Palmary PCB-3015
Image: palmary.com, Palmary
Key Specifications
grinding diameter range
wheel size
wheel peripheral speed
grinding wheel dressing device
regulating wheel size
regulating wheel speed
How much does the Palmary PCB-3015 cost?
Price estimate
We do not have a price for the Palmary PCB-3015 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Palmary PCB-3015 is the 150 mm wheel version of Palmary's small 6-axis CNC centerless grinder. It grinds Ø0.3 to Ø25 mm, the same range as the PCB-3010, with wheels half as wide again and a larger motor.
The table shows exactly what changes with the wider wheel. The grinding wheel becomes Ø305 mm by 150 mm and the regulating wheel Ø205 mm by 150 mm. The grinding wheel motor is 5.5 kW (7.4 hp), where the PCB-3010 has 3.7 kW. And the Y and B traverses are 170 mm (6.7 in), where the PCB-3010 has 120 mm, which fits axes that move across the wheel face, such as dresser traverses. X stays at 100 mm (3.9 in), C at 60 mm (2.4 in), Z at 45 mm (1.8 in) and A at 35 mm (1.4 in).
Unlike Palmary's FCL-1810, then, this wide model gets the power to use its width. For through-feed work on small diameters a 150 mm zone raises throughput; for infeed it admits longer parts.
Grinding speed is 45 m/s (8,858 ft/min). The regulating wheel motor is 0.75 kW (1.0 hp), with 10 to 200 rpm. The coolant pump is listed for both wheel and dressing cooling, and the coolant tank holds 100 L (26.4 gal). A FANUC CNC controller, both work rests and a spindle lubrication system are standard; an automatic loading and unloading system, in-process gauge and enclosure are options. Weight is 2,200 kg (4,850 lb).
Full Specifications
| Parameter | Value |
|---|---|
| Grinding Diameter Range | Ø0.3~Ø25 mm |
| Wheel Size | Ø305 x 150 x Ø177.8 mm (12.0 x 5.9 x 7.0 in) |
| Wheel Peripheral Speed | 45 m/s (8,858 ft/min) |
| Grinding Wheel Dressing Device | Single-point dressing device |
| Regulating Wheel Size | Ø205 x 150 x Ø90 mm (8.1 x 5.9 x 3.5 in) |
| Regulating Wheel Speed | 10-200 rpm (variable speed) |
| Regulating Wheel Tilt Angle | ± 5° |
| Regulating Wheel Swivel Angle | ±0.5° |
| Regulating Wheel Dresser Swivel Angle | ±5° |
| Regulating Wheel Dresser Offset | 0~5 mm |
| X Axis Travel | 100 mm (3.9 in) |
| C Axis Travel | 60 mm (2.4 in) |
| Z Axis Travel | 45 mm (1.8 in) |
| Y Axis Travel | 170 mm (6.7 in) |
| A Axis Travel | 35 mm (1.4 in) |
| B Axis Travel | 170 mm (6.7 in) |
| Wheel Spindle Motor | 5.5 kW (7.4 hp) |
| Regulating Wheel Motor | 0.75 kW (1.0 hp) |
| Slide Lubrication Motor | 0.03 kW |
| Coolant Pump Motor | 0.093 kW (wheel/dressing cooling) |
| Coolant Tank | 100 L (26.4 gal) |
| Wheel Spindle Lubrication Tank | 1.0 L (0.3 gal) |
| Slide Lubrication Tank | 4.0 L (1.1 gal) |
| Machine Weight | 2,200 kg (4,850 lb) |
| CNC Control | FANUC CNC controller |
Specifications sourced from palmary.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 150 mm wide wheels with a 5.5 kW (7.4 hp) grinding wheel motor to match
- Same Ø0.3 to Ø25 mm range as the narrower model
- 170 mm (6.7 in) of Y and B axis travel
- 45 m/s (8,858 ft/min) wheel speed on a bearing spindle
Limitations
- Enclosure, linear scale and in-process gauge are optional accessories
- Regulating wheel motor of 0.75 kW (1.0 hp)
- Maximum standard diameter of Ø25 mm
- Single-point dressing as standard; the diamond roller dresser is an option
Best For
Frequently Asked Questions
01
Standard grinding range Ø0.3 to Ø25 mm. Grinding wheel Ø305 x 150 mm on a 177.8 mm bore; regulating wheel Ø205 x 150 mm on a 90 mm bore. Machine weight is 2,200 kg (4,850 lb).
02
For wheel width and power. The PCB-3010 has 100 mm wheels and a 3.7 kW (5.0 hp) grinding motor. The PCB-3015 has 150 mm wheels and 5.5 kW (7.4 hp). The diameter range, wheel speed and control are the same.
03
Variable speed from 10 to 200 rpm. Tilt angle ±5°, swivel angle ±0.5°. The regulating wheel dressing device swivels ±5° and its offset is adjustable from 0 to 5 mm.
04
Palmary says unmanned production is possible when the automatic loading and unloading system is added, and that the 6-axis controller can be arranged with a 4-axis robot system. Both are options, as is the size measuring system.
