Huron DX 200-4 B
Image: huron.fr, Huron
Key Specifications
Max Turn Length
Accuracy
Repeatability
swing over bed
standard turning diameter
max turning diameter
How much does the Huron DX 200-4 B cost?
Price estimate
We do not have a price for the Huron DX 200-4 B that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Combine 400 mm (15.7 in) of turning length with a 52 mm bar capacity and you get the Huron DX 200-4 B. It is a slant-bed CNC turning centre with an A2-6 spindle, a 70 mm bore and an 8-station servo turret.
Among the short DX 200 models this is the most versatile specification. The bore is big enough for common bar sizes, the Z travel covers parts well beyond cut-off length, and the 320 mm maximum turning diameter allows chuck work on blanks and castings. One machine can therefore alternate between bar jobs and chucking jobs without being the wrong size for either.
The Siemens spindle motor is listed at 13.5/9 kW and the Fanuc motor at 11/7.5 kW, both over a 50-4,000 rpm range. Cross travel is 175 mm and rapid feed 24 m/min. Tailstock thrust is adjustable to 300 kgf on an 85 mm quill.
Huron's feature list for the DX 200 series covers hydraulic chucking, an automatic and manual coolant system, centralised programmable lubrication and an air-conditioned electrical panel. Tool change is quoted at 0.5 sec. The DX 200-4 B weighs 3,100 kg (6,834 lb), the same as the shorter DX 200-3 B, and shares its 2,150 x 1,440 x 1,770 mm envelope. Positioning is 0.007 mm.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Bed | 500 mm (19.7 in) |
| Standard Turning Diameter | 250 mm (9.8 in) |
| Max Turning Diameter | 320 mm (12.6 in) |
| Max Turning Length | 400 mm (15.7 in) |
| X Axis Travel | 175 mm (6.9 in) |
| Z Axis Travel | 400 mm (15.7 in) |
| Rapid Traverse Xz | 24 m/min |
| Spindle Power Siemens | 13.5/9 kW (18.1/12.1 hp) |
| Spindle Power Fanuc | 11/7.5 kW (14.8/10.1 hp) |
| Spindle Speed Range | 50-4,000 rpm |
| Spindle Bore | 70 mm (2.8 in) |
| Spindle Nose | A2-6 |
| Bar Capacity | 52 mm (2.0 in) |
| Turret Stations | 8 |
| Max Boring Bar Diameter | 40 mm (1.6 in) |
| Tool Shank Size | 25 x 25 mm (1.0 x 1.0 in) |
| Tailstock Quill Diameter | 85 mm (3.3 in) |
| Tailstock Quill Stroke | 120 mm (4.7 in) |
| Tailstock Thrust | 300 kgf |
| Positioning Accuracy | 0.007 mm (0.0003 in) |
| Repeatability | 0.005 mm (0.0002 in) |
| Machine Weight | 3,100 kg (6,834 lb) |
| Machine Length | 2,150 mm (84.6 in) |
| Machine Width | 1,440 mm (56.7 in) |
| Machine Height | 1,770 mm (69.7 in) |
Specifications sourced from huron.fr — verified 2026-10-04
Strengths & Limitations
Strengths
- 52 mm bar capacity with 400 mm of Z travel
- 13.5/9 kW on the Siemens spindle motor
- Same footprint and 3,100 kg weight as the shorter DX 200-3 B
- A2-6 spindle nose and 70 mm spindle bore
- Hydraulic chucking and hydraulic tailstock quill listed by Huron
Limitations
- Maximum turning diameter is 320 mm; the DX 200-5 A reaches 365 mm
- Tailstock thrust is limited to 300 kgf
- Fanuc motor power is 11/7.5 kW
- Turret has 8 stations for 25 x 25 mm tools only
Best For
Frequently Asked Questions
01
Maximum bar capacity is 52 mm through a 70 mm spindle bore. Huron marks the bar capacity row with a note, so confirm it against the chuck and draw tube specified.
02
A2-6 nose, 50-4,000 rpm, with 13.5/9 kW for the Siemens motor and 11/7.5 kW for the Fanuc motor. Cross travel is 175 mm and rapid feed 24 m/min.
03
Maximum turning length and Z travel are both 400 mm. For longer work with the same spindle size, the DX 200-5 A offers 500 mm and the DX 200-7 A 700 mm.
04
About 2,150 mm long, 1,440 mm wide and 1,770 mm high, at about 3,100 kg (6,834 lb). Huron lists three-point levelling among the features.
