Takamaz XWT-8

Est. $200,000 - $290,000 Specs verified 2026-10-03 · takamaz.co.jp Updated 2026-10-03

Image: takamaz.co.jp, Takamaz

Key Specifications

X Travel

150 mm (5.9 in)

Z Travel

180 mm (7.1 in)

Max Spindle

4,000 rpm

Rapid Traverse

X 24 m/min, Z 24 m/min

Spindle Power

11 / 7.5 kW × 2

Max Turn Length

100 mm (3.94 in) per spindle

How much does the Takamaz XWT-8 cost?

Estimated price range

Est.$200,000 - $290,000

Our best estimate for a cnc lathes / turning center in this class — not a quote from Takamaz. Configuration moves it a long way.

Overview

The Takamaz XWT-8 is a twin-spindle chucking lathe with an 8 collet on each spindle (Collet, 8 × 2), 11 / 7.5 kW per spindle at up to 4,000 rpm and an 8-station turret on each side. Turning length is 100 mm (3.94 in) per spindle, and the axes travel 150 mm (5.9 in) in X and 180 mm (7.1 in) in Z at 24 m/min.

The defining figure is that short turning length. At 100 mm (3.94 in) per spindle, the XWT-8 is laid out for disc-shaped and short cylindrical parts: hubs, collars, gear blanks and caps where the diameter matters more than the length. The workpiece rows list φ150 in diameter and a length of 80 with a load capacity of 3.0, which fits that picture of short, wide parts moved between the two spindles.

Spindle bearing I.D. is Ø100 mm, and the motor rating of 11 / 7.5 kW per spindle (written AC11 / 7.5 ×2 in the motor row) gives each side enough power for steel blanks of this diameter at the 4,000 rpm ceiling.

The footprint is close to square, 2,250 x 2,187 mm (88.6 x 86.1 in), which suits a cell where machines face an aisle or a robot from one side. The control is listed as FANUC 0i-TF Plus Type 0.

The XW-130M uses the same spindle rating and collet with 170 mm (6.7 in) of X and 220 mm (8.7 in) of Z, and adds driven tools at 4,000 rpm. The XWT-10 is the larger model, turning to 200 mm (7.87 in) on 18.5 / 15 kW × 2 spindles with 270 mm (10.6 in) of Z. The XWT-8 sits below both, for buyers whose parts are short and do not need driven tools.

Full Specifications

Parameter	Value
Max Turning Length	100 mm (3.94 in) per spindle
Spindle Motor Power	11 / 7.5 kW × 2
Spindle Bore	100 mm (3.94 in)
Chuck Size	Collet, 8 × 2
CNC Control	FANUC 0i-TF Plus Type 0
Floor Space Required	2,250 x 2,187 mm (88.6 x 86.1 in)
Max Spindle Speed	4,000 rpm
Maxstroke	X:150Z:180
Rapid Traverse Rate	X 24 m/min, Z 24 m/min
Speendle Motor	AC11 / 7.5 ×2
W L H	2,250×2,187
Workpiece Diameter	φ150
Workpiece Length	80
Max Load Capacity	3.0
Spindle Bearing ID	Ø100 mm
Turret Type	8-station turret × 2
X-Axis Travel	150 mm (5.9 in)
Z-Axis Travel	180 mm (7.1 in)

Specifications sourced from takamaz.co.jp — verified 2026-10-03

Strengths & Limitations

Strengths

Two 11 / 7.5 kW spindles at up to 4,000 rpm, each with an 8 collet
24 m/min rapids on X and Z over short 150 mm (5.9 in) and 180 mm (7.1 in) strokes
8-station turret × 2 lets both operations run with their own tools
Near-square footprint of 2,250 x 2,187 mm (88.6 x 86.1 in)
Ø100 mm spindle bearing I.D. on each spindle

Limitations

Turning length is limited to 100 mm (3.94 in) per spindle
No driven tool rows in the table; the XW-130M offers live tools at 4,000 rpm
8 stations per turret limit tool count on complex parts
X travel of 150 mm (5.9 in) is shorter than the 170 mm (6.7 in) of the XWT-10

Best For

Short hubs, collars and caps up to 100 mm (3.94 in) long Two-operation turning of disc-shaped parts Twin-spindle production where driven tools are not needed Cells with limited floor space for a square machine footprint

Frequently Asked Questions

01 What size parts does the Takamaz XWT-8 handle?

Turning length is 100 mm (3.94 in) per spindle, and the workpiece rows give φ150 in diameter with a length of 80 and a load capacity of 3.0. Workholding is Collet, 8 × 2. The machine is meant for short, wide chucked parts.

02 How does the XWT-8 differ from the XWT-10?

The XWT-10 turns up to 200 mm (7.87 in) on 18.5 / 15 kW × 2 spindles with a 10 collet, runs at 2,800 rpm (4,000 optional) and has 170 mm (6.7 in) of X and 270 mm (10.6 in) of Z. The XWT-8 has 11 / 7.5 kW × 2 at 4,000 rpm with 150 mm (5.9 in) of X and 180 mm (7.1 in) of Z.

03 What are the XWT-8 spindle figures?

Each of the two spindles is rated 11 / 7.5 kW and runs to 4,000 rpm. The spindle bearing I.D. is Ø100 mm. Each side has an 8-station turret, and both axes rapid at 24 m/min.

04 How much floor space does the XWT-8 need?

The footprint is listed as 2,250 x 2,187 mm (88.6 x 86.1 in). Allow extra room for chip handling, coolant and any part conveyor or loader access around that outline when planning the cell.
