Ermak ETP-S 1500x2500 (30 ton)
Image: ermaksan.com.tr, Ermak
Key Specifications
Accuracy
Repeatability
punching force
max sheet size
turret stations
max punch diameter
How much does the Ermak ETP-S 1500x2500 (30 ton) cost?
Price estimate
We do not have a price for the Ermak ETP-S 1500x2500 (30 ton) that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Ermak prints two machines under the name ETP-S 1500x2500, and this page covers the 30 Ton one. It is a servo-electric turret punch press for sheets up to 2,500 x 1,500 mm (98.4 x 59.1 in), with a 33-station turret.
Compared with the three-metre ETP-S 1500x3000, the shorter X axis saves a good deal of floor: width drops from 6,660 mm on that model to 5,000 mm here, and weight to 18,500 kg (40,785 lb). The press itself is the same class, a 30 Ton servo mechanical unit on a 60 kW (80.5 hp) supply.
Two figures are lower than on the larger table. The marking rate is 1,200 strokes/min, and the sheet clamps number 3. Maximum sheet weight is 200 kg (441 lb). Stepping rates are unchanged at 900 strokes/min for a 1 mm step and 600 strokes/min for a 25 mm step.
Sheets longer than 2,500 mm are not excluded. The X travel is given as 2,500 mm + R, the R standing for repositioning with the automatic clamps.
Positioning accuracy is ±0.1 mm with ±0.05 mm repeatability, and the auto-index stations position to 0.01°. A multi-tool is changed in 3 s.
Full Specifications
| Parameter | Value |
|---|---|
| Punching Force | 30 Ton (33 US tons) |
| Max Sheet Size | 2,500 x 1,500 mm (98.4 x 59.1 in) |
| Turret Stations | 33 |
| Max Punch Diameter | 88.9 mm (3.5 in), single tool in 1 mm sheet |
| X Axis Travel | 2,500 mm (98.4 in) + R |
| X Axis Speed | 80 m/min |
| Y Axis Speed | 80 m/min |
| Xy Combined Speed | 114 m/min |
| Turret Rotation Speed | 20 rpm |
| Auto Index Rotation Speed | 65 rpm |
| Punch Rate Marking | 1,200 strokes/min (1 mm stroke) |
| Punch Rate 1 Mm Step | 900 strokes/min (1 mm step in X and Y) |
| Punch Rate 25 Mm Step | 600 strokes/min (25 mm step in X and Y) |
| Max Thickness Fixed Station Mild Steel | 6.35 mm (0.25 in) |
| Max Thickness Fixed Station Stainless Steel | 3 mm (0.12 in) |
| Max Thickness Auto Index Station Mild Steel | 4 mm (0.16 in) |
| Max Thickness Auto Index Station Stainless Steel | 2.5 mm (0.10 in) |
| Repeatability | ±0.05 mm |
| Positioning Accuracy | ±0.1 mm |
| Index Positioning Accuracy | 0.01° |
| Multi Tool Change Time | 3 s |
| Max Sheet Weight | 200 kg (441 lb) |
| Air Pressure | 6 - 7 bar |
| Ram Stroke | 32 mm (1.26 in) |
| Sheet Clamps | 3 |
| Sheet Clamping Force | 1,200 kg (2,646 lb) |
| Power Supply | 60 kW (80.5 hp) |
| Air Supply | 2.5 L/min |
| CNC Control | GE Fanuc 31i-PB with Ermaksan HMI software |
| Press Drive | Servo mechanical press, 30 TN |
| Working Height | 950 mm (37.4 in) |
| Table Type | Brush, ball or brush + ball |
| Machine Length | 5,520 mm (217.3 in) |
| Machine Width | 5,000 mm (196.9 in) |
| Machine Height | 2,220 mm (87.4 in) |
| Machine Weight | 18,500 kg (40,785 lb) |
| CAD CAM Software | Metalix |
Specifications sourced from ermaksan.com.tr — verified 2026-10-05
Strengths & Limitations
Strengths
- 30 Ton on a 2,500 x 1,500 mm table
- 33 stations, the larger of Ermak's two turret layouts
- 5,000 mm wide instead of the 6,660 mm of the ETP-S 1500x3000
- Servo mechanical press with a programmable stroke
- Repeatability of ±0.05 mm
Limitations
- Marking rate of 1,200 strokes/min, against 2,000 on the ETP-S 1500x3000
- Three-metre sheets need a reposition
- 60 kW (80.5 hp) power supply for a mid-size table
Best For
Frequently Asked Questions
01
The maker's table has two columns with that name. One is a 30 Ton press on a 60 kW supply (this page); the other is a 20 Ton press with a smaller supply. Both have 33 stations and the same sheet size.
02
2,500 x 1,500 mm (98.4 x 59.1 in), with a maximum sheet weight of 200 kg (441 lb). X travel is 2,500 mm plus repositioning, and 3 clamps hold the sheet with 1,200 kg of force.
03
X and Y each move at 80 m/min, 114 m/min combined. The turret rotates at 20 rpm and the auto-index stations at 65 rpm.
04
5,520 mm long, 5,000 mm wide and 2,220 mm high, with a working height of 950 mm. It weighs 18,500 kg (40,785 lb).
