Takamaz XT-8

Est. $90,000 - $140,000 Specs verified 2026-10-03 · takamaz.co.jp Updated 2026-10-03

Image: takamaz.co.jp, Takamaz

Key Specifications

X Travel

190 mm (7.5 in)

Z Travel

400 mm (15.7 in)

Max Spindle

3,500 rpm (5,000 / 3,000 optional)

Rapid Traverse

X 18 m/min, Z 24 m/min

Spindle Power

11 / 7.5 kW:Ø100 3,500rpm (15/11:Ø100 5,000rpm optional) (15/11:Ø120 3,000rpm optional)

Max Turn Length

80 mm (3.15 in)

How much does the Takamaz XT-8 cost?

Estimated price range

Est.$90,000 - $140,000

Our best estimate for a cnc lathes / turning center in this class — not a quote from Takamaz. Configuration moves it a long way.

Overview

The Takamaz XT-8 is the turning-only chucker of the XT-8 family: an 8 in collet (10 in optional), an 8-station turret as standard with a 12-station turret as an option, 190 mm (7.5 in) of X and 400 mm (15.7 in) of Z. The standard spindle is rated 11 / 7.5 kW on a Ø100 mm bearing and runs to 3,500 rpm.

For a shop that only turns, bores and drills on centre, the XT-8 avoids paying for live tooling it will not use, and it is the narrowest of the family at 1,600 × 1,535 mm (W × L). Neither the XT-8M nor the XT-8MY lists its 10 in chuck option, which opens the machine to larger chucked blanks than the 8 in collet takes.

The spindle comes in three specifications. The standard 11 / 7.5 kW with a Ø100 mm bearing runs to 3,500 rpm. One option raises the rating to 15 / 11 kW and the speed to 5,000 rpm on the same Ø100 mm bearing, for smaller diameters and faster finishing. The other fits a Ø120 mm bearing with 15 / 11 kW at 3,000 rpm, for heavier cuts on larger parts. Loader workpieces are listed up to 150 mm in diameter, 50 mm long and 1.5 kg.

The 8-station turret is the main limit. A part needing more than eight tools must either be split across two operations or the 12-station turret ordered. The XT-8M on the same platform comes with the 12-station turret and 12 live tools rated to drill Ø20 mm and tap M16, with 420 mm (16.5 in) of Z, and is the next step when parts need cross-holes. Rapids on the XT-8 are 18 m/min on X and 24 m/min on Z.

Full Specifications

Parameter	Value
Max Turning Diameter	80 mm (3.15 in)
Max Turning Length	80 mm (3.15 in)
Spindle Motor Power	11 / 7.5 kW:Ø100 3,500rpm (15/11:Ø100 5,000rpm optional) (15/11:Ø120 3,000rpm optional)
Chuck Size	8 in collet (10 in optional)
CNC Control	TAKAMAZ & FANUC 0i-TF Plus
Floor Space Required	1,600 × 1,535 mm (W × L)
Max Spindle Speed	3,500 rpm (5,000 / 3,000 optional)
Maxstroke	X:190Z:400
Rapid Traverse Rate	X 18 m/min, Z 24 m/min
W L	1,600 × 1,535
Workpiece Diameter	φ150
Workpiece Length	50
Max Load Capacity	1.5
Spindle Bore	100 mm (120 mm optional)
Spindle Bearing ID	Ø100 mm (Ø120 mm optional)
Turret Type	8-station turret (standard) / 12-station turret (option)
X-Axis Travel	190 mm (7.5 in)
Z-Axis Travel	400 mm (15.7 in)

Specifications sourced from takamaz.co.jp — verified 2026-10-03

Strengths & Limitations

Strengths

Optional 10 in chuck in place of the 8 in collet for larger chucked blanks
Narrowest of the XT-8 family at 1,600 × 1,535 mm (W × L)
Spindle options of 15 / 11 kW at 5,000 rpm or 15 / 11 kW at 3,000 rpm with a Ø120 mm bearing
12-station turret available as an option to the standard 8-station
X travel of 190 mm (7.5 in) and Z travel of 400 mm (15.7 in)

Limitations

No live tools in the table, so cross-holes and flats need another machine
Standard turret has only 8 stations; 12 stations is an extra-cost option
Standard spindle tops out at 3,500 rpm
Loader workpiece length of 50 mm limits automatic loading to short parts

Best For

Turning and boring of chucked parts up to 150 mm diameter Larger blanks held in the optional 10 in chuck Shops that do not need live tooling Loader-fed production of parts up to 1.5 kg

Frequently Asked Questions

01 What is the difference between the XT-8 and the XT-8M?

The XT-8 is a turning machine with an 8-station turret as standard, 400 mm (15.7 in) of Z and a 1,600 × 1,535 mm footprint, with a 10 in chuck option. The XT-8M has a 12-station turret with 12 live tools rated to drill Ø20 mm and tap M16, 420 mm (16.5 in) of Z and a 1,750 × 1,535 mm footprint.

02 Which spindle options does the XT-8 offer?

Standard is 11 / 7.5 kW with a Ø100 mm bearing and 3,500 rpm. Options are 15 / 11 kW with the Ø100 mm bearing at 5,000 rpm, or 15 / 11 kW with a Ø120 mm bearing at 3,000 rpm. Pick the faster one for small diameters and the larger bearing for heavy cuts.

03 Can the XT-8 take a larger chuck?

Yes. The standard workholding is an 8 in collet and a 10 in chuck is listed as an option. Loader workpieces are listed up to 150 mm in diameter, 50 mm in length and 1.5 kg.

04 How many tools does the XT-8 turret hold?

The standard turret has 8 stations. A 12-station turret is an option. None of the stations is listed with live tooling, so the XT-8 turns, bores and drills on centre only.
