Ermak Power-Bend Falcon 4100-135
Image: ermaksan.com.tr, Ermak
Key Specifications
bending length
bending power
distance between columns
y rapid speed
y working speed
y return speed
How much does the Ermak Power-Bend Falcon 4100-135 cost?
Price estimate
We do not have a price for the Ermak Power-Bend Falcon 4100-135 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Four-metre sheet in thin gauges is the brief for the Ermak Power-Bend Falcon 4100-135: a bending length of 4,100 mm (161.4 in) backed by 135 Ton (149 US tons).
The ratio of force to length is low, and that is deliberate. Roofing profiles, lift cabin panels and long covers need reach, not tonnage, and paying for a heavier frame would bring nothing. This machine weighs 10,200 kg and runs on an 11 kW motor with 200 L of oil.
Its columns are 3,600 mm (141.7 in) apart. That leaves room for wide panels to pass through the frame and rest on the backgauge side, which helps when a long part has flanges on all four edges.
Ram speeds: 200 mm/s rapid, 10 mm/s working, 120 mm/s return. Backgauge: 800 mm in X at 500 mm/s and 250 mm in R at 350 mm/s. The stroke of 275 mm sits inside 550 mm of daylight, and the throat is 410 mm deep.
On the floor the machine takes 6,000 mm by 2,160 mm and rises to 2,660 mm. Ermak lists motorized crowning for this size. The table is 90 mm wide, in keeping with the narrow dies used on thin sheet, and 900 mm high.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Length | 4,100 mm (161.4 in) |
| Bending Power | 135 Ton (149 US tons) |
| Distance Between Columns | 3,600 mm (141.7 in) |
| Y Rapid Speed | 200 mm/s (7.87 in/s) |
| Y Working Speed | 10 mm/s (0.39 in/s) |
| Y Return Speed | 120 mm/s (4.72 in/s) |
| Crowning | Motorized |
| X Axis Travel | 800 mm (31.5 in) |
| X Axis Speed | 500 mm/s (19.69 in/s) |
| R Axis Travel | 250 mm (9.8 in) |
| R Axis Speed | 350 mm/s (13.78 in/s) |
| Backgauge Finger Blocks | 2 |
| Sheet Supports | 2 |
| Oil Capacity | 200 L (52.8 US gal) |
| Motor Power | 11 kW (14.8 hp) |
| Stroke | 275 mm (10.8 in) |
| Daylight | 550 mm (21.7 in) |
| Throat Depth | 410 mm (16.1 in) |
| Table Height | 900 mm (35.4 in) |
| Table Width | 90 mm (3.5 in) |
| Length | 6,000 mm (236.2 in) |
| Height | 2,660 mm (104.7 in) |
| Width | 2,160 mm (85 in) |
| Machine Weight | 10,200 kg (22,487 lb) |
Specifications sourced from ermaksan.com.tr — verified 2026-10-05
Strengths & Limitations
Strengths
- 4,100 mm bending length at 10,200 kg
- 200 mm/s rapid approach on a four-metre machine
- 3,600 mm between the columns for wide panels
- 11 kW motor and 200 L of oil
Limitations
- 135 Ton is light for 4,100 mm: thin gauges only at full length
- Return speed of 120 mm/s on the ram
- Two finger blocks across a four-metre bed
- 6,000 mm of floor length before handling space
Best For
Frequently Asked Questions
01
Long, thin parts. It bends up to 4,100 mm with 135 Ton, and wide panels up to 3,600 mm can pass between its columns. The table is 90 mm wide for narrow dies.
02
The frame is 6,000 mm long, 2,160 mm wide and 2,660 mm high. Add working room in front for four-metre blanks and behind for the backgauge, whose X axis travels 800 mm.
03
Ermak's table continues with the Power-Bend Falcon 4100-220, at 13,600 kg with an 18.5 kW motor and a 160 mm table.
04
Often. The standard machine has 2 sheet supports. Ermak offers pneumatic rear supports as an option, described as additional support latches for easier and more accurate bending.
