Ermak Power-Bend Falcon 6100-400
Image: ermaksan.com.tr, Ermak
Key Specifications
bending length
bending power
distance between columns
y rapid speed
y working speed
y return speed
How much does the Ermak Power-Bend Falcon 6100-400 cost?
Price estimate
We do not have a price for the Ermak Power-Bend Falcon 6100-400 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Nothing in the Falcon table is larger than the Ermak Power-Bend Falcon 6100-400. It bends 6,100 mm (240.2 in) with 400 Ton (441 US tons) and weighs 36,000 kg.
The figures at the extreme end of the table all belong to it. Return speed is 65 mm/s, the lowest listed. Overall height is 3,750 mm, the greatest. Working speed is 8.4 mm/s and approach 80 mm/s.
Its throat is 510 mm deep, which the Power-Bend Falcon 6100-320 does not offer as standard; that model has 410 mm. The table is 200 mm wide and 1,100 mm high. Stroke and daylight are 375 mm and 650 mm. For all its size the hydraulic unit is the familiar one, a 30 kW motor with 400 L of oil.
The columns stand 5,100 mm (200.8 in) apart. The machine is 8,150 mm long and 2,700 mm wide. A press brake of 36,000 kg is a civil engineering matter as much as a machine purchase: pit or foundation, crane, and the route for six-metre plate all come first.
Equipment matches the other six-metre Falcons, with 4 finger blocks, 4 sheet supports, 800 mm of X travel and 250 mm of R travel. Crowning is motorized as listed, and Y1 and Y2 are synchronised by linear rulers.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Length | 6,100 mm (240.2 in) |
| Bending Power | 400 Ton (441 US tons) |
| Distance Between Columns | 5,100 mm (200.8 in) |
| Y Rapid Speed | 80 mm/s (3.15 in/s) |
| Y Working Speed | 8.4 mm/s (0.33 in/s) |
| Y Return Speed | 65 mm/s (2.56 in/s) |
| Crowning | Motorized |
| X Axis Travel | 800 mm (31.5 in) |
| X Axis Speed | 500 mm/s (19.69 in/s) |
| R Axis Travel | 250 mm (9.8 in) |
| R Axis Speed | 350 mm/s (13.78 in/s) |
| Backgauge Finger Blocks | 4 |
| Sheet Supports | 4 |
| Oil Capacity | 400 L (105.7 US gal) |
| Motor Power | 30 kW (40.2 hp) |
| Stroke | 375 mm (14.8 in) |
| Daylight | 650 mm (25.6 in) |
| Throat Depth | 510 mm (20.1 in) |
| Table Height | 1,100 mm (43.3 in) |
| Table Width | 200 mm (7.9 in) |
| Length | 8,150 mm (320.9 in) |
| Height | 3,750 mm (147.6 in) |
| Width | 2,700 mm (106.3 in) |
| Machine Weight | 36,000 kg (79,365 lb) |
Specifications sourced from ermaksan.com.tr — verified 2026-10-05
Strengths & Limitations
Strengths
- The largest Falcon: 400 Ton over 6,100 mm
- 510 mm throat depth as standard
- 375 mm stroke, 650 mm daylight, 200 mm table
- 30 kW motor and 400 L tank, as on smaller heavy Falcons
Limitations
- 65 mm/s return, 80 mm/s approach, 8.4 mm/s working speed
- 36,000 kg needs engineered foundations
- 3,750 mm high and 8,150 mm long
- Table height 1,100 mm for six-metre plate
Best For
Frequently Asked Questions
01
It is 8,150 mm long, 2,700 mm wide and 3,750 mm high, and weighs 36,000 kg. Bending length is 6,100 mm, with 5,100 mm between the columns.
02
Y rapid speed is 80 mm/s, working speed 8.4 mm/s and return speed 65 mm/s. The backgauge is as quick as on small Falcons: 500 mm/s in X and 350 mm/s in R.
03
A 510 mm throat lets parts longer than the 5,100 mm column spacing sit deeper in the machine. Ermak also offers special throat depths up to 1,500 mm as an option.
04
Motorized crowning is listed for this size. Ermak additionally offers CNC-controlled hydraulic crowning with multiple hydraulic cylinders acting on a special lower beam, as an option.
