Amada ACIES-2515 AJ

Est. $450,000 - $650,000 Updated 2026-10-03

Key Specifications

Accuracy

±0.03 mm (±0.0012 in)

Repeatability

±0.02 mm (±0.0008 in)

work area

2,500 x 1,250 mm (98.4 x 49.2 in)

laser type

Fiber laser

laser power

4,000 W

max cutting thickness mild steel

19 mm (0.75 in)

How much does the Amada ACIES-2515 AJ cost?

Estimated price range

Est.$450,000 - $650,000

Our best estimate for a cnc laser cutting machine in this class — not a quote from Amada. Configuration moves it a long way.

Overview

The Amada ACIES-2515 AJ is a fiber laser machine with a 2,500 x 1,250 mm (98.4 x 49.2 in) work area and a 4,000 W source, going by the listed figures. Amada's current product pages do not show this model, so read what follows as a description of an older machine whose table has not been checked against the maker.

On the listed figures, maximum cutting thickness is 19 mm (0.75 in) in mild steel, 12 mm (0.47 in) in stainless and 8 mm (0.31 in) in aluminum. Those are ceilings, and day-to-day production normally sits below them. The work area matches a 2,500 x 1,250 mm sheet with nothing to spare, so larger formats are out.

Motion is listed as a maximum axis speed of 140 m/min and 1.2 G of acceleration, with positioning accuracy of ±0.03 mm (±0.0012 in) and repeatability of ±0.02 mm (±0.0008 in). The automatic job change row covers nozzle, focus and parameter changes, which removes operator steps between jobs of different material or thickness. The control is listed as Amada AMNC 3i with the Amada V-factory IoT platform, and the machine weight as 9,500 kg (20,944 lb). Anyone looking at a second-hand machine should check each of these against its own nameplate and documents.

Full Specifications

Parameter	Value
Work Area	2,500 x 1,250 mm (98.4 x 49.2 in)
Laser Type	Fiber laser
Laser Power	4,000 W
Max Cutting Thickness Mild Steel	19 mm (0.75 in)
Max Cutting Thickness Stainless	12 mm (0.47 in)
Max Cutting Thickness Aluminum	8 mm (0.31 in)
Positioning Accuracy	±0.03 mm (±0.0012 in)
Repeatability	±0.02 mm (±0.0008 in)
Max Axis Speed	140 m/min
Acceleration	1.2 G
Automatic Job Change	Yes (AJ — nozzle, focus, parameter auto-change)
CNC Control	Amada AMNC 3i
Iot Connectivity	Amada V-factory IoT platform
Machine Weight	9,500 kg (20,944 lb)

Specifications compiled from manufacturer literature and industry references. Not independently verified against a published spec sheet — confirm with the manufacturer or an authorised dealer before making a purchasing decision.

Strengths & Limitations

Strengths

4,000 W fiber laser with a listed 19 mm (0.75 in) maximum in mild steel
Listed maximum axis speed of 140 m/min with 1.2 G acceleration
Automatic job change row covers nozzle, focus and parameter changes
Listed positioning accuracy of ±0.03 mm (±0.0012 in) and repeatability of ±0.02 mm (±0.0008 in)

Limitations

Not on Amada's current product pages, and the listed figures are unconfirmed
Work area of 2,500 x 1,250 mm (98.4 x 49.2 in) excludes larger sheet formats
Listed maximum is 8 mm (0.31 in) in aluminum and 12 mm (0.47 in) in stainless

Best For

Sheet up to 2,500 x 1,250 mm (98.4 x 49.2 in) Mild steel up to the listed 19 mm (0.75 in) Mixed jobs that benefit from automatic nozzle and focus changes

Frequently Asked Questions

01 Is the ACIES-2515 AJ still on Amada's current product pages?

No. The model does not appear on Amada's current pages, so it should be treated as an older machine. The figures here are the listed figures and have not been checked against the maker, which makes the machine's own nameplate and manual the reference for any purchase.

02 How thick can the ACIES-2515 AJ cut?

The listed figures give a maximum cutting thickness of 19 mm (0.75 in) in mild steel, 12 mm (0.47 in) in stainless and 8 mm (0.31 in) in aluminum, from a 4,000 W fiber laser. These are upper limits; the condition of a particular machine and its optics decide what it does today.

03 What sheet size does the ACIES-2515 AJ take?

The listed work area is 2,500 x 1,250 mm (98.4 x 49.2 in). A sheet of that size fills the area completely, so anything longer or wider will not fit without repositioning.

04 How fast and how accurate is the ACIES-2515 AJ?

The listed figures are a maximum axis speed of 140 m/min and an acceleration of 1.2 G. Positioning accuracy is given as ±0.03 mm (±0.0012 in) and repeatability as ±0.02 mm (±0.0008 in). On an older machine these are worth verifying with a test cut.
