in) in X, the main turret still has 8 positions and 160 mm (6.3 in) of X travel, and the listed weight is still 3,200 kg (7,040 lb) net. A buyer moving up from a smaller LNT gets more bar and more motor on slides of the same reach.
One limit deserves a check on parts near full bar size. The pick-off device that carries the part to back machining is offered with four chucks: TNS42, TNS42E65, HAINBUCH32 and a 4 in chuck, and their capacities are listed as Ø42 / Ø65 / Ø32 / Ø65 mm. A part turned from 50.8 mm (2.0 in) stock will not fit every one of them. The pick-off live tool motor is 3.3 kW (4.4 HP) with the S840Dsl or 3.7 kW (5 HP) with the M730.
Full Specifications
| Parameter | Value |
|---|---|
| Bar Capacity | 50.8 mm (2.0 in) |
| Spindle Center Height | 1,000 mm (40 in) |
| Collet Chuck Type | F58 (Ø51) |
| Spindle Nose | ISO A2-5 |
| Spindle Bore | 60 mm (2.4 in) spindle / 52 mm (2.0 in) draw tube |
| Spindle Motor Power | 20 kW (27 HP) with S840Dsl; 15 kW (20 HP) with M730 |
| Max Spindle Speed | 4,500 rpm |
| Compound Slide Travel | Z 115 mm (4.52 in) / X 70 mm (2.75 in) |
| Compound Slide Rapid Traverse | Z 25 m/min (984 ipm) / X 15 m/min (591 ipm) |
| Compound Slide Working Feed | 5 m/min (197 ipm) |
| Resolution | 0.001 mm (0.0001 in) |
| Turret Stations | 8 |
| Turret Tool Shank | VDI-30 x 55 / □20 mm / Ø25 mm |
| Main Turret X Travel | 160 mm (6.3 in) |
| Main Turret Z Travel Lnts T3 | 750 mm (29.53 in) (LNTS-T3 version) |
| Turning Tool Section | 20 mm (3/4 in) square |
| Turret Indexing Time | 0.28 sec / 180° - 0.6 sec |
| Second Turret Stations | 8 (Turret #2 / T2E Turret) |
| Third Turret Travel | Z 200 mm (7.9 in) / X 150 mm (5.9 in) |
| Pick Off Collet Chuck Type | TNS42 / TNS42E65 / HAINBUCH32 / 4 in chuck |
| Pick Off Max Chuck Capacity | Ø42 / Ø65 / Ø32 / Ø65 mm |
| Pick Off Live Tool Motor Power | 3.3 kW (4.4 HP) with S840Dsl; 3.7 kW (5 HP) with M730 |
| Pick Off Speed Max | 3,000 rpm |
| Back Machining Tool Section | 20 mm square |
| Back Machining Boring Bar Max | 25 mm (1.0 in) |
| Machine Dimensions | 2,804 x 1,848 x 1,935 mm (110 x 72 x 76 in) (L x W x H) |
| Machine Weight | 3,200 kg (7,040 lb) net; 4,000 kg (8,800 lb) gross |
| Hydraulic Tank Capacity | 30 L |
| Hydraulic Pump Motor | 0.75 kW (1.0 hp) |
| Coolant Tank Capacity | 200 L |
| Coolant Pump Motor | 1 kW (1.3 hp) |
| Lubrication | 2 L, 10 c.c. / 10 min |
| Power Requirement | 30 kVA |
Specifications sourced from licomachinery.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Spindle motor of 20 kW (27 HP) with the S840Dsl control, against 15 kW (20 HP) on the LNT-42S
- Takes 50.8 mm (2.0 in) bar through an F58 (Ø51) collet chuck on an ISO A2-5 spindle nose
- Same listed footprint as the smaller sizes: 2,804 x 1,848 x 1,935 mm (110 x 72 x 76 in)
- Pick-off device and back machining tool holders are on the standard equipment list
- Rapid traverse on the compound slide is 25 m/min (984 ipm) in Z
Limitations
- Maximum spindle speed drops to 4,500 rpm; the LNT-42S is listed at 5,000 rpm
- Pick-off chuck capacities are Ø42 / Ø65 / Ø32 / Ø65 mm, so the choice of pick-off chuck limits full-diameter parts
- Total power required is 30 kVA
- The compound slide stroke is unchanged from the smaller sizes at 70 mm (2.75 in) in X
Best For
Frequently Asked Questions
01
LICO lists a collet bar capacity of 50.8 mm (2.0 in) with an F58 (Ø51) collet chuck. The spindle through hole is 60 mm (2.4 in) and the draw tube through hole 52 mm (2.0 in).
02
The spindle motor is 20 kW (27 HP) with the S840Dsl control and 15 kW (20 HP) with the M730. Maximum spindle speed is 4,500 rpm and the spindle nose is ISO A2-5. Total power required is 30 kVA.
03
The table names TNS42, TNS42E65, HAINBUCH32 and a 4 in chuck, with maximum capacities of Ø42 / Ø65 / Ø32 / Ø65 mm in that order. The optional accessories list repeats TNS42E65, TNS42 and HAINBUCH 32 under the pick-off device, so confirm which chuck is included.
04
Not on paper. LICO prints one set of dimensions and one weight for the series, 3,200 kg (7,040 lb) net. The LNT-51S differs from the LNT-42S in bar capacity, spindle motor, spindle nose and connected load, where the LNT-42S needs 25 kVA.
