Durma AD-S 2060
Key Specifications
bending force
bending length
distance between columns
stroke
daylight
throat depth
How much does the Durma AD-S 2060 cost?
Price estimate
We do not have a price for the Durma AD-S 2060 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Durma AD-S 2060 pairs the lowest force in the AD-S series, 60 ton, with a 2,050 mm (80.7 in) bending length. That combination makes it a thin-sheet machine. It is long enough for doors, covers and panels, and light enough in tonnage that plate work belongs on a bigger model.
Its frame opening is that of the larger machines. Stroke is 265 mm (10.4 in), daylight 530 mm (20.9 in) and the throat is 450 mm (17.7 in) deep. The AD-S 1260, the other 60 ton model, is listed with a 350 mm (13.8 in) throat. Deep four-sided trays and parts formed with tall gooseneck punches are therefore realistic here.
Light tonnage keeps the hydraulics small: a 7.5 kW (10.1 hp) motor and 100 L of oil. Beam speeds are 200 mm/sec in rapid, 10 mm/sec in work and 110 mm/sec in return. Thin sheet rarely needs dwell or slow forming, so the rapid figure is the one an operator feels.
Side frames stand 1,700 mm (66.9 in) apart, which limits the length of any flange deeper than the throat. The table is 104 mm (4.1 in) wide and Durma lists no wide table for this size. Overall the machine measures 3,200 mm (126.0 in) in length and 2,850 mm (112.2 in) in height and weighs 5,600 kg (12,346 lb).
Durma equips it with the DT 15 control, a servo X axis with 650 mm (25.6 in) of travel, manual crowning and sliding front arms with T-slot and stopper. The 1,100 mm (43.3 in) Z working distance in the table applies to the optional motorized Z1 and Z2 fingers.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Force | 60 ton |
| Bending Length | 2,050 mm (80.7 in) |
| Distance Between Columns | 1,700 mm (66.9 in) |
| Stroke | 265 mm (10.4 in) |
| Daylight | 530 mm (20.9 in) |
| Throat Depth | 450 mm (17.7 in) |
| Table Height | 900 mm (35.4 in) |
| Table Width | 104 mm (4.1 in) |
| Y Rapid Speed | 200 mm/sec |
| Y Working Speed | 10 mm/sec |
| Y Return Speed | 110 mm/sec |
| Y Axis Precision | 0.01 mm |
| X Axis Working Speed | 500 mm/sec |
| X Axis Precision | 0.05 mm |
| X Axis Travel | 650 mm (25.6 in) standard; 1,000 mm (39.4 in) optional |
| R Axis Working Speed | 350 mm/sec |
| R Axis Travel | 250 mm (9.8 in) |
| R Axis Precision | 0.1 mm |
| Z Axis Working Speed | 1,000 mm/sec |
| Z Axis Travel | 1,100 mm (43.3 in) |
| Motor Power | 7.5 kW (10.1 hp) |
| Oil Tank Capacity | 100 L |
| Machine Length | 3,200 mm (126.0 in) |
| Machine Width | 1,550 mm (61.0 in) |
| Machine Height | 2,850 mm (112.2 in) |
| Machine Weight | 5,600 kg (12,346 lb) |
Specifications sourced from durmazlar.com.tr — verified 2026-10-05
Strengths & Limitations
Strengths
- Full-size opening on a light machine: 265 mm (10.4 in) stroke and 530 mm (20.9 in) daylight
- 450 mm (17.7 in) throat depth at 60 ton
- 200 mm/sec rapid speed for thin-sheet work
- Low installed power: 7.5 kW (10.1 hp) motor, 100 L oil tank
- 5,600 kg (12,346 lb), light for a bed of 2,050 mm (80.7 in)
Limitations
- 60 ton over 2,050 mm (80.7 in) rules out thick material at full length
- 1,700 mm (66.9 in) between the columns
- No wide-table figure; table width is 104 mm (4.1 in)
- Return speed of 110 mm/sec is lower than on the AD-S 30220, listed at 140 mm/sec
Best For
Frequently Asked Questions
01
Durma's table gives no thickness chart, only the force: 60 ton across 2,050 mm (80.7 in). That is a thin-sheet rating at full length. Shorter parts can use the same 60 ton on a narrower die, so check the tonnage chart of the tooling you plan to run.
02
Its opening is generous for the tonnage. Daylight is 530 mm (20.9 in) with a 265 mm (10.4 in) stroke, and the throat is 450 mm (17.7 in) deep. Box sides longer than the throat must fit within the 1,700 mm (66.9 in) between the columns.
03
A servo motor back gauge with linear guides and ballscrew on the X axis is standard, with 650 mm (25.6 in) of travel and 1,000 mm (39.4 in) optional. Motorized R, Z1 and Z2 axes are options. Durma lists the R axis at 250 mm (9.8 in) of working distance.
04
The machine is 3,200 mm (126.0 in) long, 1,550 mm (61.0 in) wide and 2,850 mm (112.2 in) high. It weighs approximately 5,600 kg (12,346 lb), and the table height is 900 mm (35.4 in).
