Huron DX 250-1000
Image: huron.fr, Huron
Key Specifications
Max Turn Length
Accuracy
Repeatability
swing over bed
standard turning diameter
max turning diameter
How much does the Huron DX 250-1000 cost?
Price estimate
We do not have a price for the Huron DX 250-1000 that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
With a full metre between chuck and centre, the Huron DX 250-1000 is the shaft version of the DX 250. It turns 1,000 mm (39.4 in) in length and 480 mm in diameter, on a 45° slant-bed machine weighing 6,000 kg (13,228 lb).
Everything except the bed length is shared with the DX 250-700. The A2-8 spindle has an 80 mm bore, passes 65 mm bar and runs 50-2,500 rpm, with 15.6/12 kW from the Siemens motor or 15/11 kW from the Fanuc motor. Cross travel is 250 mm. The extra 300 mm of bed adds only 250 kg, so the structure per unit length is much the same.
For metre-long work the tailstock matters. Huron fits a 100 mm quill with 120 mm of stroke and adjustable thrust up to 500 kgf, operated hydraulically. On slender shafts the 500 kgf limit and the absence of a steady rest in the table are the points to discuss with Huron.
The machine is 3,500 mm long and 1,890 mm wide. Rapid feed is 24 m/min, positioning 0.01 mm and repeatability 0.005 mm. An 8-station bi-directional servo turret is standard, and the series offers a live-tool turret as an option. Roller-type guideways and the monoblock bed are intended to keep vibration down on long cuts.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Bed | 600 mm (23.6 in) |
| Standard Turning Diameter | 300 mm (11.8 in) |
| Max Turning Diameter | 480 mm (18.9 in) |
| Max Turning Length | 1,000 mm (39.4 in) |
| X Axis Travel | 250 mm (9.8 in) |
| Z Axis Travel | 1,000 mm (39.4 in) |
| Rapid Traverse Xz | 24 m/min |
| Spindle Power Siemens | 15.6/12 kW (20.9/16.1 hp) |
| Spindle Power Fanuc | 15/11 kW (20.1/14.8 hp) |
| Spindle Speed Range | 50-2,500 rpm |
| Spindle Bore | 80 mm (3.1 in) |
| Spindle Nose | A2-8 |
| Bar Capacity | 65 mm (2.6 in) |
| Turret Stations | 8 |
| Max Boring Bar Diameter | 40 mm (1.6 in) |
| Tool Shank Size | 25 x 25 mm (1.0 x 1.0 in) |
| Tailstock Quill Diameter | 100 mm (3.9 in) |
| Tailstock Quill Stroke | 120 mm (4.7 in) |
| Tailstock Thrust | 500 kgf (max.) |
| Positioning Accuracy | 0.01 mm (0.0004 in) |
| Repeatability | 0.005 mm (0.0002 in) |
| Machine Weight | 6,000 kg (13,228 lb) |
| Machine Length | 3,500 mm (137.8 in) |
| Machine Width | 1,890 mm (74.4 in) |
| Machine Height | 1,900 mm (74.8 in) |
Specifications sourced from huron.fr — verified 2026-10-04
Strengths & Limitations
Strengths
- 1,000 mm (39.4 in) of turning length and Z travel
- 480 mm maximum turning diameter over a 600 mm swing
- Only 250 kg heavier than the 700 mm version, at 6,000 kg
- 100 mm hydraulic tailstock quill
- Optional live-tool turret for milling on shafts
Limitations
- Tailstock thrust is limited to 500 kgf
- No steady rest is listed in the table
- 2,500 rpm maximum spindle speed
- Bar capacity of 65 mm through an 80 mm bore
Best For
Frequently Asked Questions
01
Maximum turning length is 1,000 mm, with 1,000 mm of Z travel. Maximum turning diameter is 480 mm and standard turning diameter 300 mm.
02
An A2-8 spindle with an 80 mm bore and 65 mm of bar capacity, running 50-2,500 rpm. Power is 15.6/12 kW with the Siemens motor and 15/11 kW with the Fanuc motor.
03
The DX 350-1000 A has the same 1,000 mm turning length and the same spindle, but a 740 mm swing, a 600 mm maximum turning diameter and 310 mm of X travel. The DX 350-1000 A weighs 6,750 kg.
04
Approximately 3,500 mm long, 1,890 mm wide and 1,900 mm high, at approximately 6,000 kg (13,228 lb). Huron marks these values as approximate.
