Anderson VMC-2076
Image: andersonvmc.com, Anderson
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Table Size
Spindle Power
Accuracy
How much does the Anderson VMC-2076 cost?
Price estimate
We do not have a price for the Anderson VMC-2076 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Anderson VMC-2076 is the largest of Anderson's 760 mm Y vertical machining centers. X travel reaches 2,000 mm (78.7 in), the table is 2,100 x 760 mm (82.7 x 29.9 in) and the table load is 2,400 kg (5,291 lb). Anderson calls it the largest model of the group, with 2000mm of X-axis travel for maximum capacity.
Two metres of X on a C-frame vertical is a long reach for a single column, and the proportions say what the machine is for. The work area is more than two and a half times as long as it is deep. Rails, extrusions, long plates, manifold bars and gang fixtures fit that shape. Square or bulky workpieces do not use it well, and at 760 mm (29.9 in) of Y a bridge-type machine is the better answer for those.
Mass and size grow with the bed. The machine weighs 10,000 kg (22,046 lb) and is 5,440 mm long, on the same 3,470 mm width and 3,190 mm height as its shorter siblings. The coolant tank is 520 L. Z travel remains 700 mm (27.6 in).
The spindle specification is shared with the rest of the family, so it has to be read as a list of choices: ISO 40 or optional ISO 50, 8,000 rpm with higher speeds listed, 11/15 kW with a 15/18.5 alternative, belt drive with direct and gearbox variants. For long steel parts taking heavy face-mill cuts, the ISO 50 and gearbox entries are the ones to ask about. Tool changes take 2.5 sec tool-to-tool and 4.8 sec chip-to-chip, and the arm-type changer rotates in both directions. The control is FANUC 0i-MF Plus with a swivelling operator panel.
Full Specifications
| Parameter | Value |
|---|---|
| Table Size | 2,100 x 760 mm (82.7 x 29.9 in) |
| Working Area | 2,000 x 760 mm (78.7 x 29.9 in) |
| X Axis Travel | 2,000 mm (78.7 in) |
| Y Axis Travel | 760 mm (29.9 in) |
| Z Axis Travel | 700 mm (27.6 in) |
| Max Table Load | 2,400 kg (5,291 lb) |
| Spindle Taper | ISO 40 (ISO 50 Optional) |
| Max Spindle Speed | 8,000 rpm (10,000, 12,000, 15,000) |
| Spindle Motor Power | 11/15 kW (15/18.5) |
| Spindle Transmission | Belt (Direct, Gearbox) |
| Distance Spindle Nose to Table | 140 ~ 840 mm (5.5 ~ 33.1 in) |
| Tool Capacity | 24 (30, 32, 36) |
| Tool Selection Method | Random Bi-directional |
| Max Tool Diameter (full magazine) | Ø75 / Ø150 mm (Ø3.0 / Ø5.9 in) |
| Max Tool Weight | 7 kg (15 lb) |
| Tool Change Time | T-T: 2.5 sec; C-C: 4.8 sec |
| Max Tool Length | 300 mm (11.8 in) |
| Positioning Accuracy | ±0.008 mm |
| Repeatability | ±0.004 mm |
| Rapid Traverse Xyz | 24/24/24 m/min (30/30/24) |
| Cutting Feed Rate | 12,000 mm/min |
| Machine Dimensions | 5,440 x 3,470 x 3,190 mm (214.2 x 136.6 x 125.6 in) |
| Coolant Tank Capacity | 520 L |
| Coolant Flow | 200 L/min |
| Air Pressure Required | 5-7 kg/cm² |
| CNC Control | FANUC 0i-MF Plus |
| Machine Weight | 10,000 kg (22,046 lb) |
Specifications sourced from andersonvmc.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 2,000 mm (78.7 in) of X travel, the longest in this family
- 2,400 kg (5,291 lb) table load on a 2,100 x 760 mm (82.7 x 29.9 in) table
- ISO 50 taper and gearbox transmission are listed as alternatives for heavier cutting
- 520 L coolant tank, the largest of the three sizes
- Arm-type tool changer with bi-directional random selection
Limitations
- Y travel of 760 mm (29.9 in) is narrow against 2,000 mm of X
- Heaviest and longest of the three: 10,000 kg (22,046 lb) and 5,440 mm
- Standard rapids of 24/24/24 m/min make long X moves slow compared with the 30/30/24 alternative
- Standard magazine is 24 tools; larger magazines are listed as alternatives
Best For
Frequently Asked Questions
01
2,000 mm (78.7 in), with 760 mm (29.9 in) of Y and 700 mm (27.6 in) of Z. The table measures 2,100 x 760 mm (82.7 x 29.9 in) and the working area 2,000 x 760 mm (78.7 x 29.9 in).
02
03
The spindle taper row reads ISO 40 with ISO 50 optional, and the transmission row lists belt with direct and gearbox variants. The table does not state the speed or the magazine that go with ISO 50 on this page, so those details should be requested with the quotation.
04
Rapid traverse is 24/24/24 m/min, with 30/30/24 listed in brackets as an alternative, and the cutting feed rate is 12,000 mm/min. Over 2,000 mm of X travel the rapid rate has a visible effect on cycle time when the tool moves between distant features.
