Ermak Power-Bend Falcon 4270-220
Image: ermaksan.com.tr, Ermak
Key Specifications
bending length
bending power
distance between columns
y rapid speed
y working speed
y return speed
How much does the Ermak Power-Bend Falcon 4270-220 cost?
Price estimate
We do not have a price for the Ermak Power-Bend Falcon 4270-220 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Ermak's 220 Ton (243 US tons) frame on the 14 ft bed gives the Ermak Power-Bend Falcon 4270-220: 4,270 mm (168.1 in) of bending length, a 160 mm table and a weight of 14,000 kg.
Most of what a buyer needs to know sits in three comparisons. Against lighter 14 ft Falcons the table is wider, 160 mm, and the tank larger at 300 L. Against the Power-Bend Falcon 4100-220 the passage between the columns is 3,780 mm where the shorter machine has 3,600 mm. And against the Power-Bend Falcon 4270-260 this model is the faster one, approaching at 180 mm/s where the heavier machine does 140 mm/s.
Return speed is 160 mm/s and bending speed 10 mm/s. The motor is 18.5 kW.
The frame is 3,000 mm high, a clear jump from the lighter versions of this bed, and 6,270 mm long by 2,250 mm wide. Check the route into the building.
Stroke is 275 mm, daylight 550 mm and throat depth 410 mm. With the table at 900 mm, plate up to moderate thickness can still be loaded by hand with two people, though the sheet supports number only 2. The backgauge gives 800 mm of X and 250 mm of R.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Length | 4,270 mm (168.1 in) |
| Bending Power | 220 Ton (243 US tons) |
| Distance Between Columns | 3,780 mm (148.8 in) |
| Y Rapid Speed | 180 mm/s (7.09 in/s) |
| Y Working Speed | 10 mm/s (0.39 in/s) |
| Y Return Speed | 160 mm/s (6.3 in/s) |
| Crowning | Motorized |
| X Axis Travel | 800 mm (31.5 in) |
| X Axis Speed | 500 mm/s (19.69 in/s) |
| R Axis Travel | 250 mm (9.8 in) |
| R Axis Speed | 350 mm/s (13.78 in/s) |
| Backgauge Finger Blocks | 2 |
| Sheet Supports | 2 |
| Oil Capacity | 300 L (79.3 US gal) |
| Motor Power | 18.5 kW (24.8 hp) |
| Stroke | 275 mm (10.8 in) |
| Daylight | 550 mm (21.7 in) |
| Throat Depth | 410 mm (16.1 in) |
| Table Height | 900 mm (35.4 in) |
| Table Width | 160 mm (6.3 in) |
| Length | 6,270 mm (246.9 in) |
| Height | 3,000 mm (118.1 in) |
| Width | 2,250 mm (88.6 in) |
| Machine Weight | 14,000 kg (30,864 lb) |
Specifications sourced from ermaksan.com.tr — verified 2026-10-05
Strengths & Limitations
Strengths
- 180 mm/s approach and 160 mm/s return on a 14 ft machine
- 220 Ton with a 160 mm table
- 3,780 mm between the columns
- 18.5 kW motor and 300 L tank
Limitations
- 3,000 mm overall height to get through the door
- 14,000 kg installed weight on the slab
- 275 mm stroke limits deep parts
- Only 2 sheet supports on a 4,270 mm bed
Best For
Frequently Asked Questions
01
The ram approaches at 180 mm/s, bends at 10 mm/s and returns at 160 mm/s. That is the quickest return listed for a 4,270 mm Falcon.
02
14,000 kg and 3,000 mm. Length is 6,270 mm and width 2,250 mm. The height in particular should be checked against doors and crane hooks.
03
The Power-Bend Falcon 4100-220 bends 4,100 mm, weighs 13,600 kg and is 2,770 mm high. This model bends 4,270 mm, weighs 14,000 kg and stands 3,000 mm.
04
The motorized X and R gauge of the series, with 800 mm and 250 mm of travel and 2 finger blocks. The X5 finger group with 5 servo motors is an option.
