Ermak Power-Bend Falcon 6100-320
Image: ermaksan.com.tr, Ermak
Key Specifications
bending length
bending power
distance between columns
y rapid speed
y working speed
y return speed
How much does the Ermak Power-Bend Falcon 6100-320 cost?
Price estimate
We do not have a price for the Ermak Power-Bend Falcon 6100-320 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Ermak Power-Bend Falcon 6100-320 is a 6,100 mm (240.2 in) press brake rated at 320 Ton (353 US tons), and it is the slowest-approaching size but one in the Falcon table: 80 mm/s down and 75 mm/s back.
Those speeds are a consequence of scale. A ram of this length is a large mass with a 375 mm stroke to cover, and Ermak moves it with the 30 kW motor and 400 L system it also uses on much shorter 320 Ton machines. Bending speed is 10 mm/s. On six-metre parts, loading and unloading outlast the stroke anyway.
Daylight is 650 mm and throat depth 410 mm. The table, 180 mm wide, is 1,100 mm above the floor. The machine weighs 30,400 kg and measures 8,150 mm in length, 2,600 mm in width and 3,565 mm in height. Few workshops have a door for that; delivery in sections or through the roof is a question to raise with Ermak early.
Parts up to 5,100 mm (200.8 in) wide pass between the columns. Four finger blocks on the backgauge and four sheet supports at the front are standard, and the X and R axes travel 800 mm and 250 mm.
Motorized crowning is listed. On a bed this long the optional hydraulic crowning, with several cylinders in a special lower beam, is worth a quotation.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Length | 6,100 mm (240.2 in) |
| Bending Power | 320 Ton (353 US tons) |
| Distance Between Columns | 5,100 mm (200.8 in) |
| Y Rapid Speed | 80 mm/s (3.15 in/s) |
| Y Working Speed | 10 mm/s (0.39 in/s) |
| Y Return Speed | 75 mm/s (2.95 in/s) |
| Crowning | Motorized |
| X Axis Travel | 800 mm (31.5 in) |
| X Axis Speed | 500 mm/s (19.69 in/s) |
| R Axis Travel | 250 mm (9.8 in) |
| R Axis Speed | 350 mm/s (13.78 in/s) |
| Backgauge Finger Blocks | 4 |
| Sheet Supports | 4 |
| Oil Capacity | 400 L (105.7 US gal) |
| Motor Power | 30 kW (40.2 hp) |
| Stroke | 375 mm (14.8 in) |
| Daylight | 650 mm (25.6 in) |
| Throat Depth | 410 mm (16.1 in) |
| Table Height | 1,100 mm (43.3 in) |
| Table Width | 180 mm (7.1 in) |
| Length | 8,150 mm (320.9 in) |
| Height | 3,565 mm (140.4 in) |
| Width | 2,600 mm (102.4 in) |
| Machine Weight | 30,400 kg (67,019 lb) |
Specifications sourced from ermaksan.com.tr — verified 2026-10-05
Strengths & Limitations
Strengths
- 320 Ton along a 6,100 mm bed
- 375 mm stroke and 650 mm of daylight
- 4 sheet supports and 4 backgauge finger blocks
- 5,100 mm passage between the columns
Limitations
- 80 mm/s approach and 75 mm/s return
- 30,400 kg, 8,150 mm long, 3,565 mm high
- 1,100 mm table height to lift long parts to
- Table width of 180 mm, narrower than on shorter Falcons of equal force
Best For
Frequently Asked Questions
01
Ermak lists 80 mm/s for the approach and 75 mm/s for the return, with a 30 kW motor moving a six-metre ram through a 375 mm stroke. The working speed is 10 mm/s.
02
The table gives 30,400 kg, 8,150 mm of length and 3,565 mm of height. Transport, door size and crane capacity have to be agreed with Ermak before ordering; the page does not describe the delivery method.
03
The Power-Bend Falcon 6100-220 has a 275 mm stroke, 550 mm of daylight, an 18.5 kW motor and weighs 24,828 kg. This model has 375 mm, 650 mm, 30 kW and 30,400 kg.
04
Four sheet supports at the front are standard on this size. Pneumatic rear supports and a sheet extraction system for removing bent parts are listed as options.
