Han's Laser G12025HF
Key Specifications
Accuracy
Repeatability
cutting area
x axis travel
y axis travel
z axis travel
How much does the Han's Laser G12025HF cost?
Price estimate
We do not have a price for the Han's Laser G12025HF that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Han's Laser G12025HF is the largest machine in the HF Expert table, a fiber laser cutting machine with a 12,000 × 2,500 mm (472.4 × 98.4 in) processing area. It is built for plate that does not fit a standard bed: long structural parts, wide sheets, or several ordinary sheets laid end to end and cut in one program.
Everything scales with the bed. The worktable takes 14,100 kg (31,085 lb). Z-axis travel is 400 mm (15.7 in), the tallest in the series. X travels 12,100 mm (476.4 in) and Y 2,600 mm (102.4 in), which leaves working margin beyond the nominal sheet on both axes.
A gantry this wide cannot move like a small one, and the table says so plainly. Maximum positioning speed is 140 m/min with 2.2 G of acceleration. Repositioning accuracy is ±0.03 mm where the G6020HF holds ±0.02 mm; positioning accuracy is the same ±0.03 mm/m, a per-metre figure, so the absolute error allowed over a 12 m part is larger than over a short one. For structural work that is normal. For long precision parts it should be discussed with the maker.
The building has to be planned around the machine. Overall dimensions are 2,840 × 423 × 261 cm (1,118.1 × 166.5 × 102.8 in), and loading a 12 m plate needs crane coverage along the full length. The control is Han's 901, and the series description lists support for 30kW cutting.
Full Specifications
| Parameter | Value |
|---|---|
| Cutting Area | 12,000 × 2,500 mm (472.4 × 98.4 in) |
| X Axis Travel | 12,100 mm (476.4 in) |
| Y Axis Travel | 2,600 mm (102.4 in) |
| Z Axis Travel | 400 mm (15.7 in) |
| Positioning Accuracy | ±0.03 mm/m |
| Repeatability | ±0.03 mm |
| Max Positioning Speed Xy | 140 m/min |
| Max Acceleration Xy | 2.2 G |
| CNC Control | Han's 901 |
| Max Table Load | 14,100 kg (31,085 lb) |
| Machine Dimensions | 2,840 × 423 × 261 cm (1,118.1 × 166.5 × 102.8 in) |
Specifications sourced from hanslaser.net — verified 2026-10-05
Strengths & Limitations
Strengths
- 12,000 × 2,500 mm (472.4 × 98.4 in) processing area
- Worktable load capacity of 14,100 kg (31,085 lb)
- 400 mm (15.7 in) Z-axis travel, the largest in the HF Expert series
- Y travel of 2,600 mm (102.4 in) gives margin on 2,500 mm wide plate
Limitations
- Lowest dynamics in the series: 140 m/min and 2.2 G
- Repositioning accuracy of ±0.03 mm, against ±0.02 mm on the G6020HF and smaller models
- Overall length of 2,840 cm demands a dedicated bay with crane coverage
- No machine weight or laser power is given in the table
Best For
Frequently Asked Questions
01
The processing area is 12,000 × 2,500 mm (472.4 × 98.4 in). Axis travel is 12,100 mm (476.4 in) in X, 2,600 mm (102.4 in) in Y and 400 mm (15.7 in) in Z, and the worktable is rated for 14,100 kg (31,085 lb).
02
X and Y positioning accuracy is ±0.03 mm/m and repositioning accuracy ±0.03 mm. The positioning figure is stated per metre, so check with Han's Laser what tolerance is guaranteed over the full 12,100 mm (476.4 in) of X travel.
03
The G6020HF has a 6,000 × 2,000 mm (236.2 × 78.7 in) area, a 5,600 kg (12,346 lb) table and positions at 160 m/min with 2.5 G. The G12025HF doubles the length, is wider, carries 14,100 kg (31,085 lb) and is listed at 140 m/min and 2.2 G.
04
Overall dimensions are 2,840 × 423 × 261 cm (1,118.1 × 166.5 × 102.8 in) as length, width and height. The laser source, cooling and extraction are in addition, and a plate of this length needs lifting equipment along the whole bed.
