Vision Wide Vertical Machining Centers (VMC)

Vision Wide NF-10023 / NF-10030

Q: How much does the Vision Wide NF-10023 / NF-10030 cost?

The price estimate for the Vision Wide NF-10023 / NF-10030 is uncertain: we have no price for it that we can cite and no estimate we can stand behind, so we give no figure. Configuration, tooling, automation and installation move the final price substantially. A specific price can be requested at https://machinetoolindex.com/machines/vision-wide-nf-10023-nf-10030#price; the request is passed to Vision Wide or an authorised dealer.

Specs verified 2026-10-04 · visionwide-tech.com Updated 2026-10-04

Image: visionwide-tech.com, Vision Wide

Key Specifications

Table Size

10,000×2,050 mm (393.7×80.7 in)

x axis travel

10,100 mm (397.6 in)

y axis travel

2,300/ 3,000 mm (90.6/ 118.1 in)

z axis travel box way single ballscrew

920 / 1,020 mm (36.2 / 40.2 in)(Opt.)

z axis travel linear way enclosed box ram dual ballscrews

1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)

max table load

26,000 kg (57,319 lb)

How much does the Vision Wide NF-10023 / NF-10030 cost?

Price estimate

Uncertain

We do not have a price for the Vision Wide NF-10023 / NF-10030 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.

Overview

Ten metres of X travel is the upper end of the NF table-type range. The Vision Wide NF-10023 / NF-10030 lists 10,100 mm (397.6 in) of X, a 10,000×2,050 mm (393.7×80.7 in) table and a 26,000 kg (57,319 lb) load.

Look at how the load rating grows along the series. The NF-8023 carries 24,000 kg (52,910 lb) on a table two metres shorter. The longest table adds length much faster than it adds capacity, so the allowable weight per metre is lowest here. This is a machine for long parts, not for the heaviest ones: rails, crane and bridge components, long frames and beams.

It moves like the NF-8023: X/Y rapid of 8 m/min and a cutting feed range of 1-7,000 mm/min. Z rapid is 15 m/min on the box way head.

Accuracy over such a length is a matter of feedback. Vision Wide states that positioning accuracy could reach ±0.005/300 mm (JIS B6333), a figure given per 300 mm, and XYZ-axis linear scale feedback is on the option list. On a ten-metre axis the scale is hard to do without. Y travel is 2,300 mm on the NF-10023 and 3,000 mm on the NF-10030.

Full Specifications

Parameter	Value
X Axis Travel	10,100 mm (397.6 in)
Y Axis Travel	2,300/ 3,000 mm (90.6/ 118.1 in)
Z Axis Travel Box Way Single Ballscrew	920 / 1,020 mm (36.2 / 40.2 in)(Opt.)
Z Axis Travel Linear Way Enclosed Box Ram Dual Ballscrews	1,000 mm (39.4 in)(Opt.) / 1,200 mm (47.2 in)(Opt.) / 1,400 mm (55.1 in)(Opt.)
Table Size	10,000×2,050 mm (393.7×80.7 in)
Max Table Load	26,000 kg (57,319 lb)
Spindle Power Cont 30 Min	18.5/22 kW (24.8/29.5 hp)(22/26 kW (29.5/34.9 hp) Opt.)(30/37 kW (40.2/49.6 hp) Opt.)
Spindle Speed Box Way 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram 2 Step Gear	4,000 / 6,000 rpm(Opt.)
Spindle Speed Linear Way Enclosed Box Ram Direct Driven	10,000 rpm(Opt.)
Cutting Feed Rate	1-7,000 mm/min
Rapid Traverse Xy	8 m/min
Rapid Traverse Z Box Way or Linear Way	15 m/min
Rapid Traverse Z Enclosed Box Ram	12 m/min
Tool Capacity Vertical Tool Change	32 / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)
Tool Capacity Floor Standing Vertical Horizontal Tool Change	32 pcs(Opt.) / 40 pcs (Opt.) / 60 pcs (Opt.)

Specifications sourced from visionwide-tech.com — verified 2026-10-04

Strengths & Limitations

Strengths

10,100 mm (397.6 in) of X travel, the longest in the NF series
26,000 kg (57,319 lb) table load
Optional XYZ-axis linear scale feedback
Z rapid of 15 m/min on the box way head

Limitations

Load capacity grows little over the NF-8023, which carries 24,000 kg (52,910 lb)
X/Y rapid of 8 m/min and cutting feed capped at 7,000 mm/min
Linear scales are optional

Best For

Rails, beams and long frames up to 10,000×2,050 mm (393.7×80.7 in) Long parts that are light for their length Five-face machining without re-clamping a ten-metre part

Frequently Asked Questions

01 What is the longest Vision Wide NF model?

The models with 10,100 mm (397.6 in) of X travel. The NF-10023 / NF-10030 is the narrowest of them, with a 10,000×2,050 mm (393.7×80.7 in) table and 2,300 mm or 3,000 mm of Y travel.

02 How much weight can the NF-10023 carry?

26,000 kg (57,319 lb). For comparison, the NF-8023 carries 24,000 kg (52,910 lb) and the NF-6023 carries 22,000 kg (48,501 lb).

03 How accurate is the NF-10023 / NF-10030?

Vision Wide says positioning accuracy could reach ±0.005/300 mm (JIS B6333) for the NF series. XYZ-axis linear scale feedback is optional. No full-travel accuracy figure is published.

04 What are the feeds on the NF-10023?

Cutting feed is 1-7,000 mm/min and the X/Y rapid is 8 m/min. Z rapid is 15 m/min with the box way or linear way head, or 12 m/min with the enclosed box ram.
