Huron DX 250-500 nvu
Key Specifications
Max Turn Length
Accuracy
Repeatability
swing over bed
standard turning diameter
max turning diameter
How much does the Huron DX 250-500 nvu cost?
Price estimate
We do not have a price for the Huron DX 250-500 nvu that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Huron DX 250-500 nvu is the largest lathe in the nvu group. It turns up to 490 mm (19.3 in) in diameter, has 250 mm of cross travel and a standard turning diameter of 300 mm, and keeps a 500 mm turning length.
Diameter is the point of this model. Against the DX 200-5B nvu, the maximum turning diameter goes from 365 mm to 490 mm and X travel from 200 mm to 250 mm, on the same 500 mm swing. Flanges, hubs, brake components and gear blanks that would foul the turret on the 200 size can be machined here.
The spindle is the A2-8 unit with a 90 mm bore and 75 mm of bar capacity, running 50-3,500 rpm. Fanuc power is 15/11 kW and Siemens power 14.4/11 kW. This is the one nvu model where the Fanuc package has the higher first figure.
In Huron's table the column for this machine is headed nuv, an evident misprint for nvu. It sits on the nvu page and shares that series' features: 30° slant saddle, rear chip disposal, a 90° tilting panel and an available electro-spindle. Weight is 4,000 kg (8,818 lb). The machine is 2,350 mm long and 1,750 mm wide. Tailstock thrust is 500 kgf, positioning 0.007 mm.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Bed | 500 mm (19.7 in) |
| Standard Turning Diameter | 300 mm (11.8 in) |
| Max Turning Diameter | 490 mm (19.3 in) |
| Max Turning Length | 500 mm (19.7 in) |
| X Axis Travel | 250 mm (9.8 in) |
| Z Axis Travel | 500 mm (19.7 in) |
| Rapid Traverse Xz | 24 m/min |
| Spindle Power Siemens | 14.4/11 kW (19.3/14.8 hp) |
| Spindle Power Fanuc | 15/11 kW (20.1/14.8 hp) |
| Spindle Speed Range | 50-3,500 rpm |
| Spindle Bore | 90 mm (3.5 in) |
| Spindle Nose | A2-8 |
| Bar Capacity | 75 mm (3.0 in) |
| Turret Stations | 8 |
| Max Boring Bar Diameter | 40 mm (1.6 in) |
| Tool Shank Size | 25 x 25 |
| Tailstock Quill Diameter | 85 mm (3.3 in) |
| Tailstock Quill Stroke | 120 mm (4.7 in) |
| Tailstock Thrust | 500 kgf |
| Positioning Accuracy | 0.007 mm (0.0003 in) |
| Repeatability | 0.005 mm (0.0002 in) |
| Machine Weight | 4,000 kg (8,818 lb) |
| Machine Length | 2,350 mm (92.5 in) |
| Machine Width | 1,750 mm (68.9 in) |
| Machine Height | 1,730 mm (68.1 in) |
Specifications sourced from huron.fr — verified 2026-10-04
Strengths & Limitations
Strengths
- 490 mm maximum turning diameter with 250 mm of X travel
- 75 mm bar capacity and an A2-8 spindle nose
- 15/11 kW with the Fanuc spindle motor
- Only 2,350 x 1,750 mm for a lathe of this diameter
- Tilting operator panel and rear-side chip disposal
Limitations
- Turning length is 500 mm, the same as on the 200 size
- Spindle limited to 3,500 rpm
- 8-station turret with boring bars up to 40 mm
- Swing over bed is 500 mm, no larger than on the 200 size
Best For
Frequently Asked Questions
01
Maximum turning diameter is 490 mm, standard turning diameter 300 mm and maximum turning length 500 mm. X travel is 250 mm and Z travel 500 mm.
02
Capacity, spindle and weight figures match the DX 250-500. The nvu version is slightly wider and taller, 1,750 mm and 1,730 mm against 1,600 mm and 1,660 mm for the DX 250-500, and its page lists rear chip disposal and a 90° tilting operator panel.
03
An A2-8 spindle with a 90 mm bore and 75 mm of bar capacity, running 50-3,500 rpm. Motor power is 14.4/11 kW with Siemens and 15/11 kW with Fanuc.
04
The tailstock has an 85 mm quill, 120 mm of stroke and 500 kgf of adjustable thrust. The turret is a bi-directional servo type with 8 stations and a quoted change time of 0.5 sec.
