Palmary OCA-3295
Image: palmary.com, Palmary
Key Specifications
swing over table
distance between centers
max grinding diameter
max load between centers
wheel size
wheel peripheral speed
How much does the Palmary OCA-3295 cost?
Price estimate
We do not have a price for the Palmary OCA-3295 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Palmary OCA-3295 is the longest CNC angular cylindrical grinder Palmary lists, with 950 mm (37.4 in) between centers. It keeps the Ø320 mm (12.6 in) swing and Ø300 mm (11.8 in) grinding diameter of the series and weighs 8,000 kg (17,637 lb).
One figure needs a second look before ordering. The table stroke is given as 1,200 mm (47.2 in), the same as on the OCA-3265. With 950 mm between centers that leaves less run-off past the ends of a full-length part than the shorter machines enjoy, which matters for dressing and for loading. Ask Palmary how the stroke is laid out relative to the centers.
The taper range narrows too: the table swivels -1° to 6° here, against -1° to 8° on the OCA-3265. For work that is essentially parallel with square shoulders, which is what an angular grinder is bought for, that is rarely a limit.
Everything at the wheel is common to the series. A Ø610 mm wheel 150 mm wide runs at 33 m/s (6,496 ft/min) on an 11 kW (14.8 hp) motor and hydro-static bearings. The wheelhead strokes 360 mm (14.2 in). Palmary says the X and Z axes move together to dress a stepped profile for multiple-step grinding. Load between centers is 150 kg (331 lb), so long parts should be slender, and 2-point and 3-point steady rests are on the option list. Control is FANUC.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Table | Ø320 mm (12.6 in) |
| Distance Between Centers | 950 mm (37.4 in) |
| Max Grinding Diameter | Ø300 mm (11.8 in) |
| Max Load Between Centers | 150 kg (331 lb) |
| Wheel Size | Ø610 x 150 x Ø203.2 mm (24.0 x 5.9 x 8.0 in) |
| Wheel Peripheral Speed | 33 m/s (6,496 ft/min) |
| X Axis Rapid Traverse | 10 m/min (394 ipm) |
| X Axis Travel | 360 mm (14.2 in) |
| X Axis Min Setting Unit | 0.001 (0.0001) mm |
| Z Axis Rapid Traverse | 10 m/min (394 ipm) |
| Z Axis Travel | 1,200 mm (47.2 in) |
| Z Axis Min Setting Unit | 0.001 (0.0001) mm |
| Table Swivel Angle | -1°~6° |
| Workhead Swivel Angle | 0°~+90° |
| Workhead Center Taper | M.T. No. 4 |
| Work Spindle Speed | 0-300 rpm |
| Max Load of Work Spindle | 35 kg (77 lb) |
| Tailstock Center Taper | M.T. No. 4 |
| Tailstock Stroke | 25 mm (1.0 in) |
| Tailstock Fine Adjustment Range | ±0.03 mm (±0.0012 in) |
| Wheel Spindle Motor | 11 kW (14.8 hp) |
| Workhead Motor | 0.37 kW (0.5 hp) (4P) |
| Wheelhead Feed Motor | 0.37 kW (0.5 hp) (4P) |
| Table Feed Motor | 1.8 kW (2.4 hp) (AC Servo Motor) |
| Hydrostatic Pump Motor | 0.37 kW (0.5 hp) (4P) |
| Wheel Spindle Lubrication Pump Motor | 0.18 kW (0.2 hp) (4P) |
| Coolant Pump Motor | 0.37 kW (0.5 hp) (2P) |
| Ballscrew Lubrication | Auto lubricator (LUBE) |
| Wheel Spindle Lubrication Tank | 31 L (8.2 gal) |
| Lubrication Tank | 31 L (8.2 gal) |
| Hydraulic Tank | 31 L (8.2 gal) |
| Ballscrew Lubrication Tank | 0.7 L (0.2 gal) |
| Coolant Tank | 230 L (60.8 gal) |
| Machine Weight | 8,000 kg (17,637 lb) |
| CNC Control | FANUC CNC controller |
Specifications sourced from palmary.com — verified 2026-10-05
Strengths & Limitations
Strengths
- 950 mm (37.4 in) between centers, the longest OCA model
- 8,000 kg (17,637 lb) machine weight for stability under a 150 mm wide wheel
- Profile dressing by simultaneous X and Z movement, as Palmary states
- Fully enclosed splash guard, X-axis linear scale and wheel-change crane are standard
Limitations
- Table stroke of 1,200 mm (47.2 in) is no longer than on the OCA-3265
- Table swivel reduced to -1° to 6°
- 150 kg (331 lb) between centers
- Steady rests are optional accessories
Best For
Frequently Asked Questions
01
Up to 950 mm (37.4 in) between centers and Ø300 mm (11.8 in) in diameter. The table stroke is 1,200 mm (47.2 in). The weight limit is 150 kg (331 lb) between No. 4 Morse taper centers.
02
8,000 kg (17,637 lb), compared with 6,800 kg (14,991 lb) for the OCA-3265 and 5,600 kg (12,346 lb) for the OCA-3235. The coolant tank holds 230 L (60.8 gal) and the three oil tanks 31 L (8.2 gal) each.
03
A taper fine adjustment tailstock is a standard accessory; the list gives ±0.02 mm for it, while the specification table gives a fine adjustment range of ±0.03 mm. Tailstock stroke is 25 mm (1.0 in). A hydraulic tailstock is optional.
04
Palmary lists an adjustable 3-jaw scroll chuck, 7 in, and an adjustable 4-jaw scroll chuck, 8 in, as optional accessories. Cam-locked driving dogs and work holders are also options. The work spindle carries 35 kg (77 lb) including the holder.
