Mazak VARIAXIS i-1050 5X

$650,000 – $950,000 Updated 2026-03-17

Key Specifications

Max Spindle

8,000 RPM

Spindle Taper

CAT 50

Tool Capacity

40 tools standard (80, 120 optional)

Rapid Traverse

40 m/min (1,575 ipm) X/Y/Z

Spindle Power

45 kW (60 hp) at 40% ED; 37 kW (50 hp) continuous

Max Workpiece ⌀

1,400 mm (55.1 in)

Overview

The Mazak VARIAXIS i-1050 5X is the largest model in the VARIAXIS i-Series vertical 5-axis machining center lineup, designed for shops that need maximum table size, workpiece weight capacity, and material removal capability in a trunnion-style 5-axis machine. With a 1,050 mm diameter rotary table, 1,500 kg workpiece capacity, and a powerful CAT 50 spindle, the i-1050 5X addresses the demands of large aerospace structural work, heavy energy components, and oversized mold and die machining.

Axis travels step up significantly from the i-800: X-axis runs 900 mm, Y-axis 1,400 mm, and Z-axis 700 mm. These travels allow larger parts to be fully machined in a single setup, and the 1,400 mm Y-axis is one of the longest available on any production 5-axis VMC. The trunnion table at 1,050 mm diameter accepts workpieces up to 1,400 mm in diameter and 500 mm in height — covering large bulkheads, wing ribs, engine mounts, and structural frames that would otherwise require multiple setups or a larger HMC.

The CAT 50 spindle delivers 45 kW (60 hp) and 500 Nm of torque with an 8,000 RPM maximum speed. The higher power rating compared to the i-800 reflects the i-1050's heavier cutting targets in thick titanium and steel. Roller gear cam drives on A-axis (-120 to +30 degrees) and C-axis (360-degree continuous) deliver backlash-free positioning. Rapid traverse is 40 m/min.

MAZATROL SmoothAi manages all five simultaneous axes with AI vibration detection and advanced thermal compensation. Machine weight reaches 38,000 kg, providing substantial thermal mass for vibration control during aggressive cutting. The i-1050 5X is Mazak's answer to the DMG Mori DMU 125 FD, Okuma MU-10000H, and Hermle C 62.

Full Specifications

Parameter	Value
X Axis Travel	900 mm (35.4 in)
Y Axis Travel	1,400 mm (55.1 in)
Z Axis Travel	700 mm (27.6 in)
A Axis Range	-120 to +30 degrees
C Axis Range	360 degrees (continuous)
Max Spindle Speed	8,000 RPM
Spindle Taper	CAT 50
Spindle Motor Power	45 kW (60 hp) at 40% ED; 37 kW (50 hp) continuous
Spindle Torque	500 Nm (369 ft-lb) at 40% ED; 350 Nm continuous
Table Diameter	1,050 mm (41.3 in)
Max Workpiece Diameter	1,400 mm (55.1 in)
Max Workpiece Height	500 mm (19.7 in)
Max Workpiece Weight	1,500 kg (3,307 lb)
Rapid Traverse Rate	40 m/min (1,575 ipm) X/Y/Z
Tool Capacity	40 tools standard (80, 120 optional)
Max Tool Diameter	160 mm (6.3 in)
Max Tool Length	450 mm (17.7 in)
Max Tool Weight	30 kg (66 lb)
Machine Weight	38,000 kg (83,776 lb)
CNC Control	MAZATROL SmoothAi CNC

Specifications sourced from mazakusa.com — verified 2026-03-28

Strengths & Limitations

Strengths

1,050 mm table diameter and 1,500 kg capacity enable 5-axis machining of large aerospace structures that exceed the envelope of most vertical 5-axis machines
1,400 mm Y-axis travel is among the longest available on any production trunnion-style 5-axis VMC, covering elongated aerospace wing panels and structural frames
45 kW / 500 Nm CAT 50 spindle delivers maximum cutting power for heavy titanium and steel roughing on large structural components
38,000 kg machine weight provides exceptional vibration damping for deep cuts in difficult materials
Roller gear cam drives on both rotary axes maintain positioning accuracy over millions of cycles without the wear associated with worm gear drives
500 mm maximum workpiece height is the most generous in the VARIAXIS series, accommodating tall components that cannot be machined on the i-800

Limitations

8,000 RPM maximum spindle speed makes the i-1050 less suitable for high-speed aluminum machining — the machine is optimized for steel and titanium
At 38,000 kg, installation requires very substantial floor loading analysis and likely a concrete pit with isolation
Capital cost from $650,000 requires consistent aerospace or energy sector workload to justify the investment
Setup and fixturing for 1,050 mm table work requires overhead crane access and skilled setup personnel familiar with large-part 5-axis fixturing
40-tool standard ATC may be insufficient for complex large parts; upgrading to 120 tools is often required and adds cost

Best For

Aerospace prime manufacturers machining large titanium wing ribs, bulkheads, and structural frames up to 1,400 mm in length Defense contractors producing large structural components for military aircraft, helicopter frames, and armored vehicle parts in titanium and steel Large mold and die shops machining oversized steel mold cavities, cores, and electrodes with 5-axis contouring Energy sector manufacturers producing large turbine housings, impeller assemblies, and compressor components in superalloys Aerospace repair and overhaul operations reconditioning large engine cases and structural assemblies requiring simultaneous 5-axis access

Frequently Asked Questions

01 What does a Mazak VARIAXIS i-1050 5X cost?

New pricing typically ranges from $650,000 to $950,000 fully configured. The large table, heavy-duty spindle, and automation options drive pricing toward the upper end of this range. Mazak typically quotes the i-1050 5X with custom packages including ATC upgrades and automation for specific customer applications.

02 How does the i-1050 compare to the i-800 5X?

The i-1050 steps up to a 1,050 mm table (vs 800 mm), 1,500 kg load capacity (vs 1,000 kg), 900x1400x700mm travels (vs 630x1100x600mm), and 45 kW / 500 Nm spindle (vs 37 kW / 350 Nm). The i-1050 is the appropriate choice when parts regularly exceed the i-800's table diameter or workpiece height. The i-800 remains the better value for parts within its capacity range.

03 What is the maximum workpiece diameter the i-1050 can machine in 5-axis?

The table diameter is 1,050 mm, but the machine can accommodate workpieces up to 1,400 mm in diameter — the part extends over the table edges when the trunnion tilts. In 5-axis contouring mode, the practical workpiece envelope is somewhat smaller and depends on fixturing height and the required A-axis tilt range.

04 Can the i-1050 5X machine in all 5 axes simultaneously?

Yes. The i-1050 5X designation confirms simultaneous 5-axis interpolation with MAZATROL SmoothAi controlling all five axes concurrently. The machine is not limited to 3+2 positioning; it performs simultaneous contouring for aerospace surfaces, turbine blades, and complex structural features.

05 What automation options are available?
