Ermak ETP-S 1500x2000
Image: ermaksan.com.tr, Ermak
Key Specifications
Accuracy
Repeatability
punching force
max sheet size
turret stations
max punch diameter
How much does the Ermak ETP-S 1500x2000 cost?
Price estimate
We do not have a price for the Ermak ETP-S 1500x2000 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Ermak ETP-S 1500x2000 is the compact, fast model among Ermak's servo-electric turret punch presses. Sheet capacity is 2,000 x 1,500 mm (78.7 x 59.1 in), the press is rated at 20 Ton and the turret has 27 stations.
Speed sets it apart from the rest of the ETP-S table. Each axis moves at 120 m/min and the combined speed is 170 m/min. The turret also turns faster, at 27 rpm. On nibbling and dense hole patterns in small sheets, positioning time is most of the cycle, and this model has the least of it.
The punch rates tell a mixed story. Marking is 1,500 strokes/min and the 1 mm step rate is 900 strokes/min, but at a 25 mm step the rate is 350 strokes/min, lower than the longer machines.
The 27-station turret is arranged as 11 A, 10 B, 1 C and 2 D fixed stations, plus two B and one C auto-index stations, according to Ermak's layout. Note that the largest auto-index station is therefore a C station.
It is the smallest machine of the series: 4,290 mm wide, 5,520 mm long, 16,000 kg (35,273 lb). The table takes sheets up to 125 kg (276 lb). Power supply is 40 kW (53.6 hp).
Full Specifications
| Parameter | Value |
|---|---|
| Punching Force | 20 Ton (22 US tons) |
| Max Sheet Size | 2,000 x 1,500 mm (78.7 x 59.1 in) |
| Turret Stations | 27 |
| Max Punch Diameter | 88.9 mm (3.5 in), single tool in 1 mm sheet |
| X Axis Travel | 2,000 mm (78.7 in) + R |
| X Axis Speed | 120 m/min |
| Y Axis Speed | 120 m/min |
| Xy Combined Speed | 170 m/min |
| Turret Rotation Speed | 27 rpm |
| Auto Index Rotation Speed | 65 rpm |
| Punch Rate Marking | 1,500 strokes/min (1 mm stroke) |
| Punch Rate 1 Mm Step | 900 strokes/min (1 mm step in X and Y) |
| Punch Rate 25 Mm Step | 350 strokes/min (25 mm step in X and Y) |
| Max Thickness Fixed Station Mild Steel | 6.35 mm (0.25 in) |
| Max Thickness Fixed Station Stainless Steel | 3 mm (0.12 in) |
| Max Thickness Auto Index Station Mild Steel | 4 mm (0.16 in) |
| Max Thickness Auto Index Station Stainless Steel | 2.5 mm (0.10 in) |
| Repeatability | ±0.05 mm |
| Positioning Accuracy | ±0.1 mm |
| Index Positioning Accuracy | 0.01° |
| Multi Tool Change Time | 3 s |
| Max Sheet Weight | 125 kg (276 lb) |
| Air Pressure | 6 - 7 bar |
| Ram Stroke | 32 mm (1.26 in) |
| Sheet Clamps | 3 |
| Sheet Clamping Force | 1,200 kg (2,646 lb) |
| Power Supply | 40 kW (53.6 hp) |
| Air Supply | 2.5 L/min |
| CNC Control | GE Fanuc 31i-PB with Ermaksan HMI software |
| Press Drive | Servo mechanical press, 20 TN |
| Working Height | 950 mm (37.4 in) |
| Table Type | Brush, ball or brush + ball |
| Machine Length | 5,520 mm (217.3 in) |
| Machine Width | 4,290 mm (168.9 in) |
| Machine Height | 2,220 mm (87.4 in) |
| Machine Weight | 16,000 kg (35,273 lb) |
| CAD CAM Software | Metalix |
Specifications sourced from ermaksan.com.tr — verified 2026-10-05
Strengths & Limitations
Strengths
- 120 m/min per axis and 170 m/min combined, the fastest ETP-S
- Turret rotation of 27 rpm
- Smallest footprint of the series at 5,520 x 4,290 mm
- 40 kW (53.6 hp) power supply
- Servo-electric press that Ermak describes as oil-free
Limitations
- 27 stations instead of 33
- Only 350 strokes/min at a 25 mm step
- Maximum sheet weight of 125 kg (276 lb)
- Sheets longer than 2,000 mm need repositioning
Best For
Frequently Asked Questions
01
X and Y each reach 120 m/min, and the combined X + Y speed is 170 m/min. The ETP-S 1500x3000, by comparison, is listed at 80 m/min per axis.
02
Ermak gives the layout as 11A+10B+1C+2D with 2B+1C auto-index stations. Three automatic index stations let contours be cut at any angle. A multi-tool with 3 or 8 stations is optional.
03
Up to 125 kg (276 lb), on a sheet of at most 2,000 x 1,500 mm. Three clamps hold the sheet with a clamping force of 1,200 kg.
04
1,500 strokes/min for marking with a 1 mm stroke, 900 strokes/min at a 1 mm step and 350 strokes/min at a 25 mm step in X and Y. The ram stroke is 32 mm.
