Dener FTL 9025
Key Specifications
laser power
chuck size
max cutting length
max cutting weight
chuck type
min tail length
How much does the Dener FTL 9025 cost?
Price estimate
We do not have a price for the Dener FTL 9025 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Dener FTL 9025 is a nine-metre, three-chuck tube fiber laser. Maximum cutting length is 9,300 mm (366.1 in) with a 250 mm chuck, and both loading and unloading lengths are 9 m.
That symmetric layout is the reason to buy it. A nine-metre bar goes in, and a finished part of nearly that length can come out, fully supported. Long columns, rails, conveyor frames and lighting masts are cut in one piece with every hole and cope in place.
The maximum cutting weight is 1,200 kg (2,646 lb), four times the figure of the FTL 6025 with the same chuck. So this model is not just a longer version; it is built for heavier bars as well.
Motion figures follow the 250 mm chuck class: 92 m/min tube feeding speed and 85 r/min chuck rotation. Axis travels are 850 mm in X, 10,000 mm in Y and 300 mm in Z. The installation is 19,000 × 2,800 × 3,000 mm. Laser power is 3-20 kW, and the control is FSCUT5000A.
Dener lists an automatic loading system as optional equipment. On nine-metre bars weighing up to 1,200 kg, manual loading means a crane for every bar, so that option affects throughput more than any speed figure.
Full Specifications
| Parameter | Value |
|---|---|
| Laser Power | 3-20 kW |
| Chuck Size | 250 mm (9.8 in) |
| Max Cutting Length | 9,300 mm (366.1 in) |
| Max Cutting Weight | 1,200 kg (2,646 lb) |
| Chuck Type | 3 Moving Chucks |
| Min Tail Length | ≥0 mm |
| Support Type | Servo Follow-Up Support System |
| Resonator | Maxphotonics |
| Laser Head Up to 3 Kw | BOCI BLT310T (≤3 kW) |
| Laser Head 6 Kw | BOCI BLT421TS (6 kW) |
| Laser Head 12 Kw | BOCI BLT442T (12 kW) |
| Laser Head 20 Kw | BOCI BLT560H (20 kW) |
| CNC Control | FSCUT5000A |
| Interface Software | TubePro |
| Guide Rail Pinion and Rack | HIWIN, YYC |
| Motor and Drive | Inovance |
| Gearbox | Motoreducer |
| Nesting Software | TubesT Professional |
| X Axis Travel | 850 mm (33.5 in) |
| Y Axis Travel | 10,000 mm (393.7 in) |
| Z Axis Travel | 300 mm (11.8 in) |
| Xy Positioning Accuracy | ±0.05 mm |
| Xy Repeatability | ±0.05 mm |
| Tube Feeding Speed | 92 m/min |
| Machine Dimensions | 19,000 × 2,800 × 3,000 mm |
| Unloading Length | 9 m |
| Chuck Rotation Speed | 85 r/min |
| Loading Unloading Length | 9 + 9 m |
Specifications sourced from en.dener.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 9,300 mm cutting length with 9 m loading and 9 m unloading
- 1,200 kg (2,646 lb) maximum cutting weight
- Minimum tail length of ≥0 mm
- Laser power options up to 20 kW
Limitations
- 19,000 mm long installation
- Automatic loading system is optional
- Z travel is limited to 300 mm
- The acceleration figure on the maker's page is not usable
Best For
Frequently Asked Questions
01
The unloading length is 9 m and the maximum cutting length 9,300 mm. Loading and unloading length is listed as 9 + 9 m.
02
Up to 1,200 kg (2,646 lb) per tube, in a 250 mm (9.8 in) chuck. The FTL 6025 with the same chuck is limited to 300 kg.
03
The E-FTL 9025 has two chucks, a 2 m unloading length, a 440 kg weight limit and 3-12 kW. The FTL 9025 has three chucks, 9 m of unloading, 1,200 kg and 3-20 kW.
04
Travels are 850 mm in X, 10,000 mm in Y and 300 mm in Z. Tube feeding speed is 92 m/min and chuck rotation speed 85 r/min.
