Huron DX 200-5 A
Image: huron.fr, Huron
Key Specifications
Max Turn Length
Accuracy
Repeatability
swing over bed
standard turning diameter
max turning diameter
How much does the Huron DX 200-5 A cost?
Price estimate
We do not have a price for the Huron DX 200-5 A that we can stand behind, so we show no number. Configuration, options and installation move the final price a long way: a quote is the reliable figure.
Overview
The Huron DX 200-5 A marks the step to the larger DX 200 frame. Maximum turning diameter rises to 365 mm (14.4 in), cross travel to 200 mm and turning length to 500 mm, and the tailstock thrust goes up to 500 kgf.
The DX 200-4 B below it has 175 mm of X travel and a 320 mm turning limit. From this model upward the slide is longer and the machine is wider, 1,540 mm instead of the 1,440 mm of the DX 200-4 B. The standard turning diameter stays at 250 mm and the swing at 500 mm.
Spindle hardware is the A2-6 unit with a 70 mm bore and 52 mm bar capacity, running 50-4,000 rpm. Huron lists 13.5/9 kW for Siemens and 11/9 kW for Fanuc. The Fanuc figure differs from the DX 200-4 B, which is listed at 11/7.5 kW.
Half a metre between chuck and centre makes this a practical small shaft lathe. The quill is 85 mm in diameter with a 120 mm stroke. The servo turret has 8 stations and indexes in both directions. Rapids are 24 m/min, positioning is 0.007 mm and repeatability 0.005 mm. Weight is 3,400 kg (7,496 lb), and the machine is 2,350 mm long and 1,710 mm high.
Full Specifications
| Parameter | Value |
|---|---|
| Swing Over Bed | 500 mm (19.7 in) |
| Standard Turning Diameter | 250 mm (9.8 in) |
| Max Turning Diameter | 365 mm (14.4 in) |
| Max Turning Length | 500 mm (19.7 in) |
| X Axis Travel | 200 mm (7.9 in) |
| Z Axis Travel | 500 mm (19.7 in) |
| Rapid Traverse Xz | 24 m/min |
| Spindle Power Siemens | 13.5/9 kW (18.1/12.1 hp) |
| Spindle Power Fanuc | 11/9 kW (14.8/12.1 hp) |
| Spindle Speed Range | 50-4,000 rpm |
| Spindle Bore | 70 mm (2.8 in) |
| Spindle Nose | A2-6 |
| Bar Capacity | 52 mm (2.0 in) |
| Turret Stations | 8 |
| Max Boring Bar Diameter | 40 mm (1.6 in) |
| Tool Shank Size | 25 x 25 mm (1.0 x 1.0 in) |
| Tailstock Quill Diameter | 85 mm (3.3 in) |
| Tailstock Quill Stroke | 120 mm (4.7 in) |
| Tailstock Thrust | 500 kgf |
| Positioning Accuracy | 0.007 mm (0.0003 in) |
| Repeatability | 0.005 mm (0.0002 in) |
| Machine Weight | 3,400 kg (7,496 lb) |
| Machine Length | 2,350 mm (92.5 in) |
| Machine Width | 1,540 mm (60.6 in) |
| Machine Height | 1,710 mm (67.3 in) |
Specifications sourced from huron.fr — verified 2026-10-04
Strengths & Limitations
Strengths
- 365 mm maximum turning diameter with 200 mm of cross travel
- 500 mm of turning length and Z travel
- Tailstock thrust adjustable to 500 kgf
- Positioning still 0.007 mm at this bed length
- Fanuc motor listed at 11/9 kW
Limitations
- Bar capacity is 52 mm; the DX 200-5 B takes 75 mm
- Standard turning diameter remains 250 mm
- Maximum boring bar diameter is 40 mm
- No driven tools listed for the DX 200 series
Best For
Frequently Asked Questions
01
The DX 200-5 A has 200 mm of X travel, a 365 mm maximum turning diameter, 500 mm of turning length and 500 kgf of tailstock thrust. The DX 200-4 B has 175 mm, 320 mm, 400 mm and 300 kgf. Both use the A2-6 spindle with a 70 mm bore.
02
13.5/9 kW with the Siemens motor and 11/9 kW with the Fanuc motor, over a speed range of 50-4,000 rpm. The spindle nose is A2-6 and the bore 70 mm.
03
Approximately 2,350 mm long, 1,540 mm wide and 1,710 mm high. Machine weight is approximately 3,400 kg (7,496 lb).
04
Yes, the DX 200-5 B, which has an A2-8 nose, a 90 mm bore and 75 mm of bar capacity, with a 50-3,500 rpm speed range and 14.4/11 kW on the Siemens motor.
