LICO LNT-42S
Image: licomachinery.com, LICO
Key Specifications
Max Spindle
Spindle Power
bar capacity
spindle center height
collet chuck type
spindle bore
How much does the LICO LNT-42S cost?
Price estimate
We do not have a price for the LICO LNT-42S that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
On the LICO LNT-42S, tooling is spread over several carriers instead of one large turret. It is a multi-slide CNC automatic for bar up to 42 mm (1.62 in), with a 5,000 rpm spindle, and it is the second of four sizes in the LNT S series.
Start with the main turret. It has 8 positions, accepts VDI-30 x 55 holders, and takes turning tools of 20 mm (3/4 in) square section. X travel is 160 mm (6.3 in). In the LNTS-T3 version the main turret slide has 750 mm (29.53 in) of Z travel. Indexing is quoted as 0.28 sec / 180° - 0.6 sec, and the standard equipment list describes the turret as servo driven, with driven tools.
Nearer the spindle sits the compound slide, the part of the machine that earns the name multi-slide. Its stroke is short, 115 mm (4.52 in) in Z and 70 mm (2.75 in) in X, and its working feed is 5 m/min (197 ipm). A stroke that short suits forming, grooving and cut-off tools, which leaves the longer cuts to the turret. LICO also tabulates a Turret #2 or T2E turret with 8 positions, both optional accessories, and a Turret #3 with 200 mm (7.9 in) of Z and 150 mm (5.9 in) of X.
Behind all this the spindle is the same unit the LNT-36S uses in terms of power: 15 kW (20 HP) with the S840Dsl control or 11 kW (15 HP) with the M730. The through hole grows to 53 mm (2.1 in) and the draw tube to 43 mm (1.7 in). How many of the optional carriers a job needs is worth settling before ordering, because the table does not say which fit together.
Full Specifications
| Parameter | Value |
|---|---|
| Bar Capacity | 42 mm (1.62 in) |
| Spindle Center Height | 1,000 mm (40 in) |
| Collet Chuck Type | F48 (Ø42) |
| Spindle Bore | 53 mm (2.1 in) spindle / 43 mm (1.7 in) draw tube |
| Spindle Motor Power | 15 kW (20 HP) with S840Dsl; 11 kW (15 HP) with M730 |
| Max Spindle Speed | 5,000 rpm |
| Compound Slide Travel | Z 115 mm (4.52 in) / X 70 mm (2.75 in) |
| Compound Slide Rapid Traverse | Z 25 m/min (984 ipm) / X 15 m/min (591 ipm) |
| Compound Slide Working Feed | 5 m/min (197 ipm) |
| Resolution | 0.001 mm (0.0001 in) |
| Turret Stations | 8 |
| Turret Tool Shank | VDI-30 x 55 / □20 mm / Ø25 mm |
| Main Turret X Travel | 160 mm (6.3 in) |
| Main Turret Z Travel Lnts T3 | 750 mm (29.53 in) (LNTS-T3 version) |
| Turning Tool Section | 20 mm (3/4 in) square |
| Turret Indexing Time | 0.28 sec / 180° - 0.6 sec |
| Second Turret Stations | 8 (Turret #2 / T2E Turret) |
| Third Turret Travel | Z 200 mm (7.9 in) / X 150 mm (5.9 in) |
| Pick Off Collet Chuck Type | TNS42 / TNS42E65 / HAINBUCH32 / 4 in chuck |
| Pick Off Max Chuck Capacity | Ø42 / Ø65 / Ø32 / Ø65 mm |
| Pick Off Live Tool Motor Power | 3.3 kW (4.4 HP) with S840Dsl; 3.7 kW (5 HP) with M730 |
| Pick Off Speed Max | 3,000 rpm |
| Back Machining Tool Section | 20 mm square |
| Back Machining Boring Bar Max | 25 mm (1.0 in) |
| Machine Dimensions | 2,804 x 1,848 x 1,935 mm (110 x 72 x 76 in) (L x W x H) |
| Machine Weight | 3,200 kg (7,040 lb) net; 4,000 kg (8,800 lb) gross |
| Hydraulic Tank Capacity | 30 L |
| Hydraulic Pump Motor | 0.75 kW (1.0 hp) |
| Coolant Tank Capacity | 200 L |
| Coolant Pump Motor | 1 kW (1.3 hp) |
| Lubrication | 2 L, 10 c.c. / 10 min |
| Power Requirement | 25 kVA |
Specifications sourced from licomachinery.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Main turret with 8 positions for VDI-30 x 55 holders, plus a separate compound slide for forming and cut-off tools
- A second 8-position turret (Turret #2 or T2E) can be added from the optional accessories list
- The LNTS-T3 version gives the main turret slide 750 mm (29.53 in) of Z travel
- Spindle power of 15 kW (20 HP) with the S840Dsl control at a 42 mm bar capacity
- Pick-off device with a back machining platform for up to 4 gang tool holders or up to 3 live tool units
Limitations
- Top speed is 5,000 rpm, where the LNT-36S reaches 6,000 rpm on the same spindle motor
- Turret #2 and the T2E turret are options, and air or hydraulic live tool units are also extra
- Compound slide working feed is 5 m/min (197 ipm) on a stroke of only 70 mm (2.75 in) in X
- Bar above 42 mm needs the LNT-51S, which LICO lists with a 50.8 mm (2.0 in) capacity
Best For
Frequently Asked Questions
01
The main turret has 8 positions. LICO's table also lists Turret #2 or a T2E turret with 8 positions, which are optional accessories, and the back machining platform takes up to 4 gang tool holders or up to 3 live tool units. The compound slide carries its own tools.
02
The tool shank row reads VDI-30 x 55 / □20 mm / Ø25 mm, and the turning tool section is 20 mm (3/4 in) square. Back machining tools are 20 mm square, with a maximum boring bar of 25 mm (1.0 in).
03
LICO's table gives two rows for the main turret slide, LNTS and LNTS-T3. For LNTS-T3 the Z travel is 750 mm (29.53 in) with 160 mm (6.3 in) of X. The page does not explain the versions further, so ask LICO which one a quotation covers.
04
A 5,000 rpm spindle with an F48 (Ø42) collet chuck. Motor power is 15 kW (20 HP) with the S840Dsl control or 11 kW (15 HP) with the M730. The spindle through hole is 53 mm (2.1 in) and the draw tube 43 mm (1.7 in).
