Yawei PBH(A)-1600/12000
Key Specifications
bending force
table length
distance between columns
throat depth
ram stroke
max opening height
How much does the Yawei PBH(A)-1600/12000 cost?
Price estimate
We do not have a price for the Yawei PBH(A)-1600/12000 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Yawei PBH(A)-1600/12000 is where the PBH(A) series changes character. On a 12,000 mm (472.4 in) table with 16,000 kN of force, the throat opening jumps to 1,000 mm (39.4 in) and the maximum opening height to 1,250 mm (49.2 in).
Those two figures are far beyond anything below it in the table. The PBH(A)-1200/12000, with a table of equal length, has a 610 mm (24.0 in) throat and a 720 mm (28.3 in) opening. With more than a metre of daylight, a closed or nearly closed section can be formed and then drawn out along the bed, and with a throat this deep a part can overhang the columns by a long way. The slider stroke is 500 mm (19.7 in).
Between the columns there is 9,500 mm (374.0 in). Power comes from two motors, printed as 2 x 55 kW, and a 3,000 L tank. Slider speeds are 70 mm/s; 7 mm/s; 60 mm/s, the same as on the eight-metre PBH(A)-1600/8200.
The overall dimensions, 12,200 x 4,700 x 9,900 mm (480.3 x 185.0 x 389.8 in), describe a structure almost ten metres high. Yawei prints no weight. Machines of this kind are normally set partly below floor level, and the supplier's foundation drawing is the document to plan from.
Typical products are large tapered and polygonal poles, crane boom sections and long box girders, formed from single plates.
Full Specifications
| Parameter | Value |
|---|---|
| Bending Force | 16,000 kN |
| Table Length | 12,000 mm (472.4 in) |
| Distance Between Columns | 9,500 mm (374.0 in) |
| Throat Depth | 1,000 mm (39.4 in) |
| Ram Stroke | 500 mm (19.7 in) |
| Max Opening Height | 1,250 mm (49.2 in) |
| Ram Speed | 70 mm/s; 7 mm/s; 60 mm/s |
| Main Motor Power | 2 x 55 kW |
| Oil Tank Volume | 3,000 L |
| Machine Dimensions | 12,200 x 4,700 x 9,900 mm (480.3 x 185.0 x 389.8 in) |
Specifications sourced from en.yawei.cc — verified 2026-10-05
Strengths & Limitations
Strengths
- Throat opening of 1,000 mm (39.4 in)
- Maximum opening height of 1,250 mm (49.2 in)
- 16,000 kN over a 12,000 mm (472.4 in) table
- 9,500 mm (374.0 in) between the columns
- Slider speeds equal to the PBH(A)-1600/8200
Limitations
- No machine weight is printed
- Structure almost ten metres high
- Stroke of 500 mm (19.7 in) is short against the opening height
- 3,000 L of oil and two main motors to supply
Best For
Frequently Asked Questions
01
Depth and daylight. Against the PBH(A)-1200/12000, the throat opening goes from 610 mm (24.0 in) to 1,000 mm (39.4 in) and the maximum opening height from 720 mm (28.3 in) to 1,250 mm (49.2 in).
02
16,000 kN of nominal force on a 12,000 mm (472.4 in) table, with 9,500 mm (374.0 in) between the columns and a slider stroke of 500 mm (19.7 in).
03
The motor row is printed as 2 x 55 kW and the oil tank volume as 3,000 L. Slider speeds are 70 mm/s; 7 mm/s; 60 mm/s, three values without labels.
04
Overall dimensions are 12,200 x 4,700 x 9,900 mm (480.3 x 185.0 x 389.8 in) as length, width and height. No total weight is given in Yawei's table for this model.
