Victor Taichung VMT-X360
Image: machine-tools.victortaichung.com, Victor Taichung
Key Specifications
Max Spindle
Tool Capacity
Max Turn Length
swing over bed
max turning diameter
spindle nose
How much does the Victor Taichung VMT-X360 cost?
Price estimate
We do not have a price for the Victor Taichung VMT-X360 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Victor Taichung VMT-X360 is the long-bed half of the VMT-X range, a turn-mill for parts up to Ø720 mm (Ø28.34 in) in diameter and 2,100 mm (82.67 in) long. Swing over the bed is Ø1,120 mm (Ø44.09 in). The main spindle carries an A2-11 nose with a 12 in chuck, runs to 3,000 rpm and passes Ø91 mm (Ø3.58 in) bar.
Everything about it is scaled for shafts. Turning length is close to double the 1,075 mm of the VMT-X260, the maker gives a Y-axis travel of 420 mm (16.5 in), and the magazine holds 60 tools. Turning power is given as 30 kW. The milling spindle itself is unchanged across the range: HSK-T63, 12,000 rpm, 15 / 18.5 / 22 kW (20 / 25 / 30 HP).
With a Double SP machine the sub-spindle is a copy of the main spindle, 3,000 rpm on an A2-11 nose with Ø91 mm (Ø3.58 in) through it. The tailstock quill, M.T. #5, appears only in the Single SP column. Both columns are listed at 23,500 kg (51,808.56 lb).
What a buyer should weigh is the chuck. A 12 in chuck on a machine that swings Ø720 mm (Ø28.34 in) suits bar and slender shaft work at up to 3,000 rpm. For heavier chuck work on the same bed, Victor Taichung offers the VMT-X400 with a 15 in chuck at 2,500 rpm.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Bed | Ø1,120 mm (Ø44.09 in) |
| Max Turning Diameter | Ø720 mm (Ø28.34 in) |
| Max Turning Length | 2,100 mm (82.67 in) |
| Max Spindle Speed | 3,000 rpm |
| Spindle Nose | A2-11 (12”) |
| Bar Capacity | Ø91 mm (Ø3.58 in) |
| Sub Spindle Speed | Double SP: 3,000 rpm (Single SP: not listed) |
| Sub Spindle Nose | Double SP: A2-11 (12") (Single SP: not listed) |
| Sub Spindle Bar Capacity | Double SP: Ø91 mm (Ø3.58 in) (Single SP: not listed) |
| Milling Spindle Speed | 12,000 rpm |
| Milling Spindle Power | 15 / 18.5 / 22 kW (20 / 25 / 30 HP) |
| Tool Shank | HSK-T63 |
| Tool Capacity | 60 |
| Tailstock Quill Taper | Single SP: M.T. #5 (Double SP: not listed) |
| Machine Weight | 23,500 kg (51,808.56 lb) |
Specifications sourced from machine-tools.victortaichung.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 2,100 mm (82.67 in) turning length with a Ø720 mm (Ø28.34 in) maximum turning diameter
- Ø91 mm (Ø3.58 in) bar capacity through an A2-11 spindle at up to 3,000 rpm
- 60-tool magazine for the 12,000 rpm HSK-T63 milling spindle
- Y-axis travel of 420 mm (16.5 in) for off-centre features on large shafts
- Double SP sub-spindle has the same nose, speed and bore as the main spindle
Limitations
- The 12 in chuck is small for the Ø720 mm (Ø28.34 in) the machine can swing
- Milling power is the same 15 / 18.5 / 22 kW (20 / 25 / 30 HP) as on the smallest VMT-X machine
- The Double SP column lists no tailstock quill
- 23,500 kg (51,808.56 lb) of machine needs a foundation designed for it
Best For
Frequently Asked Questions
01
Maximum turning diameter is Ø720 mm (Ø28.34 in), maximum turning length is 2,100 mm (82.67 in) and swing over the bed is Ø1,120 mm (Ø44.09 in). Bar capacity through the main spindle is Ø91 mm (Ø3.58 in).
02
The chuck and the spindle speed. The VMT-X360 has a 12 in chuck and 3,000 rpm. The VMT-X400 has a 15 in chuck and 2,500 rpm on the same A2-11 nose. Capacity, bar size, milling spindle and the 60-tool magazine are the same on both.
03
60 tools with an HSK-T63 interface, feeding a 12,000 rpm milling spindle rated 15 / 18.5 / 22 kW (20 / 25 / 30 HP). The VMT-X200 and VMT-X260 carry 40 tools.
04
Not from the table. The M.T. #5 tailstock quill is listed for the Single SP only, and the Double SP column shows a sub-spindle with no quill. A steady rest is listed as an option for both.
