Hyundai WIA L300A
Key Specifications
Max Spindle
Rapid Traverse
Spindle Power
Max Turn Length
max turning diameter
chuck size
Overview
The Hyundai WIA L300A is a mid-size 2-axis CNC turning center designed for shops that regularly machine larger-diameter chucked parts and require a step up from compact sub-10-inch chuck machines. With a 10-inch chuck, 430 mm (16.9 in) maximum turning diameter, and 610 mm (24 in) maximum turning length, the L300A handles the medium production turning work that compact lathes cannot accommodate. It sits squarely in competition with the Haas ST-20, Mazak QT-250, and DN Solutions Lynx 2600.
The spindle delivers 5,000 RPM with 18.5/15 kW (25/20 hp) — meaningfully more power than compact 8-inch chuck machines — and bar capacity of 76 mm (3 in) opens the machine to a wider range of bar stock diameters. The Fanuc i-Series control is standard, maintaining operator familiarity across the Hyundai WIA fleet. A 12-station turret with BMT tooling provides good flexibility for complex turning programs.
Hyundai WIA's 30-degree slant-bed one-piece casting carries forward from the smaller L230A, and the L300A's larger footprint still fits within the floor space budget of most turning cells. The machine weighs approximately 5,500 kg, providing adequate mass for vibration damping in medium-depth cuts on steel and stainless. Rapid traverse of 30 m/min (1,181 ipm) in X and Z is competitive for the class.
At $65,000-$90,000 new, the L300A undercuts or matches the Haas ST-20 while offering a machine built to similar quality standards. Korean manufacturing and favorable exchange rates allow Hyundai WIA to be price-competitive without compromising build quality. For shops running medium-size turned parts in production volumes, the L300A offers an excellent value proposition with full OEM support.
Full Specifications
| Parameter | Value |
|---|---|
| Max Turning Diameter | 430 mm (16.9 in) |
| Max Turning Length | 610 mm (24 in) |
| Chuck Size | 10" |
| Bar Capacity | 2.9921" |
| Swing Over Bed | 29.528" |
| Max Spindle Speed | 5,000 RPM |
| Spindle Motor Power | 18.5/15 kW (25/20 hp) |
| Spindle Nose | A2-6 |
| Turret Stations | 12 |
| Turret Type | BMT turret |
| Guideway Type | Linear guides |
| Rapid Traverse Rate | 30 m/min (1,181 ipm) |
| Machine Weight | 5,500 kg (12,125 lb) |
| CNC Control | Fanuc i-Series |
| Tucson Hybrid | |
| 42075 As Shown | $41,295 as shown |
| Tucson Plug In Hybrid | |
| Ioniq 5 | |
| 45075 As Shown | $54,300 as shown |
| Santa Fe Hybrid | |
| 48700 As Shown | $47,850 as shown |
| Palisade Hybrid | |
| Ioniq 9 | |
| Elantra Hybrid | |
| 29800 As Shown | $29,800 as shown |
| Sonata Hybrid | |
| Sonata Gas Hybrid | |
| Ioniq 6 | |
| Venue | |
| 22825 As Shown | $23,450 as shown |
| Kona | |
| Tucson | |
| 39425 As Shown | $38,645 as shown |
| Santa Cruz | |
| 43700 As Shown | $42,750 as shown |
| Santa Fe | |
| 47600 As Shown | $46,850 as shown |
| Palisade | |
| 54560 As Shown | $51,000 as shown |
| Elantra | |
| 27175 As Shown | $26,775 as shown |
| 35100 As Shown | $34,350 as shown |
| Sonata | |
| 36050 As Shown | $35,500 as shown |
| Concept Vehicle | |
| Power | 29.5 hp |
| Available | 17inch Alloy wheels |
| Power Up To | 201 hp/150 kW |
| Combined | 139hp |
| Standard | HTRAC AWDHTRAC AWD is available on all trims. |
| Up To | 320 hp/239 kW320 hp/239 kW standard on AWD models. |
| Optional | HTRAC AWDHTRAC All Wheel Drive (AWD) available on all trims. |
| Modell300abrandhyundai Wiatypecnc Lathescontrolcontact Sales Rep | Contact Sales Rep. |
| Modell300abrandhyundai Wiatypecnc Lathescontrol | Contact Sales Rep. |
| Model | L300A |
| Brand | HYUNDAI WIA |
| Type | CNC Lathes |
| Chuck Size10bar Capacity29921 Axis3power295 Hp | Max RPM3,000 RPMSwing29.528"Machining Length28.347"ControlCNC |
| Axis | 3 |
| Max Rpm | 3,000 RPM |
| Machining Length | 28.347" |
| Cnc Control | CNC |
| Looking To Purchase A New Hyundai Wia L300a | Contact Sales Rep. |
Specifications sourced from machinetools.com — verified 2026-03-28
Strengths & Limitations
Strengths
- 10-inch chuck with 16.9-inch turning diameter handles medium-size chucked parts that compact lathes cannot reach
- 76 mm (3 in) bar capacity covers a wider range of bar stock without special spindle liners
- 18.5 kW (25 hp) spindle provides strong cutting power for productive material removal in steel and stainless
- Fanuc i-Series control ensures operator familiarity and access to the largest pool of qualified programmers
- 30 m/min rapid traverse reduces non-cutting time on programs with frequent tool changes
- 30-degree slant bed one-piece casting delivers good rigidity and efficient chip evacuation
- Competitive pricing at $65K-$90K versus the Haas ST-20 at similar or higher price points
Limitations
- 5,000 RPM maximum speed limits surface feet per minute on small-diameter finishing passes
- No live tooling on the base L300A — the L300LM or L300LMSY variants add milling and sub-spindle capability at added cost
- Hyundai WIA's North American dealer footprint is smaller than Haas or Mazak, which may affect service response times in some regions
- 610 mm turning length constrains shaft work — the L300LA long-bed variant extends this but costs more
- Linear guide design offers high speed but less vibration damping than box-way machines in heavy interrupted cuts
Best For
Frequently Asked Questions
01
New L300A machines typically sell for $65,000-$90,000 depending on options and dealer. Used machines from 2018-2022 commonly appear in the $35,000-$55,000 range depending on condition and hours. The L300A competes directly with the Haas ST-20 and often comes in at a similar or lower price.
02
The base L300A is a 2-axis turning center without live tooling. Hyundai WIA offers the L300LM (live milling, C-axis) and L300LMSY (live milling, sub-spindle, Y-axis) variants for shops needing mill-turn capability. These are priced higher but eliminate secondary milling operations on complex parts.
03
Both machines are mid-size 10-inch chuck 2-axis turning centers at comparable price points. The Haas ST-20 benefits from a larger dealer network and the well-known Haas NGC control. The L300A offers competitive specifications and Hyundai WIA's reputation for above-average build quality at the price point. Choose based on dealer proximity and control preference.
04
The L300A comes standard with flood coolant. Through-spindle coolant (TSC) is available as an option for deeper drilling and hard material applications. High-pressure coolant options up to 70 bar are available on some configurations. Chip conveyors are also available as factory or field-installed options.
