You Ji VHL2000ATC
Image: image.youji.com, You Ji
Key Specifications
Spindle Power
table diameter
max swing diameter
max turning diameter
max turning height
x1 axis travel
How much does the You Ji VHL2000ATC cost?
Price estimate
We do not have a price for the You Ji VHL2000ATC that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
Every drive and travel row is larger on the You Ji VHL2000ATC than on the two smaller side-head machines. This vertical turning center has a Ø2,000 mm (78.7 in) table, a 60/75 kW (80.5/100.6 hp) table motor and an 11/15 kW (14.8/20.1 hp) live spindle motor on the side head.
The envelope is Ø2,300 mm (90.6 in) of turning diameter under a Ø2,500 mm (98.4 in) swing, with 1,600 mm (63.0 in) of turning height. To use that height the crossrail travels 1,150 mm (45.3 in) vertically and the main ram has 950 mm (37.4 in) of Z1. X1 travel is -600, +1,350 mm (-23.6, +53.1 in).
On the side head, Z2 grows to 950 mm (37.4 in) while X2 remains 1,720 mm (67.7 in). The stronger live spindle, marked α12i against the α8i of the smaller models, makes outside-diameter milling and drilling more than an occasional operation.
That combination suits tall cylindrical parts with features on the wall: large valve bodies, gearbox casings, winch drums and wind-turbine hubs. The main ram turns and bores from the top while the side head handles the outside, and the part is clamped once.
It is a long machine at 14,500 x 6,500 mm (570.9 x 255.9 in), and 6,500 mm (255.9 in) high. ATC, ATC+C with C-axis function and two raised-column heights are in the model key. The VHL table states no loading weight or table speed.
Full Specifications
| Parameter | Value |
|---|---|
| Table Diameter | Ø2,000 mm (78.7 in) |
| Max Swing Diameter | Ø2,500 mm (98.4 in) |
| Max Turning Diameter | Ø2,300 mm (90.6 in) |
| Max Turning Height | 1,600 mm (63.0 in) |
| X1 Axis Travel | -600, +1,350 mm (-23.6, +53.1 in) |
| Z1 Axis Travel | 950 mm (37.4 in) |
| Crossrail Vertical Travel | 1,150 mm (45.3 in) |
| Spindle Motor Power | 60/75 kW (80.5/100.6 hp) (α40i) |
| Side Head X2 Axis Travel | 1,720 mm (67.7 in) |
| Side Head Z2 Axis Travel | 950 mm (37.4 in) |
| Side Head Live Spindle Power | 11/15 kW (14.8/20.1 hp) (α12i) |
| Floor Space | 14,500 x 6,500 mm (570.9 x 255.9 in) |
| Machine Height | 6,500 mm (255.9 in) |
Specifications sourced from image.youji.com — verified 2026-10-04
Strengths & Limitations
Strengths
- 60/75 kW (80.5/100.6 hp) table spindle motor, the largest in the VHL series
- Side head live spindle motor of 11/15 kW (14.8/20.1 hp) with 950 mm (37.4 in) Z2 travel
- 1,600 mm (63.0 in) turning height with 1,150 mm (45.3 in) of crossrail travel
- Ø2,300 mm (90.6 in) turning diameter; X1 travel of -600, +1,350 mm (-23.6, +53.1 in)
Limitations
- Floor dimension of 14,500 x 6,500 mm (570.9 x 255.9 in)
- Side head X2 travel is 1,720 mm (67.7 in), no more than on the VHL1200ATC
- No loading weight or table speed is printed for the series
Best For
Frequently Asked Questions
01
The table spindle motor is 60/75 kW (80.5/100.6 hp), marked α40i, and the side head live spindle motor is 11/15 kW (14.8/20.1 hp), marked α12i. The VHL1600ATC lists 37/45 kW (49.6/60.3 hp) and 7.5/11 kW (10.1/14.8 hp).
02
X1 is -600, +1,350 mm (-23.6, +53.1 in), Z1 is 950 mm (37.4 in) and the crossrail moves 1,150 mm (45.3 in) vertically. The side head has 1,720 mm (67.7 in) in X2 and 950 mm (37.4 in) in Z2.
03
Up to Ø2,300 mm (90.6 in) in turning diameter, Ø2,500 mm (98.4 in) in swing and 1,600 mm (63.0 in) in turning height, on a Ø2,000 mm (78.7 in) table.
04
Table, swing, turning diameter, turning height and table motor match. The VTL2000ATC has a single ram and occupies 6,850 x 4,650 mm (269.7 x 183.1 in). The VHL2000ATC adds the side head and occupies 14,500 x 6,500 mm (570.9 x 255.9 in).
