Anderson EXXACT DUO
Key Specifications
Max Spindle
Spindle Taper
Tool Capacity
Spindle Power
number of tables
vacuum zones per table
How much does the Anderson EXXACT DUO cost?
Price estimate
We do not have a price for the Anderson EXXACT DUO that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Anderson EXXACT DUO is the twin-table, twin-spindle member of the EXXACT line. Anderson's table lists 2 tables, given as 2 x 1840 mm (2 x 72.4 in) in X by 2 x 1600 mm (2 x 63 in) in Y, each with 1 vacuum zone, and the company describes the head as an ANDI HSK-63F dual spindle.
Two tables change how the operator works. One table can be loaded while parts are cut on the other, so the spindle is not waiting on a person. Two spindles change the output per pass: matching parts can be cut side by side. Anderson sums this up as doubling productivity, which is its claim and depends entirely on the part mix.
The listed figures follow the single-table EXXACT closely. X stroke is 4400 mm (174 in), Z stroke 350 mm (14 in), and X and Y both rapid at 80 M/min. Spindle power is 18 HP / 24 HP at up to 24000 rpm. The ride-along tool changer is listed as 10 / 12 and the boring block as 5+5 or 10+7. Floor area is 6000 x 3375 mm (236 x 133 in), height 2800 mm (110 in) and weight 9300 kg (20,500 lbs.). The control is FANUC 0i.
Some caution is due with this table. The Y stroke cell is empty, and the Z rapid row prints a metric and an inch figure that do not agree, so neither is repeated here. The page also describes the machine in one place as a traveling gantry design and in another as a fixed bridge with moving tables. Ask Anderson for the current configuration sheet before relying on any of those points. Anderson's EXXACT PRO DUO page gives a fuller table for a machine of the same table size.
Full Specifications
| Parameter | Value |
|---|---|
| Number of Tables | 2 |
| Vacuum Zones per Table | 1 |
| Table Size X | 2 x 1840 mm (2 x 72.4 in) |
| Table Size Y | 2 x 1600 mm (2 x 63 in) |
| X Axis Travel | 4400 mm (174 in) |
| Z Axis Travel | 350 mm (14 in) |
| Rapid Traverse X | 80 M/min (3150“/min.) |
| Rapid Traverse Y | 80 M/min (3150“/min.) |
| Spindle Motor Power | 18 HP / 24 HP |
| Max Spindle Speed | 24000 rpm |
| Spindle Taper | HSK-63F |
| Tool Capacity | 10 / 12 |
| Boring Block | 5+5 or 10+7 |
| Vacuum Pump | 10/25/40 HP |
| CNC Control | FANUC 0i |
| Floor Area | 6000 x 3375 mm (236 x 133 in) |
| Machine Height | 2800 mm (110 in) |
| Machine Weight | 9300 kg (20,500 lbs.) |
| Vector Spindle HSK 63 E | optional |
| Reverse Air Flow | optional |
| Bar Code Reader | optional |
| C Axis | optional |
| Gantry Offload Pusher | optional |
| Automatic Loading | optional |
Specifications sourced from andersonamerica.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 2 tables, so one can be loaded while the other is being cut
- Dual HSK-63F spindle for cutting matching parts together
- Spindle power of 18 HP / 24 HP at up to 24000 rpm
- 80 M/min rapids in X and Y with 4400 mm (174 in) of X stroke
- Boring block in 5+5 or 10+7 form and a ride-along tool changer
Limitations
- Each table has 1 vacuum zone, so partial sheets leave open area
- Anderson's table leaves the Y stroke blank and prints a Z rapid whose two units disagree
- Each table is 1840 mm (72.4 in) long, which rules out full-length sheet on one table
- 9300 kg (20,500 lbs.) on a 6000 x 3375 mm (236 x 133 in) floor area
Best For
Frequently Asked Questions
01
The table lists 2 tables with sizes of 2 x 1840 mm (2 x 72.4 in) in X and 2 x 1600 mm (2 x 63 in) in Y, each with 1 vacuum zone. X stroke is 4400 mm (174 in). The Y stroke cell is empty in Anderson's table, so the usable width per spindle should be confirmed.
02
Anderson describes an ANDI HSK-63F dual spindle. The table lists power as 18 HP / 24 HP and maximum speed as 24000 rpm. The Vector Spindle HSK 63-E is an option. The ride-along tool changer row reads 10 / 12; the table does not say whether that count is per spindle.
03
Both have two tables of 1840 x 1600 mm (72.4 x 63 in) and a 4400 mm (174 in) X stroke. The EXXACT PRO DUO table is more detailed: it lists a 1775 mm (70 in) Y stroke, 2 vacuum zones per table, two 18 HP heads with 10 positions per spindle and a net machine weight of 8200 kg (18,100 lbs).
04
The Vector Spindle HSK 63-E, reverse air flow, a bar-code reader, a C-axis, a gantry offload pusher and automatic loading are each marked optional. The vacuum pump is offered in 10, 25 or 40 HP sizes and the control is FANUC 0i.
