Accuway UT-600LX2
Image: accuway.com.tw, Accuway
Key Specifications
Max Spindle
Spindle Power
Max Turn Length
control
swing over bed
swing over saddle
How much does the Accuway UT-600LX2 cost?
Price estimate
We do not have a price for the Accuway UT-600LX2 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Accuway UT-600LX2 turns parts up to 900 mm (35.4 in) in diameter and 1,900 mm (74.8 in) long, on a Z travel of 2,100 mm (82.7 in). Its listed weight is 20,000 kg (44,092 lb).
Start with the weight, because it is out of line with its neighbours. The shorter UT-600L is listed at 14,500 kg (31,966 lb) and the longer UT-600LX3 at 19,000 kg (41,887 lb), less than this model. The same pattern appears in the UT-400 pages. The figures are given here as Accuway prints them; whoever plans the foundation should get the weight confirmed in writing.
The working envelope is clear enough. Swing over the saddle is 950 mm (37.4 in), so nearly the full turning diameter can travel the length of the bed. X travel is 495 mm (19.5 in). Z rapid traverse is 15 m/min (591 in/min).
What goes into the chuck decides the spindle column. For solid shafts and rolls the three A2-15 columns with the smaller chucks apply, at 1,500 rpm, 850 rpm or 800 rpm. For pipe, the A2-20 columns have a 32 in chuck and a 320 mm (12.6 in) or 375 mm (14.8 in) bore, at 400 rpm or 300 rpm. All of them are driven by 30/37 kW (40.2/49.6 hp) through a 2-step gearbox. The tailstock body travels 2,050 mm (80.7 in). A steady rest is optional.
Full Specifications
| Parameter | Value |
|---|---|
| CNC Control | FANUC 0i-T |
| Swing Over Bed | 1,030 mm (40.6 in) |
| Swing Over Saddle | 950 mm (37.4 in) |
| Max Turning Diameter | 900 mm (35.4 in) |
| Max Turning Length | 1,900 mm (74.8 in) |
| Guideway Type | Box |
| Spindle Nose | A2-15 / A2-15 / A2-15 / A2-20 / A2-20 |
| Chuck Size | 20 / 20 / 24 / 32 / 32 in |
| Spindle Bore | 205 / 235 / 258 / 320 / 375 mm (8.1 / 9.3 / 10.2 / 12.6 / 14.8 in) |
| Max Spindle Speed | 1,500 / 850 / 800 / 400 / 300 rpm |
| Spindle Motor Power | Cont. / 30min: 30/37 kW (40.2/49.6 hp), in brackets 37/45 kW (49.6/60.3 hp) + 2-step gearbox |
| X Axis Travel | 495 mm (19.5 in) |
| Z Axis Travel | 2,100 mm (82.7 in) |
| Rapid Traverse X | 20 m/min (787 in/min) |
| Rapid Traverse Z | 15 m/min (591 in/min) |
| Turret Tooling | BOT |
| Turret Drive | Servo mechanical |
| Turret Stations | 12 |
| Square Tool Shank | 32 mm (1.3 in) |
| Round Tool Shank | 50 mm (2.0 in) |
| Tailstock Body Travel | 2,050 mm (80.7 in) |
| Tailstock Quill Travel | 150 mm (5.9 in) |
| Tailstock Quill Diameter | 160 mm (6.3 in) |
| Tailstock Quill Taper | MT#6 |
| Machine Dimensions | L x W x H: 6.9 x 2.9 x 3 m (271.7 x 114.2 x 118.1 in) |
| Machine Weight | 20,000 kg (44,092 lb) |
Specifications sourced from accuway.com.tw — verified 2026-10-04
Strengths & Limitations
Strengths
- 900 mm (35.4 in) turning diameter over 1,900 mm (74.8 in) of length
- 950 mm (37.4 in) swing over saddle
- Five spindle columns, bores from 205 mm (8.1 in) to 375 mm (14.8 in)
- Tailstock body travel of 2,050 mm (80.7 in) with a 160 mm (6.3 in) quill
- Gear box among the standard accessories
Limitations
- Listed weight of 20,000 kg (44,092 lb) is higher than the longer UT-600LX3 and needs confirming
- Z rapid traverse of 15 m/min (591 in/min)
- A2-20 columns run at 400 rpm or 300 rpm
- 6.9 x 2.9 x 3 m (271.7 x 114.2 x 118.1 in) footprint
Best For
Frequently Asked Questions
01
Swing over bed 1,030 mm (40.6 in), swing over saddle 950 mm (37.4 in), maximum turning diameter 900 mm (35.4 in), maximum turning length 1,900 mm (74.8 in), X travel 495 mm (19.5 in) and Z travel 2,100 mm (82.7 in).
02
The net weight row reads 20,000 kg (44,092 lb), and the dimensions 6.9 x 2.9 x 3 m (271.7 x 114.2 x 118.1 in). Because the longer UT-600LX3 is listed lighter, at 19,000 kg (41,887 lb), the figure should be confirmed with Accuway.
03
The chuck diameter row reads 20 / 20 / 24 / 32 / 32 in: the first three sit on A2-15 noses and the last two on A2-20 noses. The spindle hole diameters are 205, 235, 258, 320 and 375 mm (8.1, 9.3, 10.2, 12.6 and 14.8 in).
04
A 12-station BOT turret with servo mechanical drive for 32 mm (1.3 in) square and 50 mm (2.0 in) round shank tools. An APT 60 power turret with CS contouring control or CF Axis Control is on the optional accessories list.
