HSG TS2-90
Key Specifications
laser power
round tube capacity
square tube capacity
tube length range
unloading length
acceleration
How much does the HSG TS2-90 cost?
Price estimate
We do not have a price for the HSG TS2-90 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
HSG builds the TS2-90 for bar stock that the standard TS2 cannot swallow. Its tube length range is 1,000-9,200 mm (39.4-362.2 in), and the unloading length grows with it to 4.5 m or 6.5 m (14.8 ft / 21.3 ft).
The unloading figure deserves as much attention as the loading one. A long bed is of little use if a long part has nowhere to land, and on this model the longer of the two unloading tables covers parts up to 6.5 m. The unloading side uses a follow-up flip board and two concave wheels that reposition for each part length, so long, thin sections are supported while they are cut free.
Nothing else in the column moves. Round tube is Φ12-Φ273 mm (0.5-10.7 in), square tube 12 × 12 to 220 × 220 mm, and laser power 3,000-6,000 W. Acceleration stays at 1.4 G with a 140 m/min maximum linkage speed.
One limit is easy to miss. The single-tube capacity is 300 kg (661 lb) whatever the length, so a 9,200 mm bar has to be light enough per metre to stay under it; heavy-wall sections at full length will not qualify. HSG's bundle loader is also specified for 3600-6500mm tube only, so full-length bars on this model are loaded by other means.
Full Specifications
| Parameter | Value |
|---|---|
| Laser Power | 3,000-6,000 W |
| Round Tube Capacity | Φ12-Φ273 mm (0.5-10.7 in) |
| Square Tube Capacity | 12 × 12 to 220 × 220 mm (0.5 × 0.5 to 8.7 × 8.7 in) |
| Tube Length Range | 1,000-9,200 mm (39.4-362.2 in) |
| Unloading Length | 4.5 m / 6.5 m (14.8 ft / 21.3 ft) |
| Acceleration | 1.4 G |
| Max Single Tube Weight | 300 kg (661 lb) |
| Max Linkage Speed | 140 m/min |
Specifications sourced from hsglaser.com — verified 2026-10-05
Strengths & Limitations
Strengths
- Takes tube from 1,000 to 9,200 mm (39.4-362.2 in) long
- Unloading length of 4.5 m or 6.5 m (14.8 ft / 21.3 ft) for long finished parts
- Same Φ12-Φ273 mm (0.5-10.7 in) round capacity and 1.4 G acceleration as the TS2
- Follow-up flip board and two follow-up concave wheels support the part during unloading
Limitations
- Single tube weight stays at 300 kg (661 lb) even at 9,200 mm, which rules out heavy-wall bars at full length
- HSG's bundle loader is specified for 3600-6500mm tube, shorter than this machine's maximum
- Square tube is limited to 220 × 220 mm (8.7 × 8.7 in)
- Laser power does not go beyond 6,000 W
Best For
Frequently Asked Questions
01
The range of tube length is 1,000-9,200 mm (39.4-362.2 in). The unloading length is 4.5 m or 6.5 m (14.8 ft / 21.3 ft), depending on the version ordered. The standard TS2 is listed with 1,000-6,500 mm and 3 m or 4.5 m.
02
The maximum loading capacity for a single tube is 300 kg (661 lb), the same as on the shorter TS2. Because the limit does not rise with length, check the weight of your heaviest full-length section before choosing this model.
03
Round tube from Φ12 to Φ273 mm (0.5-10.7 in) and square tube from 12 × 12 to 220 × 220 mm (8.7 × 8.7 in). Laser power is offered from 3,000 to 6,000 W, and HSG also names channel steel, angle steel and I-beams.
04
Not as HSG describes it. The brochure says the bundle loader supports automatic loading of tubes with a length of 3600-6500mm and a weight of up to 300kg. Ask HSG how longer bars are loaded on this model.
