Huron AX MY 300
Image: huron.fr, Huron
Key Specifications
Max Spindle
Rapid Traverse
Spindle Power
Max Turn Length
Accuracy
Repeatability
How much does the Huron AX MY 300 cost?
Price estimate
We do not have a price for the Huron AX MY 300 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Huron AX MY 300 is the large-frame AX with Y-axis milling. It joins a 36 kW, 385 Nm turning spindle to a 12-station live turret that travels ± 50 mm in Y, and it keeps a tailstock for long work.
This is the version for parts that are heavy to turn and also carry real milling content. Capacity is 420 mm (16.5 in) in diameter and 600 mm in length over a 650 mm swing. Bar capacity is 65 mm through an A2-8 spindle with a 75 mm bore. On the tool side, BMT 55 holders give the driven tools a stiffer mounting than the BMT 45 of the 200 size, which helps when an end mill is cutting a slot in steel.
The Y stroke of ± 50 mm covers flats and keyways on most of the diameters the machine can turn. Driven tools reach 4,000 rpm, the same ceiling as the main spindle. X and Y traverse at 24 m/min and Z at 30 m/min.
Tailstock data are MT 4, 130 mm quill diameter, 620 mm travel and 500 daN thrust. Positioning is 0.005 mm and repeatability 0.003 mm on X and Z. Huron's feature list adds hydraulic chucking and a monoblock base. Width and depth with doors open and conveyor are 4,225 and 4,220 mm.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Bed | 650 mm (25.6 in) |
| Max Turning Diameter | 420 mm (16.5 in) |
| Max Turning Length | 600 mm (23.6 in) |
| X Axis Travel | 250 mm (9.8 in) |
| Z Axis Travel | 625 mm (24.6 in) |
| Y Axis Travel | ± 50 mm (± 2.0 in) |
| Rapid Traverse Rate | X-Y: 24 m/min; Z: 30 m/min |
| Max Spindle Speed | 4,000 rpm |
| Spindle Motor Power | 36 kW (48.3 hp) |
| Spindle Torque | 385 Nm (284.0 lb-ft) |
| Spindle Bore | 75 mm (3.0 in) |
| Spindle Nose | A2-8 |
| Bar Capacity | 65 mm (2.6 in) |
| Tailstock Taper | MT 4 |
| Tailstock Quill Diameter | 130 mm (5.1 in) |
| Tailstock Quill Travel | 620 mm (24.4 in) |
| Tailstock Thrust | 500 daN |
| Turret Type | Live tools |
| Turret Stations | 12 |
| Turret Tooling | BMT 55 |
| Live Tool Speed | 4,000 rpm |
| Positioning Accuracy | 0.005 mm (0.0002 in) |
| Repeatability | 0.003 mm (0.0001 in) |
| Machine Width | 4,225 mm (166.3 in) |
| Machine Depth | 4,220 mm (166.1 in) |
| Machine Height | 2,210 mm (87.0 in) |
Specifications sourced from huron.fr — verified 2026-10-04
Strengths & Limitations
Strengths
- 385 Nm turning spindle combined with a ± 50 mm Y axis
- BMT 55 driven-tool holders
- MT 4 tailstock with a 130 mm quill for heavy shafts
- 420 mm turning diameter and 65 mm bar capacity
- Positioning of 0.005 mm on X and Z
Limitations
- Driven tools are limited to 4,000 rpm
- No secondary spindle; the AX MSY 300 covers that
- Turning length is 600 mm, slightly less than on the 200 size
- Nearly square 4,225 x 4,220 mm footprint
Best For
Frequently Asked Questions
01
A turret travel of ± 50 mm perpendicular to X, so driven tools can machine off the spindle centreline. That allows straight-sided slots, true flats and off-axis holes without C-axis interpolation.
02
36 kW and 385 Nm at up to 4,000 rpm, on an A2-8 spindle nose with a 75 mm bore. Maximum bar capacity is 65 mm.
03
The AX MY 200 turns up to 330 mm with a 9.2 kW, 175 Nm spindle, BMT 45 tooling and ± 40 mm of Y. The AX MY 300 turns up to 420 mm with 36 kW and 385 Nm, BMT 55 tooling and ± 50 mm of Y.
04
The table for the AX MY 300 lists a tailstock with an MT 4 taper, a 130 mm quill, 620 mm of quill travel and 500 daN of thrust.
