Palmary OCD-42130P
Image: palmary.com, Palmary
Key Specifications
swing over table
distance between centers
max grinding diameter
max load between centers
wheel size
wheel peripheral speed
How much does the Palmary OCD-42130P cost?
Price estimate
We do not have a price for the Palmary OCD-42130P that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Palmary OCD-42130P is the longest of Palmary's CNC plunge cylindrical grinders with angular wheelhead: 1,300 mm (51.2 in) between centers under a Ø420 mm (16.5 in) swing. No smaller-swing P model is as long, so this is the only choice in the series for long stepped shafts.
The table stroke is 1,800 mm (70.9 in). To turn long parts the workhead motor is raised to 2.0 kW (2.7 hp), the largest in the P series, and total power becomes 19 kVA, against 18 kVA for the OCD-4280P. Curiously the listed weight does not change: 4,800 kg (10,582 lb), the same figure Palmary prints for the OCD-4280P. Treat it as approximate.
Long shafts with many seats are the reason to buy it: machine tool spindles, rotor shafts, long gearbox shafts. Each seat is plunge ground with a wheel of Ø455 to 510 mm, 50 to 80 mm wide, on 5.5 kW (7.4 hp), then the table moves on at up to 10 m/min (394 ipm). The 150 kg (331 lb) center load applies here too, and at this length the optional 2-point and 3-point steady rests deserve a place in the quotation.
Table swivel is -3° to +8° and the workhead swivels -30° to +90°. X stroke is 260 mm (10.2 in) with a linear scale. A FANUC CNC controller and a fully enclosed splash guard are standard accessories.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Table | Ø420 mm (16.5 in) |
| Distance Between Centers | 1,300 mm (51.2 in) |
| Max Grinding Diameter | Ø400 mm (15.7 in) |
| Max Load Between Centers | 150 kg (331 lb) |
| Wheel Size | Ø455~510 x 50~80 x Ø127 mm |
| Wheel Peripheral Speed | 33 m/s (6,496 ft/min) |
| X Axis Rapid Traverse | 10 m/min (394 ipm) |
| X Axis Travel | 260 mm (10.2 in) |
| X Axis Min Setting Unit | 0.001 (0.0001) mm |
| Z Axis Rapid Traverse | 10 m/min (394 ipm) |
| Z Axis Travel | 1,800 mm (70.9 in) |
| Z Axis Min Input Increment | 0.001 (0.0001) mm |
| Table Swivel Angle | -3°, +8° |
| Workhead Swivel Angle | -30°~+90° |
| Workhead Center Taper | M.T. No. 4 |
| Work Spindle Speed | 10-300 rpm |
| Max Load of Work Spindle | 35 kg (77 lb) (max. length: 150 mm) |
| Tailstock Center Taper | M.T. No. 4 |
| Tailstock Stroke | 25 mm (1.0 in) |
| Tailstock Fine Adjustment Range | ±0.03 mm (±0.0012 in) |
| Wheel Spindle Motor | 5.5 kW (7.4 hp) (6P) |
| Workhead Motor | 2.0 kW (2.7 hp) (4P) Frequency |
| Wheelhead Feed Motor | 1.2 kW (1.6 hp) |
| Table Feed Motor | 2.5 kW (3.4 hp) |
| Hydrostatic Pump Motor | 0.37 kW (0.5 hp) (4P) |
| Wheel Spindle Lubrication Pump Motor | 0.37 kW (0.5 hp) (4P) |
| Coolant Pump Motor | 0.18 kW (0.2 hp) (2P) |
| Ballscrew Lubrication | Auto lubricator (LUBE) |
| Power Requirement | 19 kVA |
| Wheel Spindle Lubrication Tank | 31 L (8.2 gal) |
| Lubrication Tank | 31 L (8.2 gal) |
| Hydraulic Tank | 31 L (8.2 gal) |
| Ballscrew Lubrication Tank | 0.7 L (0.2 gal) |
| Coolant Tank | 120 L (31.7 gal) |
| Machine Weight | 4,800 kg (10,582 lb) |
| CNC Control | FANUC CNC controller |
Specifications sourced from palmary.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 1,300 mm (51.2 in) between centers, the longest plunge model
- 1,800 mm (70.9 in) of table stroke
- 2.0 kW (2.7 hp) workhead motor, the largest in the P series
- Keeps the -3° to +8° table swivel of the OCD-4280P
Limitations
- 150 kg (331 lb) load between centers on a 1,300 mm (51.2 in) part
- Listed weight equals that of the shorter OCD-4280P, so the figure needs confirming
- Total power of 19 kVA, the highest in the P series
- Steady rests are optional accessories
Best For
Frequently Asked Questions
01
1,300 mm (51.2 in), with 1,800 mm (70.9 in) of table stroke. Diameter capacity is Ø400 mm (15.7 in) under a Ø420 mm (16.5 in) swing. The centers are No. 4 Morse taper and the maximum load between them is 150 kg (331 lb).
02
Length, workhead motor and power. The OCD-4280P has 800 mm (31.5 in) between centers, a 1.5 kW (2.0 hp) workhead motor and needs 18 kVA. The OCD-42130P has 1,300 mm (51.2 in), a 2.0 kW (2.7 hp) workhead motor and needs 19 kVA.
03
Palmary does not say, but a 1,300 mm (51.2 in) shaft limited to 150 kg (331 lb) is slender, and plunge grinding loads the part across the full wheel width of up to 80 mm. A 2-point steady rest and an adjustable 3-point steady rest are optional accessories.
04
The X axis has a minimum setting unit of 0.001 mm and the Z axis a minimum input increment of 0.001 mm. A linear scale for the X axis is a standard accessory, and both axes are driven by AC servo motors through automatically lubricated ballscrews.
