DN Solutions Vertical Machining Centers (VMC)

DN Solutions MYNX 7500 50 II

Est. $150,000 - $205,000 Specs verified 2026-10-02 · dn-solutions.com Updated 2026-10-02

Image: dn-solutions.com, DN Solutions

Key Specifications

X Travel

1,525 mm (60 in)

Y Travel

770 mm (30 in)

Z Travel

625 mm (25 in)

Max Spindle

6,000 rpm

Table Size

1,600 × 750 mm (63 × 30 in)

Spindle Power

18.5 kW (25 hp)

How much does the DN Solutions MYNX 7500 50 II cost?

Estimated price range

Est.$150,000 - $205,000

Our best estimate for a vertical machining centers (vmc) in this class — not a quote from DN Solutions. Configuration moves it a long way.

Overview

The DN Solutions MYNX 7500 50 II is a vertical machining center that pairs the large Mynx frame with a 6,000 rpm spindle: 1,525 mm (60 in) of X, 770 mm (30 in) of Y and 625 mm (25 in) of Z, a 1,600 × 750 mm (63 × 30 in) table and 18.5 kW (25 hp) of spindle power.

Power is where this model departs from its neighbours. The MYNX 7500 II on the same travels lists 15 kW (20 hp) at 8,000 rpm, and the smaller MYNX 6500 50 II lists 15 kW (20 hp) at 6,000 rpm; this machine is listed at 18.5 kW (25 hp), about 23% more. DN's table gives no torque figure for it, though. The MYNX 7500 II shows 286.5 N·m (211 ft-lb), and whether the 6,000 rpm machine matches or exceeds that is a question to put to DN together with the taper, because the answer decides which cutters it can drive.

The envelope is that of a plate and mould-base machine. Y travel of 770 mm (30 in) slightly exceeds the 750 mm (30 in) depth of the table, and the table takes 1,500 kg (3,307 lb). Z is no taller than on the MYNX 6500 50 II, which also has 625 mm (25 in), so the extra size is all in the plane of the table. Moving up again is a large jump: the MYNX 9500 has 2,500 mm (98 in) of X, 950 mm (37 in) of Y and a 3,500 kg (7,716 lb) load, at 23,000 kg (50,706 lb).

Rapids are 30 m/min (1,181 ipm) on X and Y and 24 m/min (945 ipm) on Z. The machine weighs 13,500 kg (29,762 lb), the same as the MYNX 7500 II. DN's table has no footprint row for this model. The MYNX 7500 II is listed at 3,900 × 4,050 mm (154 × 159 in) and 3,227 mm (127 in) high, which gives a first idea of the space, but get the layout drawing for this machine before the foundation is planned.

Full Specifications

Parameter	Value
X-Axis Travel	1,525 mm (60 in)
Y-Axis Travel	770 mm (30 in)
Z-Axis Travel	625 mm (25 in)
Rapid Traverse X	30 m/min (1,181 ipm)
Rapid Traverse Y	30 m/min (1,181 ipm)
Rapid Traverse Z	24 m/min (945 ipm)
Max Spindle Speed	6,000 rpm
Spindle Motor Power	18.5 kW (25 hp)
Table Size	1,600 × 750 mm (63 × 30 in)
Max Table Load	1,500 kg (3,307 lb)
Machine Weight	13,500 kg (29,762 lb)

Specifications sourced from dn-solutions.com — verified 2026-10-02

Strengths & Limitations

Strengths

18.5 kW (25 hp) of spindle power, about 23% more than the 15 kW (20 hp) of the MYNX 7500 II
770 mm (30 in) of Y travel over a 1,600 × 750 mm (63 × 30 in) table
Table load of 1,500 kg (3,307 lb)
13,500 kg (29,762 lb) of machine under 1,525 mm (60 in) of X travel
CAM-type tool changer and a structure DN describes as built for heavy duty cutting

Limitations

No torque figure in DN's table for this model, so cutting capacity cannot be read from the rows
Top speed is 6,000 rpm; the MYNX 7500 II reaches 8,000 rpm
No footprint, taper or tool capacity row for this model
Z travel is 625 mm (25 in), no more than on the smaller MYNX 6500 50 II
Z rapid is 24 m/min (945 ipm), below the 30 m/min (1,181 ipm) of X and Y

Best For

Large mould bases and die plates up to 1,500 kg (3,307 lb) Steel and cast-iron roughing that can use 18.5 kW (25 hp) below 6,000 rpm Plates up to 1,525 mm (60 in) long and 770 mm (30 in) wide Work too wide for the 670 mm (26 in) of Y on the MYNX 6500 50 II

Frequently Asked Questions

01 What separates the MYNX 7500 50 II from the MYNX 7500 II?

Spindle rows only. The MYNX 7500 50 II is listed at 6,000 rpm and 18.5 kW (25 hp), with no torque figure. The MYNX 7500 II is listed at 8,000 rpm, 15 kW (20 hp) and 286.5 N·m (211 ft-lb). Travels, the 1,600 × 750 mm (63 × 30 in) table, the 1,500 kg (3,307 lb) load, the rapids and the 13,500 kg (29,762 lb) weight are the same.

02 What torque does the MYNX 7500 50 II spindle produce?

DN's comparison table does not say. It lists 18.5 kW (25 hp) and 6,000 rpm for this model and leaves the torque row empty. The smaller MYNX 6500 50 II shows 286.5 N·m (211 ft-lb) with 15 kW (20 hp), which is a reference point and not this machine's figure. Ask DN for the torque and power chart.

03 How large and heavy a part fits the MYNX 7500 50 II?

Travels are 1,525 mm (60 in) in X, 770 mm (30 in) in Y and 625 mm (25 in) in Z. The table is 1,600 × 750 mm (63 × 30 in) and rated for 1,500 kg (3,307 lb) with fixtures. Y travel is slightly greater than the table depth, so a part that overhangs the table front to back can still be reached.

04 What should I plan for when installing a MYNX 7500 50 II?

The weight is 13,500 kg (29,762 lb). DN's table gives no length, width or height for this model. The MYNX 7500 II, which has the same travels and weight, is listed at 3,900 × 4,050 mm (154 × 159 in) and 3,227 mm (127 in) high. Use that only as a first estimate and plan from DN's layout drawing for the machine ordered.
