Campbell Grinder 1000L1000
Key Specifications
Tool Capacity
Spindle Power
max swing diameter
max part height
max part weight
max od grind height
How much does the Campbell Grinder 1000L1000 cost?
Price estimate
We do not have a price for the Campbell Grinder 1000L1000 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Campbell Grinder 1000L1000 is the larger of the two 1000LEAN vertical grinders, with a maximum swing of 1,000 mm (39.37 in) and 1,100 mm (43.5 in) of X travel. Part and fixture can be 865 mm (34.00 in) tall and weigh 910 kg (2,000 lbs).
Against the 1000L800 the difference is reach, not power. X travel grows from the 1,000 mm (39 in) of the 1000L800 to 1,100 mm (43.5 in), and the C axis table runs at 0-200 RPM where the 1000L800 has 0-250 RPM, as suits larger diameters. The rest of the two columns is identical: 14.9 kW (20 HP), 0-8,500 RPM, HSK 80 and a changer for 6 tools.
The kinematics are those of a small universal vertical grinder. Z travel is 865 mm (34 in). A programmable, zero backlash B axis swivels the spindle through 135 degrees, so one wheel can reach an OD, a face and a taper, and the changer brings in an ID wheel or a different abrasive. The linear guides are preloaded and carry embedded absolute scales.
The machine is 137 in (3,480 mm) high, 142 in (3,607 mm) wide and 140 in (3,556 mm) deep. It is built on a traveling column with a one-piece fabricated base, and Campbell supplies it with Fanuc front end controls. Grinding coolant is delivered at the grinding spindle and at a stationary stand pipe.
Full Specifications
| Parameter | Value |
|---|---|
| Max Swing Diameter | 1,000 mm (39.37 in) |
| Max Part Height | 865 mm (34.00 in) part and fixture |
| Max Part Weight | 910 kg (2,000 lbs) part and fixture |
| Max OD Grind Height | 865 mm (34.00 in) |
| Spindle Speed | 0-8,500 RPM |
| Spindle Motor Power | 14.9 kW (20 HP) |
| Tool Connection | HSK 80 |
| Max Arbor Length | 203 mm (8.00 in) |
| Wheel Size | 305 mm dia x 50 mm wide (12 in dia x 2 in wide) max. |
| Tool Capacity | 6 tools |
| Max Tool Length | 200 mm (8 in) |
| Z Axis Travel | 865 mm (34 in) |
| B Axis Range | 135 degrees (infinitely variable) |
| CNC Control | Fanuc front end controls |
| Machine Height | 137 in (3,480 mm) |
| X Axis Travel | 1,100 mm (43.5 in) |
| C Axis Speed | 0-200 RPM, reversable and positioning |
| Machine Width | 142 in (3,607 mm) |
| Machine Depth | 140 in (3,556 mm) |
Specifications sourced from campbellgrinder.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 1,100 mm (43.5 in) of X travel with a 1,000 mm (39.37 in) maximum swing
- Programmable zero backlash B axis with 135 degrees of swivel
- Automatic changer for 6 tools with an HSK 80 connection
- Preloaded linear guides with embedded absolute scales
Limitations
- The same 14.9 kW (20 HP) spindle as the smaller 1000L800
- C axis speed is 0-200 RPM, lower than the 0-250 RPM of the 1000L800
- Part and fixture are limited to 910 kg (2,000 lbs) and 865 mm (34.00 in) of height
- Maximum tool length is 200 mm (8 in), which limits deep ID work
Best For
Frequently Asked Questions
01
Maximum swing is 1,000 mm (39.37 in). Part and fixture can be up to 865 mm (34.00 in) tall and weigh up to 910 kg (2,000 lbs). X travel is 1,100 mm (43.5 in) and Z travel is 865 mm (34 in).
02
The catalogue gives a height of 137 in (3,480 mm), a width of 142 in (3,607 mm) and a depth of 140 in (3,556 mm). The base is a one-piece fabrication with an integrated floor pan, and the machine supports crane and forklift loading.
03
X and Z are the linear axes, with 1,100 mm (43.5 in) and 865 mm (34 in) of travel. The B axis swivels the grinding spindle through 135 degrees and is infinitely variable. The C axis is the rotary table, which runs at 0-200 RPM in either direction and can position.
04
A rotary disk dresser, part probing, light turning, a mag chuck and additional wheel arbors. The standard machine already includes the automatic wheel changer, the single-point dressing system and Fanuc front end controls, so the option list is much shorter than for Campbell's engineered-to-order vertical grinders.
More from Campbell Grinder
Other CNC Grinding Machines
Palmary OCD-42130P
