HNK HKDB-150F(1.3Mx8M)
Key Specifications
Spindle Taper
Table Size
Spindle Power
max table load
x axis travel
y axis travel
How much does the HNK HKDB-150F(1.3Mx8M) cost?
Price estimate
We do not have a price for the HNK HKDB-150F(1.3Mx8M) that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The HNK HKDB-150F(1.3Mx8M) puts the heavy spindle on the fixed-table duplex machine. Two travelling columns each carry a Ø150 mm (5.9 in) spindle driven by a 37/45 kW (49.6/60.3 hp) motor, cont/30min, over a table of 1,300 x 8,000 mm (51.2 x 315.0 in).
It is the widest table in either HKDB series. The moving-table HKDB-150(1.2Mx8M), which has the same spindles and the same 8,000 mm (315.0 in) of travel, is narrower and carries half the load: 10,000 kg (22,046 lb) against the 20,000 kg (44,092 lb) of this machine. For heavy steel castings and thick fabrications the F version is the natural choice.
Oddly, the spindle gap is narrower here than on that moving-table sibling. The distance between spindle ends is 200 to 1,500 mm (7.9 to 59.1 in). So although the table is wider, the widest part that fits between the noses is slightly smaller, and a job near the limit should be checked against both models.
Z travel is 650 mm (25.6 in), with 700 mm (27.6 in) in square brackets, and Y travel 2,000 mm (78.7 in) with the spindle centre from 0 to 2,000 mm (0.0 to 78.7 in) above the table top. Speed range is 5 to 2,000 rpm on ISO No.50. Fanuc 31i-B and Siemens 840D are listed, and the columns can travel simultaneously or independently.
Full Specifications
| Parameter | Value |
|---|---|
| Table Size | 1,300 x 8,000 mm (51.2 x 315.0 in) |
| Max Table Load | 20,000 kg (44,092 lb) |
| X Axis Travel | 8,000 mm (315.0 in) |
| Y Axis Travel | 2,000 mm (78.7 in) |
| Z Axis Travel | 650 mm (25.6 in) [700 mm (27.6 in)] |
| Spindle Heads | 2 |
| Distance Between Spindle Ends | 200 ~ 1,500 mm (7.9 ~ 59.1 in) |
| Distance Table Top to Spindle Center | 0 ~ 2,000 mm (0.0 ~ 78.7 in) |
| Spindle Taper | ISO No.50 |
| Spindle Diameter | Ø150 mm (5.9 in) |
| Spindle Motor Power | 37/45 kW (49.6/60.3 hp) (cont/30min) |
| Spindle Speed Range | 5 ~ 2,000 rpm |
| CNC Control | Fanuc 31i-B, Siemens 840D |
Specifications sourced from en.hnkkorea.com — verified 2026-10-04
Strengths & Limitations
Strengths
- Two Ø150 mm (5.9 in) spindles with 37/45 kW (49.6/60.3 hp) each
- 1,300 mm (51.2 in) wide fixed table rated for 20,000 kg (44,092 lb)
- Z travel of 650 mm (25.6 in), or 700 mm (27.6 in) in square brackets
- 8,000 mm (315.0 in) of column travel
Limitations
- Spindle gap tops out at 1,500 mm (59.1 in), less than the 1,600 mm (63.0 in) of the HKDB-150(1.2Mx8M)
- Speed range ends at 2,000 rpm
- Two moving columns each need their own chip and cable management
Best For
Frequently Asked Questions
01
Same spindles and X travel. The HKDB-150F(1.3Mx8M) has a fixed 1,300 mm (51.2 in) wide table for 20,000 kg (44,092 lb) and moving columns; the HKDB-150(1.2Mx8M) has a moving 1,200 mm (47.2 in) wide table for 10,000 kg (22,046 lb) and a spindle gap up to 1,600 mm (63.0 in).
02
37/45 kW (49.6/60.3 hp) per head on a cont/30min basis, two heads in all. Spindle diameter is Ø150 mm (5.9 in), taper ISO No.50 and speed 5 to 2,000 rpm.
03
X 8,000 mm (315.0 in), Y 2,000 mm (78.7 in), and Z 650 mm (25.6 in) per head with 700 mm (27.6 in) in square brackets. The spindle ends can be set 200 to 1,500 mm (7.9 to 59.1 in) apart.
04
Yes. The HKDB-150F(1.3Mx16M) has the same columns and spindles on a 1,300 x 16,000 mm (51.2 x 629.9 in) table with 16,000 mm (629.9 in) of X travel.
