Yawei PBC-220/3100
Key Specifications
bending force
bending length
distance between columns
throat depth
ram stroke
die setting height
How much does the Yawei PBC-220/3100 cost?
Price estimate
We do not have a price for the Yawei PBC-220/3100 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Yawei PBC-220/3100 puts the top pressure of the PBC series, 2,200 kN, on the three-metre bed. Its main motor is 21.4 kW (28.7 hp), the largest in the series.
The frame grows to carry the load. Overall dimensions are 3,640 x 1,820 x 3,025 mm (143.3 x 71.7 x 119.1 in), and the width of 1,820 mm is a clear step up from the 1,570 mm of the PBC-160/3100. Weight is 12,300 kg (27,116 lb).
Speed is the price. Slider speeds read 160 mm/s; 14 mm/s; 160 mm/s, the lowest set on the PBC page, against 200 mm/s; 15 mm/s; 180 mm/s for the PBC-160/3100. For heavy plate that is of little concern, because handling the part takes longer than the stroke. For thin sheet it makes this the wrong machine.
A comparison inside Yawei's range is useful. The hybrid PBM-220/3100 has the same pressure and bed, weighs 13,000 kg (28,660 lb) and lists 220 mm/s in the first speed position. The PBC is the conventional hydraulic design, with a 300 L tank and a single motor. It offers the point-by-point mechanical crowning and dual rail slider guide that Yawei lists for the series. Frame figures stay at 410 mm (16.1 in), 265 mm (10.4 in) and 600 mm (23.6 in), with 2,600 mm (102.4 in) between columns.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Force | 2,200 kN |
| Bending Length | 3,100 mm (122.0 in) |
| Distance Between Columns | 2,600 mm (102.4 in) |
| Throat Depth | 410 mm (16.1 in) |
| Ram Stroke | 265 mm (10.4 in) |
| Die Setting Height | 600 mm (23.6 in) |
| Ram Speed | 160 mm/s; 14 mm/s; 160 mm/s |
| Main Motor Power | 21.4 kW (28.7 hp) |
| Oil Tank Volume | 300 L |
| Machine Dimensions | 3,640 x 1,820 x 3,025 mm (143.3 x 71.7 x 119.1 in) |
| Machine Weight | 12,300 kg (27,116 lb) |
Specifications sourced from en.yawei.cc — verified 2026-10-05
Strengths & Limitations
Strengths
- 2,200 kN, the highest pressure in the PBC series
- Compact length for the force, with a 3,100 mm bed
- 21.4 kW (28.7 hp) main motor
- Mechanical crowning adjustable point by point
- Lighter than the hybrid PBM-220/3100, which weighs 13,000 kg (28,660 lb)
Limitations
- Slowest slider speeds on the PBC page: 160 mm/s; 14 mm/s; 160 mm/s
- Wider frame than the PBC-160/3100
- First speed position of 160 mm/s; the PBM-220/3100 lists 220 mm/s
- 2,600 mm (102.4 in) between columns
Best For
Frequently Asked Questions
01
2,200 kN, offered on the PBC-220/3100 and the PBC-220/4100. This model applies it over a bending length of 3,100 mm (122.0 in).
02
Slider speeds are 160 mm/s; 14 mm/s; 160 mm/s, unlabelled in the table. They are the lowest values in the PBC series; the PBC-160/3100 lists 200 mm/s; 15 mm/s; 180 mm/s.
03
Pressure, length and frame figures match. The PBM-220/3100 is a hybrid with 15 x 2 kW and 13,000 kg (28,660 lb). The PBC-220/3100 has a single 21.4 kW (28.7 hp) motor and weighs 12,300 kg (27,116 lb).
04
Overall dimensions are 3,640 x 1,820 x 3,025 mm (143.3 x 71.7 x 119.1 in). Oil tank volume is 300 L. Machine weight is 12,300 kg (27,116 lb).
