GF Machining Mikron VCE 2000 Pro
Key Specifications
X Travel
Y Travel
Z Travel
Max Spindle
Spindle Taper
Tool Capacity
Overview
The Mikron VCE 2000 Pro is a production-oriented VMC from GF Machining Solutions VCE Pro series, designed for shops needing reliable high-uptime milling with GF build quality at a more accessible price than the MILL P or MILL E series.
Travels: 2,000 x 900 x 800 mm (78.7 x 35.4 x 31.5 in). Table: 2,100 x 850 mm (82.7 x 33.5 in), 3,000 kg (6,614 lb) capacity.
Standard spindle runs at 16,000 RPM with BT40/HSK-A63 taper. 24-pocket magazine (expandable to 60). Heidenhain TNC 640 control. Pricing: $300,000 to $450,000.
Full Specifications
| Parameter | Value |
|---|---|
| X-Axis Travel | 2,000 mm (78.7 in) |
| Y-Axis Travel | 900 mm (35.4 in) |
| Z-Axis Travel | 800 mm (31.5 in) |
| Table Size | 2,100 x 850 mm (82.7 x 33.5 in) |
| Table Load Capacity | 3000 kg |
| Max Spindle Speed | 16,000 RPM (10,000 / 6,000 RPM options) |
| Spindle Taper | BT40 / HSK-A63 |
| Tool Capacity | 40 / 60 pockets - HSK-A6330 / 40 / 60 pockets - ISO & BT4024 / 40 pockets - ISO & BT50 |
| CNC Control | Heidenhain TNC 640 |
| Travel X Y Z | 2000 x 900 x 800 mm |
| Feed Rate X Y Z | 20 m/min |
| Rapid Feed Rate Xy Z | 40 m/min |
| Working Table | 2100 x 850 mm |
| Working Spindle | 16'000 rpm - HSK-A63 / ISO & BT 4010'000 rpm - ISO & BT406'000 rpm - ISO & BT50 |
| Automation | System 3R Workpartner 1+, Transformer WorkMaster & Transformer 6-axis |
Specifications sourced from gfms.com — verified 2026-03-28
Strengths & Limitations
Strengths
- 2,000 x 900 x 800 mm travels with 3,000 kg table capacity provides generous working volume
- GF build quality and thermal stability at the VCE Pro price point
- Multiple spindle speed options optimize for the dominant material
- HSK-A63 or BT40 taper maintains compatibility with standard tooling
- Tool magazine expandable to 60 pockets supports complex programs
- Heidenhain TNC 640 provides advanced contour processing and look-ahead
Limitations
- Lacks ITC thermal compensation and Step-Tec spindle of MILL P series
- Competes with established Japanese and Korean VMCs at similar prices
- 3-axis configuration requires refixturing for multi-face work
- Limited high-speed finishing vs dedicated HSM machines with 30K+ RPM
Best For
Frequently Asked Questions
01
$300,000-$450,000 new depending on configuration.
02
VCE Pro is below MILL E. MILL E has higher speeds, better thermal management, broader automation. VCE Pro offers solid capability at lower cost.
03
16,000 RPM (10,000 / 6,000 RPM options)
04
Compatible with System 3R pallets and robotic loading.
